INSTRUCTIONS
1. Mount template to door or drawer.
2. Remove cam from lock. Drill 3/4" diameter hole.
3. Place collar onto lock and insert lock into hole.
4. Place spur washer (for wood only) to lock.
5. Place 3/4" nut tightly.
6. Place 90 or 180 rotation washer, whichever is preferred.
7. Place cam (either straight or bent, whichever suits conditions
better). You can adjust cam by bending it slightly.
8. Fasten lock with lock washer and screw.
1381
SATISFACTION GUARANTEED
(See website for details http://www.Hickoryhardware.com/warranty)
Belwith Products
©
3100 Broadway, SW • Grandville, MI 49418
Made to Belwith Products' specifications in China
Cabinet and
Drawer Lock
