- Page 1 Cobalt Digital Inc. 8310(-C) (10-Slot) 8321(-C) (20-Slot) openGear 2RU Frame and Power Supply (PS-8300) User Manual 8310/8321-UM Version: 1.0...
- Page 2 The material in this manual is furnished for informational use only. It is subject to change without notice and should not be construed as a commitment by Cobalt Digital Inc. Cobalt Digital Inc. assumes no responsibility or liability for errors or inaccuracies that may appear in this manual.
- Page 3 Important Regulatory and Safety Notices Before using this product and any associated equipment, refer to the “Important Safety Instructions” listed below so as to avoid personal injury and to prevent product damage. Products may require specific equipment, and /or installation procedures be carried out to satisfy certain regulatory compliance requirements.
-
Page 4: Important Safety Instructions
Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. The safe operation of this product requires that a protective earth connection be provided. A grounding conductor in the equipment's supply cord provides this protective earth. To reduce the risk of electrical shock to the operator and service personnel, this ground conductor must be connected to an earthed ground. - Page 5 Product Power Cord Requirements North American Line Voltages 100 - 120 Volts This product is supplied with certified 10A/125V SVT type supply cords. Conductors are color coded white (neutral), black (line) and green or green/yellow Warning (ground). Operation of this equipment at line voltages exceeding 130V requires that alternative supply cords with appropriate voltage and current ratings be used International Line Voltages 200 - 240 Volts This product has been designed for use with certified IEC 320- C13 10A/250V - H03...
- Page 6 Maintenance/User Serviceable Parts Routine maintenance to this Cobalt Digital Inc. product is not required. This product contains no user serviceable parts. If the frame does not appear to be working properly, please contact Technical Support using the numbers listed under the “Contact Us” section on the last page of this manual. All Cobalt Digital Inc.
-
Page 7: Table Of Contents
Contents Introduction In This Chapter .......................... 9 A Word of Thanks ....................... 9 Overview ........................9 Features ........................10 Documentation Terms ....................11 Installation and Setup In This Chapter ........................12 Static Discharge......................12 Unpacking........................13 Installing the Frame ....................14 Power Supply PS-8300 and Power Cable.............. - Page 8 Frame Controller Alarm Mute/Bootload Button............43 Warranty and Repair Policy..................45 Ordering Information In This Chapter ........................46 Contact Us Contact Cobalt Digital Inc.......................48 Visit us at the Cobalt Digital Inc. website................48 8310/8321 User Manual • • • • (V 1.0) Page 8...
-
Page 9: Introduction
Should you have questions or concerns pertaining to the installation or operation of your frame, please contact Cobalt Digital Inc. (Contact information is supplied on the back cover of this manual.) Our technical staff is always available for consultation, training, or service. -
Page 10: Features
For applications where other types of I/O connections are necessary (such as twisted-pair audio or fiber interfaces), the frame also supports slot-dependent rear modules. Rear modules can be ordered with cards, and are easy and quick to install. Robust Power Supplies The 8310 frame can accommodate two front-loaded PS-8300 power supplies. -
Page 11: Documentation Terms
• Aluminum construction reduces overall weight • Two independent looping Reference Inputs feed all card slots • SMPTE alarm interface for simple monitoring • Ethernet port for optional networked control • Robust 150 Watt Power Supply with integral cooling fan •... -
Page 12: Installation And Setup
Installation and Setup In This Chapter This chapter contains the following sections: • Static Discharge • Unpacking • Installing the Frame • Power Supply PS-8300 and Power Cable • Fault Reporting • Improving Performance • Ventilation and Cooling • Cable Connections •... -
Page 13: Unpacking
Static discharge can cause serious damage to sensitive semiconductor devices. Avoid handling circuit boards in high static environments such as carpeted areas, and when wearing synthetic fiber clothing. Always exercise proper grounding Susceptibility precautions when working on circuit boards and related equipment. -
Page 14: Installing The Frame
Installing the Frame The frame frame mounts in the rack frame by means of four rack screws fastened through the front mounting flanges. This should normally be sufficient to carry the load, including the weight of accompanying cables. However, in certain applications such as mobile truck installations, it may be desirable to also support the rear of the frame. -
Page 15: Fault Reporting
Note In case of a power supply failure, contact your openGear dealer. The PS-8300 is a power factor corrected supply, capable of working with all world AC standards (100-240V). The supply has an indicator LED on the front, and an error detection circuit that will indicate the conditions described in Table 1. -
Page 16: Cable Connections
For reliable performance, it is recommended that the frame door not be opened for longer than 5 minutes when using the Cooling Fan Module option on frames loaded with more than 40 Watt. Notice Without Fan Kit: Fan Kit Installed: 8310-C Max. -
Page 17: Rear I/O Modules
Each AC connector includes a Powerlock, which is designed to retain the power cable connector. Clip the Powerlock over the shoulder of the inserted AC cable end. Note — In some countries, it may be necessary to supply the correct mains supply cord. Use only an approved IEC 320 C-13 type A/C line cord rated for a minimum 10A at 250V and Warning certified for the country of use. - Page 18 Rear I/O Module Installation If you are installing an openGear card in a 8310-C-BNC or 8310-BNC frame, skip this section. If you received a custom rear I/O module for your openGear card, you will need to install the I/O module in your 8310 frame before you can connect cables. Use the following procedure to install the DFR-RM-82xx in the 8310 digital distribution frame: Ensure that the frame is properly installed according to instructions in the section “Installing the Frame”...
