OPERATION MANUAL and INSTALLATION INSTRUCTIONS for
IntelliCon ®
- RU
COMMERCIAL REFRIGERATION ENERGY ECONOMIZER
Description
®
The IntelliCon -RU is a patented microprocessor-based energy-
saving device for commercial refrigeration systems.
®
IntelliCon reduces electric consumption and lowers compressor
run-time by actively managing the compressor cycling pattern, in
conjunction with the existing compressor controls. Note that the
®
IntelliCon can not cause the compressor to run when the controls
are not calling for cooling.
compressor protection by eliminating compressor short-cycling.
This unit is compatible with Intellidyne's Remote Display Unit
(model RDU). In addition to Status, the RDU will also indicate total
compressor run-time and economizer time.
Electric Ratings
Power Input: 24, 115, 220 VAC ± 10%, 5 Watts Max., 50/60Hz
Control Circuit Input: 24,115,220 VAC ± 10%, 0.1A Max. Burden
Relay Contact: Form B, 10A @ 220 VAC
Environmental Conditions
Indoor Use
Maximum Altitude (2000M)
Rated Ambient Temperature 32 - 120˚F. (0 - 49˚C.)
Maximum Rh 90% non-condensing
Mains Supply Voltage Fluctuations ± 10%
Transient Overvoltage Category (III)
Pollution Degree (2)
Operation
After installation, setting the slide switch on the top of the unit to
the 'ON' position activates the device. The lights on the front panel
indicate the state of operation of the device and will sequence as
the device goes through its operating cycle. Each light indicates
one of the possible modes of operation, which are:
STANDBY MODE:
shut off the compressor after cooling the space to the desired
temperature. The IntelliCon
compressor to start. This occurs for a period of time after the
compressor has shut down.
ECONOMIZING:
The refrigeration unit's compressor control has
requested the compressor to start but the IntelliCon
intervened to delay the start based on information it has gathered
from the previous run cycle.
COMPRESSOR ON:
ANTI-SHORT-CYCLE:
feature of the device, which ensures at least a thirty-second delay
between compressor starts. This light will illuminate whenever the
compressor has been turned off and will remain on for the thirty-
second protection period. The compressor can not be enabled
while this light is lit.
During normal operation, the top three lights will cycle from one
state to the next and the anti-short-cycle light will come on for
thirty-seconds after the compressor is stopped.
Installation
®
The IntelliCon -RU is electrically installed in series with the
refrigeration unit's compressor control as shown in the wiring
diagrams on the reverse side. Check and determine the voltages
of the compressor control circuit and power circuit prior to
installation. FOR SAFETY, POWER TO THE UNIT MUST BE
DISCONNECTED DURING INSTALLATION.
Positioning
The unit must be protected from the elements and may be
mounted on the equipment either vertically or horizontally. The unit
should be mounted directly on the existing electric enclosure via
the unit's standard ½" electrical fitting or within the enclosure using
an accessory mounting bracket. For mounting in the elements, a
rain-tight mounting enclosure is available.
Wiring
All wiring and connections must comply with Local and
National Electrical Codes. The unit should be wired as shown
in the wiring diagrams on the reverse side. It is important to
read all of the instructions carefully. Ensure that POWER TO
Intellidyne LLC • 5507 Nesconset HWY STE10 PMB148 • Mount Sinai, NY 11766, USA • Email customercare@intellidyne.green
®
The IntelliCon -RU enhances
The refrigeration unit's control system has
®
-RU is waiting for the next call for the
®
The compressor is enabled.
This is an added compressor protection
THE UNIT IS OFF DURING INSTALLATION and that all unused
leads are individually taped/insulated.
The
Checkout
Recheck wiring one last time. Set the IntelliCon
to 'Off/Bypass' and restore power to the compressor. Set the slide
switch to 'On'. First, as part of the system check, all four (4) lights
®
on the IntelliCon -RU will be briefly lit and then go out. Next,
either the 'STANDBY MODE', or the 'ECONOMIZING' light will
activate depending upon the operating state of the refrigeration
unit controls. The 'ANTI-SHORT-CYCLE' light will come on and
remain on for thirty-seconds.
After the thirty-second interval, the 'ANTI-SHORT-CYCLE' light will
go out. Next, if the 'ECONOMIZER' light is lit, after a short delay
the 'COMPRESSOR ON' light will light and the compressor should
start. If this happens, the installation is complete.
®
If the IntelliCon -RU remains in the 'STANDBY MODE' after the
'ANTI-SHORT-CYCLE' light goes out, it will be necessary to
simulate a cooling call to verify proper operation. Note the control
thermostat or pressuretrol setting and force a compressor call by
temporarily resetting the control. Verify that the IntelliCon
has changed
'COMPRESSOR ON'.
normally. Make sure to return the compressor control to its'
previous setting.
'STANDBY MODE' when the unit's control is calling for the
compressor to run, the unit is probably miswired; see the WIRING
NOTE below.
Service and Troubleshooting
After Installation and Checkout, the IntelliCon
maintenance and will provide years of trouble free operation.
The unit may be bypassed at any time by putting the slide switch
to the 'Off/Bypass' position. In this position, the unit has no effect
on the system and the compressor will function as it did prior to the
®
IntelliCon -RU installation.
diagnose problems without the IntelliCon
IMPORTANT - READ CAREFULLY
1. Failure to
-RU has
damage to the system or cause a hazardous condition.
2. Installer must be experienced, qualified, and in certain
locations, licensed to work on the system that this
control is being installed on.
3. After installation
out procedure as provided in these instructions
confirm proper system operation .
4. Intellidyne is not responsible for improper installation or
any damages that may result from improper installation.
5. Actual wiring may differ from that shown in the diagrams.
6. Equipment may have controls not shown.
7. Because the IntelliCon can operate with different voltages
for the power and control circuits, it has separate
common wires for these circuits.
these wires are connected to the proper commons or the
unit will not function properly. See the wiring diagrams
on the reverse side of this sheet for details.
IMPROPER VOLTAGE SELECTION MAY DAMAGE
THE UNIT AND VOID THE WARRANTY.
Form RU2500rev14.0
®
-RU slide switch
This is normal during power-up.
modes to either 'ECONOMIZING'
This indicates the unit is operating
®
If the IntelliCon -RU does not come out of
®
-RU requires no
This allows service personnel to
®
-RU interfering.
follow these instructions may result
is complete, follow
It is necessary that
®
-RU
or
in
the check-
to
