TABLE OF FIGURES ..................V LEGAL NOTICE AND WARRANTY ..............VI CONTACT INFORMATION ................. VII SAFETY INSTRUCTIONS................VIII REVISION HISTORY..................X ABOUT THIS DOCUMENT................XI INTRODUCTION ................13 ASIS S ............13 VERVIEW OF HELF RODUCTS ™ S ATCA AC S ..........
Page 3
Table of Contents 2.2.2 Fan Tray Design ................27 2.2.3 Performance ................28 2.2.4 Fan Speed ................... 28 2.2.5 RTM for the Shelf managers............28 INSTALLING THE SHELF ..............29 .................. 29 HELF OWER .................. 29 OOLS EQUIRED ..................30 LANNING ..............
Page 4
Table of Contents ................. 42 ROUBLESHOOTING SYSTEM SPECIFICATIONS .............. 43 ..................43 ERTIFICATION ................... 43 ECHNICAL ............... 46 CRONYMS SED IN THIS ANUAL Five-Slot AC Revision 1.0.0...
Table of Figures Table of Figures 1 – S ................15 IGURE HELF LOCK IAGRAM 2 – S .................. 15 IGURE HELF RONT 3 – S ..................16 IGURE HELF 4 – S ............. 16 IGURE HELF HASSIS WITH ABLE OLDERS 5 - S ..............
3 Galgalei Haplada St. Kfar Saba, ISRAEL 44422 Telephone: +972-73-233-6633 Fax: +972-73-233-6634 sales@asis-pro.com E-mail: North America Headquarters 11067 Caminito Arcada San Diego, CA, 92131 USA Telephone: 858 776-1421 salesna@asis-pro.com E-mail: See the ASIS web site at http://www.asis-pro.com Five-Slot AC Revision 1.0.0...
Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. ASIS strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment.
Page 9
Safety Instructions When transporting a sensitive component, first place it in an antistatic container or packaging. Handle all sensitive components at an ESD workstation. If possible, use antistatic floor pads and workbench pads. Handle components and boards with care. Don’t touch the components or contacts on a board.
Related Documents For information on the Shelf Manager, see the ASIS Shelf Manager Board user manual. Instructions relating to software installation and documentation for application software development for this platform are available in the Shelf Manager External Interface Reference Manual.
Page 12
About this Document Style Conventions Verdana Regular text. Arial Bold Commands, keys and other parts of the user interface. Names of classes, methods, arguments, exceptions, properties, etc. Arial Italics Also used for special terms, the first time they appear. Monospace Text displayed on the LCD or on a computer attached to the product.
Introduction Overview of ASIS Shelf Products 1 Introduction This chapter includes a summary of the Asis shelf product line and a brief overview of the Perform™ Series 5-Slot ATCA AC Shelf. For acronyms used in this document see Section 5.3.
Understanding the Shelf Components Platform Components 2 Understanding the Shelf Components This chapter summarizes the functional features of the Perform™ Series 5-Slot ATCA AC Shelf, and describes in further detail each of the components as well as the shelf system cooling mechanism.
Platform Components Figure 5 - Shelf Component Positioning In order to increase ASIS 5 slot ATCA AC Shelf reliability and to simplify the shelf’s format, only one of the boards installed in the Shelf has logic circuits in it. All other boards and FRU’s are passive.
Understanding the Shelf Components Platform Components Backplane 2.1.3 Features The ATCA PICMG 3.0-compliant backplane provides interconnectivity between the FRU's and card connectivity. It conforms to the PICMG 3.0 R2.0 AdvancedTCA Base Specification. Backplane features include: Five slots Fabric interface with full mesh interconnect. The Fabric Interface grid consists of eight differential pairs per channel;...
Understanding the Shelf Components Platform Components the Base, Fabric, and update-channel interface. This portion supports a full- mesh topology for both the Base and the Fabric interfaces. Update-Channel Connections The update channels are backplane connections between pairs of modules that operate on a redundant basis.
Understanding the Shelf Components Platform Components Synchronization Clock Interface The backplane supports a set of synchronization clock buses that can exchange synchronization timing information. This synchronization can be used for system-wide and intersystem synchronization purposes, which are important in some applications, such as those involving synchronous time division multiplex (TDM).
