- Page 1 DV PowerPacks Li-Ion Batteries for Camcorders, On-Camera Lights and Accessories USER MANUAL Revision 5.0 www.blueshape.net Printed in Malta 2022...
- Page 2 BMBP9 Series Replaces Canon BP-9XX Main Features: Charge Indicator (4-Step LED) Battery Data Communication with RED® KOMODO™ Blueshape Plus - Higher Capacity Specifications: Nominal Voltage: 7.2V Nominal Capacity: 46Wh / 69Wh Weight: 212g / 293g ...
- Page 3 BMBPU90 Replaces Sony BP-U90 Main Features: Charge Indicator (4-Step LED) 1x D-Tap 1x USB (Type A - 1.0A Max./ 5W) Specifications: Nominal Voltage: 14.4V Nominal Capacity: 6700mAh—96Wh Weight: 418g BMNPF Series Replaces Sony NP-FXXX Main Features BMNPF970: Charge Indicator (4-Step LED) ...
- Page 4 BMNPFV100 Replaces Sony NP-FV100 Main Features: High Capacity Specifications: Nominal Voltage: 7.2V Nominal Capacity: 3100mAh—22Wh Weight: 126g Warning Do not charge in Turbo Mode BMJVC70 Replaces JVC SSL JVC-70 Main Features: Charge Indicator (4-Step LED) 1x USB (Type A - 2.1A Max./ 10.5W) ...
-
Page 5: Specifications
CMDUAL-PD Main Features: Turbo Mode (2.0A - 2.5A per channel) Interchangeable Universal Plate System Charge Status LED USB Type-C® Input with PD 2.0 Protocol Includes 20V 65W USB PD AC Adapter Specifications: Nominal Charge Voltage: 8.4V;16.8V ... -
Page 6: Li-Ion Battery Packs
Li-Ion Battery Packs The battery packs are equipped with built- in safety/protection features. Should these features be compromised in any way what so ever, the battery pack may leak corrosive chemicals, overheat, emit smoke, burst and/ or ignite. Danger 1. Do not disassemble or modify the battery pack. 2. -
Page 7: Setup And Operation
Warning 1. Do not use the battery pack for other purposes other than those specified. Otherwise, its guaranteed performance will be lost and/or its service life will be shortened. 2. If recharging operation fails to complete even when a specified recharging time has elapsed, immediately stop further recharging. - Page 8 Charging Battery Packs with CMDUAL-PD Danger 1. The charger is intended for specific Li-Ion batteries only. Do not use with other battery chemistries or with incompatible battery mounts. Warning 1. Do not use Turbo mode on battery packs of 2600mAh or less. 2.
- Page 9 2. Set-up and Operation 1. Attach desired plates to the slots ensuring correct mating and locking of plate in its slot. You may use any two different charging plate models at the same time. 2. Attach USB Type-C power adapter to the rear port. 3.
- Page 10 Storage The battery should be stored in a dry place at normal temperatures, ideally below 25 C and not above 60 C (recommended 0 C to 20 The battery is a perishable item, more attention and care need to be used: It is recommended to charge the battery after each use.
-
Page 11: Warranty Information
Warranty Information BLUESHAPE PowerPacks and PowerPack chargers are warranted to be free from defects in materials, workmanship and functionality for a period of 12 months commencing from the date of purchase. This warranty shall not apply to any products or parts of, that have been subjected to misuse, negligence or damage.