- Page 19 openBUS Connector This RJ45 connector is used to exchange information data from cards installed in the 8310 frame to an external monitoring/control system. Only cards having the openBUS interface will be able to be monitored and controlled this way. This is reserved for future use with openGear products.
-
Page 20: Smpte 269M Fault Reporting Option
SMPTE 269M Fault Reporting Option In This Chapter This chapter contains the following sections: • Overview • Frame Connections • Details Overview The SMPTE 269M Fault Reporting system, also known as a SMPTE “alarm,” provides an indication if one or more frame cards encounter a fault or an abnormal condition. This option is available when a Network Controller Card is installed in the Frame Controller Slot. -
Page 21: Frame Connections
Frame Connections The SMPTE 269M Fault Reporting connection on openGear 8310 series frames is provided by the FAULT BNC connector, for interfacing with a customer-designed alarm system. SMPTE Fault BNC Figure 8. SMPTE 269M Alarm Reporting Frame Connections Details The fault report contacts are closed when the card detects an internal failure or a power loss condition. The fault report contacts are closed for about 2 milliseconds every 16 ms to report any error for which SMPTE fault reporting has been enabled. -
Page 22: Specifications
-7.5V, ± 10%, 0A - 2.5A Power Supply Sum of both outputs not to exceed 150 Watt Total maximum For safety reasons, Cobalt Digital Inc. power supplies do not fit into rack frames of other manufacturers. Height 3.5" (90mm) Width 19" (483mm) - Page 23 Category Parameter Specification Level 1Vpp nominal Analog video sync (black burst or tri-level), or Signal AES/EBU DARS Impedance 75Ω terminating Return Loss >30dB to 30MHz Max DC on Ref Input ±1V Alarm Indicator ANSI/SMPTE 269M-1999 contact closure Connector Female BNC Max Voltage 24V DC Max Current...
-
Page 24: Important Notes
Important Notes: The power dissipation of each product installed in this frame is indicated in the Specifications section of the documentation provided with each module. For long-term reliability and increased product life, it is recommended that the total dissipation of all modules installed in a 8310 frame should not exceed 40 Watt total without the CFM-8310, and 120 Watt total with the CFM-8310. -
Page 25: Frame Features
Frame Features In This Chapter This chapter contains the following sections: • Cooling Features Installing the Cooling Fan Module Cooling Fan Functions and User Controls Installing the Controller Card Functions of the Controller Card Controls and LEDs of the Controller Card •... -
Page 26: Cooling Features
Cooling Features The standard 8310 frame can be also be ordered as the 8310-C version, with the Cooling Fan Module installed as original equipment from the factory. However, for customers wishing to increase the ventilation on their standard 8310 frames, the optional CFM-8310 Cooling Fan Module is available as a field upgrade kit. -
Page 27: Cooling Fan Functions And User Controls
Open the CFM-8310 package and remove the components. Verify that all necessary components are included. • Fan PCB 8310A-016 • Fan Filter S985-006 • 8 nuts 650-007 • 8 washers 960-025 • MFC-8310(-N) Frame Controller Card Turn frame power off. Open the frame door. -
Page 28: Installing The Controller Card
Next you will install either an MFC-8310 or an MFC-8310-N controller card. Refer to the appropriate section for installation instructions for your specific controller card. Installing the Controller Card Use the following procedure to install the MFC-8310 controller card component of the CFM-8310: Figure 11. -
Page 29: Controls And Leds For The Controller Card
seconds after the fan door is closed, then adjust to the appropriate level based on power consumption. • Monitors the frame door and PS-8300(s) to ensure that fans in all units are operating correctly. • Monitors the fan door and notifies the user if it is left open too long. •... - Page 30 LED displays and descriptions are provided in the following table: Table 3. MFC-8310 Controller Card LED Descriptions Color Display and Description Alarm When lit, an alarm condition is occurring in the frame. (MFC-8310) Status OK Green When lit, the MFC-8310 module is operating correctly. (MFC-8310) Comm.
-
Page 31: Remote Control Networking Features
Remote Control Networking Features This section includes instructions for installing the MFC-8310-N controller card for the CFM-8310 module. Note: ® Refer to Cobalt reference guide COMPASS™ Remote Control User Guide” (PN 9000RCS-RM) for thorough information and step-by-step instructions for setting up network remote control of COMPASS™... -
Page 32: Functions Of The Network Controller Card
This completes the procedure to configure the network settings for the MFC-8310-N controller card. Functions of the Network Controller Card The MFC-8310-N controller card component of the CFM-8310 performs several functions: • Monitors frame power usage and sets the fan speed accordingly (higher power consumption requires higher fan speed for adequate cooling). - Page 33 Alarm Mute Button Fan Board Connector Edge Figure 14. MFC-8310-N Card Edge Controls DIP Switches on the MFC-8310-N The following DIP Switches are located on the MFC-8310-N controller card. DIP_1 Switch DIP_1 switch disables the audio alarm signal as follows: •...