The field replaceable and hot swappable, 90 VAC to 240 VAC, power supplies are providing power to the shelf. The ASIS 5 slot ATCA AC Shelf is equipped with AC power inlets which are located in the rear for redundancy.
Understanding the Shelf Components Platform Components Each power supply is capable of supplying 1200w. One power supply is fully capable of supplying the power consumed by a fully occupied shelf. The use of the second power supply is for cases where redundancy is needed. Both power supplies are located in the lower part of the shelf.
Understanding the Shelf Components Platform Components Figure 12 – Power Supply Distribution of Power on Shelf Grounding Requirements and Power Input When connecting ground and power cables to the shelf, follow instructions in the beginning of this document. Fan Tray 2.1.6 The fan tray is a closed module containing eight 80x80mm fans that supply air volume and velocity for cooling the high-density/high-performance computing environment (see...
Understanding the Shelf Components Platform Components It is recommended to replace the fan tray as soon as possible. The fan tray is factory-mounted in the Perform™ Series 5-Slot ATCA AC Shelf. It is easily replaceable, and can be replaced while the shelf is operating. For more on shelf cooling, see Section 2.2.
Compliance with ATCA's temperature specifications requires a steady air flow in the shelf. To insure a steady air flow, either the Perform™ Series 5-Slot ATCA AC Shelf must be fully populated, or a blank panel, available from ASIS, must be equipped to fill every empty slot.
Understanding the Shelf Components Platform Components If the saved configuration matches one of the E²PROMs it is assumed to be the right one and it is stored in both E²PROMs. If the three configurations are all different, the Shelf manager board will not boot up.
Understanding the Shelf Components Shelf Cooling Shelf Cooling Overview 2.2.1 Perform™ Series 5-Slot ATCA AC Shelf complies with all the cooling requirements specified in PICMG V3.x specifications. The cooling system consists of eight high-performance fans. The air comes in from the right side and exits through the left side of the shelf.
Understanding the Shelf Components Shelf Cooling Performance 2.2.3 The eight fans supply air volume and velocity for cooling the high-density/high- performance computing environment. The cooling power of the fans can dissipate the heat generated by up to five front boards and complementary RTMs. At least 300W per front board and 30W for RTM per slot is supported.
Installing the Shelf Shelf Power-Up 3 Installing the Shelf This chapter provides you with instructions on how to prepare the Perform™ Series 5-Slot ATCA AC Shelf for use. You will be performing some or all of the following setup tasks: Site Planning Checking Package Contents Rack Mounting...
Installing the Shelf Site Planning Site Planning Only qualified personnel should be involved with this installation procedure. The Perform™ Series 5-Slot ATCA AC Shelf can be installed either on a standard 19" rack or as a desk-top unit. All sides of the shelf should be easily accessible. The prerequisites for setting up the Perform™...
Installing the Shelf Installation Steps Installation Steps The following overall procedure is described more in detail in the sections below. This operation should be maintained at lest by two personal. 1. Install the Cable-management tray holder (optional). Mount the shelf in the rack with four screws. 2.
Installing the Shelf Installer Grounding Installer Grounding Any person involved in handling the shelf or card installation or replacement is required to wear an ESD grounding device. One grounding sockets can be found on the shelf: An ESD grounding socket in the front of the shelf Figure 19 - Front ESD Socket Shelf Power-Up To power up the shelf:...
Installing the Shelf Shelf Third Party Application Card Insertion 3.10 Shelf Third Party Application Card Insertion Third-party application cards must be AdvancedTCA-compliant. Application cards should be inserted only after the installation, power-up and testing procedures of the Perform™ Series 5-Slot ATCA AC Shelf have been completed. Insert application cards according to the manufacturer's instructions, making sure they are properly-positioned in their slots and are secured to their respective connectors.
Maintenance And Troubleshooting Performing Periodic Maintenance 4 Maintenance And Troubleshooting This chapter includes instructions regarding: Performing Periodic Maintenance Figure 20 – Shelf Air filter and Power supply air filter extraction Handling Electromagnetic Interference Extracting Modules Handling Alarms Hot-Swapping FRUs Resetting The System Troubleshooting.
