SnapStream QAM/ATSC Quick Start

Quick Start:
1
Connect coax cable to your over-the-air antenna or in-house QAM feed.
A
Connect coax cable to the SnapStream Encoder (QAM/ATSC). See diagram.
B
Over-the-air antenna
Combiner
In-house QAM
QAM Encoder
2
Connect the SnapStream Encoder (QAM/ATSC) to your organization's network switch via ethernet cable.
A
Connect the SnapStream Encoder (QAM/ATSC) to power and turn it on.
B
SnapStream Encoder (QAM/ATSC)
NETWORK
LINE IN
MOUSE VGA OUT
LINE OUT
KEYBOARD DVI
HDMI
MIC IN
USB USB USB
