Instruction Manual for Installation and Application of JTW-ZOM-TC5162 Addressable Rate of Rise and Fixed Temperature Heat
Detector
〖Before installation and application of the product, please read the Instruction Manual for
Installation and Application〗
Instruction Manual for Installation and
Application of JTW-ZOM-TC5162 Addressable
Rate of Rise and Fixed Temperature Heat Detector
(Ver 2.0)
YINGKOU TIANCHENG FIRE PROTECTION EQUIPMENT CO., LTD.
1
China·Liaoning·Yingkou Tiancheng Fire Protection Equipment Co., Ltd.
Advertisement
Table of Contents
Summary of Contents for Tiancheng Fire Protection Equipment JTW-ZOM-TC5162
- Page 1 Instruction Manual for Installation and Application of JTW-ZOM-TC5162 Addressable Rate of Rise and Fixed Temperature Heat Detector 〖Before installation and application of the product, please read the Instruction Manual for Installation and Application〗 Instruction Manual for Installation and Application of JTW-ZOM-TC5162 Addressable Rate of Rise and Fixed Temperature Heat Detector (Ver 2.0)
- Page 2 Instruction Manual for Installation and Application of JTW-ZOM-TC5162 Addressable Rate of Rise and Fixed Temperature Heat Detector I General JTW-ZOM-TC5162 Addressable Rate of Rise and Fixed Temperature Heat Detector (Detector) uses advanced SCM technology. According to a variety of advanced fire criterion, detector can accurately and timely detect the changes of ambient temperature and determine fire and then alarm.
- Page 3 Instruction Manual for Installation and Application of JTW-ZOM-TC5162 Addressable Rate of Rise and Fixed Temperature Heat Detector 8. Dimension Diameter: 100mm Height: 50mm (with base) 4. Ingress protection rating: IP33 （Not tested to EN54 standard） Material and color of enclosure: ABS; milky white...
- Page 4 Instruction Manual for Installation and Application of JTW-ZOM-TC5162 Addressable Rate of Rise and Fixed Temperature Heat Detector V Mounting and Wiring 1. Mounting Installation of the detector is shown in Fig. 2. Fig. 2 3. Base of the detector is shown in Fig. 3. Fix the base with two tapping screws, and then connect loop to terminals (polarity-insensitive).
- Page 5 Instruction Manual for Installation and Application of JTW-ZOM-TC5162 Addressable Rate of Rise and Fixed Temperature Heat Detector 1).Registration: After confirming the installation and wiring is correct, register devices to the fire alarm control panel, and check whether the numbers of installed detectors and registered detectors are consistent.
- Page 6 Instruction Manual for Installation and Application of JTW-ZOM-TC5162 Addressable Rate of Rise and Fixed Temperature Heat Detector Check whether there is short circuit in the thermistor. IX Maintenance 1. The detector should be installed just before commission and kept well before installation, taken corresponding measures for dust-proof, damp-proof and corrosion-proof.
- Page 7 Instruction Manual for Installation and Application of JTW-ZOM-TC5162 Addressable Rate of Rise and Fixed Temperature Heat Detector WEEE Information 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
- Page 8 Instruction Manual for Installation and Application of JTW-ZOM-TC5162 Addressable Rate of Rise and Fixed Temperature Heat Detector China·Liaoning·Yingkou Tiancheng Fire Protection Equipment Co., Ltd Add: No.11-2 Kechechang Xili, Xishi District, Yingkou, Pilot Free Trade Zone (Liaoning), China Tel: 86-417-3553119 Post Code: 115004 E-mail: info@tcfiretech.com...
