Cobra Digital DVC3300 User Manual

Cobra digital digital camcorder user's manual
Hide thumbs Also See for DVC3300:
Table of Contents

Advertisement

Quick Links

Download this manual
Http://cobradigital.com/download.php

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVC3300 and is the answer not in the manual?

Questions and answers

Related Manuals for Cobra Digital DVC3300

Summary of Contents for Cobra Digital DVC3300

  • Page 1 Http://cobradigital.com/download.php...
  • Page 2 ENGLISH Basic Reference Congratulations on your selection of this camera! The basic reference provides you with the general information you need to start using it. CONTENTS Safety Precautions ... Quick Reference ... General Guide ... Trouble Shooting ... E-22...

  • Page 3: Safety Precautions

    You should be responsible for the damage to the camera or materials caused by your improper operation to the Digital camcorder! Do not expose the Digital camcorder to moisture and make sure no water get into the camera. Do not attempt to modify this Digital camcorder!
  • Page 4 FEATURES 5.1Mega pixels CMOS sensor, up to 12 Mega pixels Interpolated resolution 2-inch TFT color LCD monitor screen Long battery life 8x digital zoom 32MB internal flash memory, support max. 4GB SD card or MMC card This camera can play high quality MPEG-4 movie and Music Record DVD quality MPEG-4 video 10seconds or 20seconds self-timer PICT print...

  • Page 5: Package Contents

    Package Contents Check to make sure that all of the items shown on the below are included with your camera. If something is missing, contact with your dealer as soon as possible. Strap Camera USB cable AC adapter CD-ROM Strap Camera AC-adapter CD-ROM...

  • Page 6: Getting To Know Your Camera

    Getting to know your Camera Direction Button Shutter Button WT Button Display Button Menu Button Mode Button Power Button USB Port TV/Music Port...
  • Page 7 Getting to know your Video Camera Macro Switch Lens Memory Card Slot Flash Tripod Microphone...

  • Page 8: Remote Controller

    Remote Controller...

  • Page 9: Loading The Battery Into The Camera

    Loading the battery into the camera 1.Slide the battery cover and unload it . 2.Align the [+-] mark on the battery with camera. 3.Close the battery cover. Using a Memory Card 1.The camera has 32MB built-in memory for recording. 2.The camera support 4GB SD card or MMC card. Note: When there is a memory card inserted, it will be the top priority for saving data.

  • Page 10: Using Memory Card

    Using Memory Card While the camera cannot read the memory card, please clean metal interface softly with soft cloth and then reload. Never remove a card from the camera while the camera is working. Doing so can cause the file save operation to fail, and even damage the memory card.

  • Page 11: Recording An Image

    Recording an image 1.Open TFT , the camera will be on automatically. 2.Press the MODE button, and choose the capture mode. 3.Point the camera at the subject, and use the monitor screen to compose the image. 4.Holding the camera still, gently press the shutter to release button. When the image shown on the screen turning left, indicating the image is recorded.
  • Page 12 Capture Tab Menu 3264X2448 2592X1944 2048X1536 1024X768 Setup Tab Menu...

  • Page 13: Recording A Video

    Recording a video 1.Press the MODE button, and choose the video mode. 2.Press the SHUTTER to release button fully to start video recording. A red dot and the recording time will appear on the display. Press Note: 1.In recording mode, press the 2.In standby mode, press [MENU] press...

  • Page 14: Recording Voice

    Recording voice 1.Press the MODE button, and choose the voice mode. 2.Press the SHUTTER release button fully to start voice recording. The recording time will appear on the screen. Press Playback 1.Press the MODE button, and choose the playback mode. 2.Press until the image you want to display.

  • Page 15: Music Mode

    Play Tab Menu Music Mode 1.Press the MODE button, and choose the music mode. 2.Press to choose the downloaded music file which you want to play, press [SHUTTER] to play, press pause, and press [SHUTTER] [DISPLAY] again to stop. Play the files circularly Repeat the current file Play all file one time Adjust the volume...
  • Page 16 Note: When you copy music from PC to your camera or SD card, please choose mass storage in PC mode, and connect your camera and computer via the USB cable. Then you can creat a music file under this path My Computer/Removable Disk/MP3, and copy the music you downlo aded from your PC into this file.
  • Page 17 You can print the picture directly via a PictBridge printer. Power up the camcorder, and enter PLAY BACK mode, please choose the picture which one will be printed. Then press print menu, please use the USB cable connect your camcorder and the printer, and it will print the picture automatically.
  • Page 18 Downloading photos/video to the PC Instructions to install USB driver and application software to your computer. Please read the following instruction carefully before installing driver program. 1. Please insert the software CD into the CD driver befor e connecting the camera to the comp uter ( thi s CD is atta ched in t he pack age.) and the insta ll program will run automatically.
  • Page 19 Downloading photos/video to the PC Note: If there is something wrong with the automatic installation, you could also finish the installation manually according to the guide to install the hardware. The corresponding driver program could be found in the drivers\manual folder in the CD root folder. Please read in this folder.
  • Page 20 Instaling tools software on your computer 1.Insert the CD into the CD-ROM driver. This will automatically launch the menu application, which displays a menu screen on your computer. 2.Install program for editing photo. Follow the instructions that appear on your computer screen.
  • Page 21 How to convert movie to MPEG-4 format and play Use the procedures in the section to install the software from the bundled CD-R OM to you computer. Select install Media converting file to MPEG-4 format. 1.Run the Media Converter , and choose a source file which comes from your computer to convert, then select the path which you want to save the MPEG-4 movie.
  • Page 22 How to convert movie to MPEG-4 format and play 2.You can find out the MPEG-4 files in the path you have chosen at the first step. 3.Set your camera to Mass Storage, and use the USB cable to connect your camera and computer. 4.Copy the MPEG-4 files to the memory card.

  • Page 23: Troubleshooting

    TROUBLE SHOOTING memory card is loaded, camera cannot record. Memory card is locked. Please unlock it. Memory card is full. Please transfer the files you want to keep to your computer and then delete files from memory, or use a different memory card. Image is not record when the shutter button is pressed.
  • Page 24 TROUBLE SHOOTING The image is too dark or too bright. Please reset the EV SHIFT. The flash does not fire. Flash off is selected as the flash mode. Please select a different mode. The date displayed is not correct. Please reset the date and time in setup mode. Can not print the photos.
  • Page 47 7750-000491-001...