Maintenance And Troubleshooting Handling Electromagnetic Interference The air filter can be extracted without interrupting power. Release the two tumble screws on the front side of the air filter unit and extract the unit by pulling the two tumble screws. Figure 20 – Shelf Air filter and Power supply air filter extraction Handling Electromagnetic Interference The shelf emits electromagnetic waves that may interfere with nearby equipment.
Maintenance And Troubleshooting Extracting Modules Extracting Modules Third Party Board Extraction/Insertion 4.3.1 To extract an ATCA-compliant third party board: 1. Pull the board's insertion lever slightly. The de-activation sequence begins. 2. After the board's blue led lights steady, pull out the board's insertion lever. 3.
Maintenance And Troubleshooting Extracting Modules Power Supply Extraction 4.3.5 If Power Supply redundancy is implemented, one of the power supplies can be extracted without interfering the normal operation of the shelf. To extract PS: 1. Disconnect the power cables. 2. Release the two tumble screws on the front side of the power supply. 3.
Maintenance And Troubleshooting Extracting Modules Figure 21 – Extracting a Fan Tray 3. Insert the replaceable fan tray unit. 4. Push each of the two thumbscrews in and tighten. E²PROM Replacement 4.3.8 E²PROMs are generally installed and handled only in the factory. Follow the procedure below in the rare case that it becomes necessary to field replace the E²PROMs.
Maintenance And Troubleshooting Handling Alarms Handling Alarms Both visual indicators and software alarms are provided. Visual Alarms 4.4.1 Nine LEDs at the front of the Shelf manager card provide visual alarms. LED Functions: General LEDs Status Meaning Green Shelf manager is active Shelf manager failure Blink Shelf manager is inactive...
Maintenance And Troubleshooting Hot-Swapping FRUs Upon completion of boot-up, LEDs will display as follows: General LEDs Telco Alarm LEDs Application Defined LEDs return to normal state Remains ON Lights steady blue for a few seconds, then begins blinking, then goes off after a few blinks Software Alarms 4.4.2...
Maintenance And Troubleshooting Resetting The System To remove a module: 1. Partially open the module’s right ejector latch to activate the module’s hot-swap switch. The module’s IPMC sends to the Shelf Manager a request to deactivate, and the blue hot swap LED blinks at a fast rate. 2.
Maintenance And Troubleshooting Troubleshooting Troubleshooting The following table summarizes potential problems and recommended solutions. Problem Probable cause Solution Shelf Manager board does not boot up Shelf Manager board is Check that the Shelf Manager properly: not in fully inserted in board is properly inserted in the the cage.
System Specifications Certification 5 System Specifications This chapter documents the product’s standards certification, and physical and other technical specification parameters. Certification The Perform™ Series 5-Slot ATCA AC Shelf is targeted for NEBS level-3, FCC, UL and CE certification. It complies with the following standards: Advanced TCA, PICMG 3.x IPMI v 1.5.
Page 44
System Specifications Technical Data Description/ Category Property Value Accessibility Shelf Manager, Fan Tray, Front boards, Air Filter Tray, Front Power Supplies Rear RTMs Backplane Up to five third-party ATCA-compliant front boards, full mesh, dual redundant Shelf Managerboards, Bus architecture bussed IPMB (radial by request). Signal bandwidth rating Supports up to 5Gbps per differential pair.
Page 45
System Specifications Technical Data Description/ Category Property Value Cooling Front hot-pluggable fan tray with 8, N+1, axial fans for Number of fans front and RTM slots Redundancy N+1 (i.e., any one fan can fail with no service degradation) Fan speed Variable speed under shelf manager board controll Up to 300 Watt per front board, Cooling capacity...
System Specifications Acronyms Used in this Manual Acronyms Used in this Manual Acronym Meaning ATCA Advanced Telecom Computing Architecture Field-Replaceable Unit Hot swap IPMB Intelligent Platform-Management Bus IPMI Intelligent Platform-Management Interface Rear Transmission Module NEBS Network Equipment-Building Systems Shelf Manager Shelf Manager board ETSI European Telecommunications Standards Institute...