- Page 34 Reset Button This button is used to restart both of the onboard processors: the fan control processor and the communications processor. The communications processor requires approximately 30 seconds to restart and re-establish network communications. MFC-8310-N LEDs The front edge of the MFC-8310-N, and the CFM-8310 in the frame door, have LED indicators for cooling module fan, alarm, and communication activity.
-
Page 35: Dashboard And Dashboard Lite Control System Software
You can use the DashBoard or DashBoard Lite Control Systems to monitor and control your openGear frames and controller cards from a computer. The DashBoard software and manual can be downloaded from the Cobalt Digital Inc. website. SNMP Monitoring and Control The MFC-8310-N Network Controller card provides optional support for remote monitoring and... - Page 36 Enabling SNMP You must obtain a license key from Cobalt Digital Inc. to enable SNMP support. Use the following procedure to obtain your license key: Request a license key from your distributor or at sales@cobaltdigital.com, quoting the 8-character hardware-ID provided on the page.
-
Page 37: Rear Support Bars And Brackets
Rear Support Bars and Brackets Under normal conditions, mounting the frame to the front of the rack with four rack screws should be sufficient to carry the load, including the weight of accompanying cables. The optional FSB-8310 Rear Support Bars and Brackets are specifically engineered to compensate for extra load stress associated with certain applications, such as mobile truck installations, to also support the rear of the frame. - Page 38 8321 20-Slot Frame Setup In This Chapter This chapter provides information on setting up and using the 8321 series frame. The 8321 is a 2RU modular frame, designed to accommodate up to 20 openGear cards and support up to 10 high-density openGear fiber cards.
- Page 39 Rear Modules for the 8321 Series Frames If your 8321 series frame was ordered with cards requiring Full Rear Modules or Split Rear Modules, the appropriate modules are installed at the factory or included with the cards. Blank Rear Modules (R2-BLANK) are installed when the slot does not have an openGear card installed.
- Page 40 Split Rear Module This module features two card connectors and can include up to 10 BNCs, or a combination of BNC, AES, and fiber optic connectors. Each card connector is routed to a column of five BNCs. This module can only be used in a 8321 series frame. A Split Rear Module occupies two slots in the frame but provides connectors for two openGear cards.
- Page 41 Cooling Features The 8321 series frames come standard with the Cooling Fan Module installed as original equipment from the factory. However, if you need to replace the ventilation in a 8321 series frame door, the optional CFM-8321 Cooling Fan Module is available as a field installation kit. Cooling Fan Functions and User Controls The 8321 series frames includes Fault LEDs and the Alarm mute button on the front of the frame door.
- Page 42 Specifications for the 8321 Series Frames This section includes the Technical Specifications table for the 8321 series frame. Table 4.5 8321 Series Frame Technical Specifications Category Parameter Specification Input 100-240VAC, 47-63Hz, 190W Output 1 +12V, ± 10%, 0.5A - 12.5A PS-8300 Power Supply Output 2...
-
Page 43: Service Information
Frame Controller Alarm Mute/Bootload Button In the unlikely event of a complete card failure, you may be instructed by a Cobalt Digital Inc. Technical Support specialist to perform a complete software reload on the MFC-8310 frame controller card. - Page 44 Use the following procedure to reload the software: Eject the card. Press and hold the Alarm Mute/Bootload button, while re-inserting the card into the frame. Release the button. The STATUS OK LED will flash GREEN while the card is waiting for a new software load. If a new software load is not sent to the card within 60 seconds, the card will attempt to restart with it's last operational software load.
-
Page 45: Warranty And Repair Policy
(1) year. Cobalt Digital Inc.'s (“Cobalt”) sole obligation under this warranty shall be limited to, at its option, (i) the repair or (ii) replacement of the product, and the determination of whether a defect is covered under this limited warranty shall be made at the sole discretion of Cobalt. -
Page 46: Ordering Information
Ordering Information In This Chapter Your 8310 openGear Two Rack Unit Frame and Power Supply (PS-8300) is a part of the openGear family of products. We offer a full line of openGear terminal equipment including distribution, conversion, monitoring, synchronizers, encoders, decoders, AES, keyers, control switches, as well as analog audio and video products. - Page 47 Notes: 8310/8321 User Manual • • • • (V 1.0) Page 47...
-
Page 48: Contact Us
E-MAIL Sales Information Sales@cobaltdigital.com 2406 East University Avenue POSTAL Cobalt Digital Inc. Urbana, IL 61802 USA SERVICE Visit us at the Cobalt Digital Inc. website. http://www.cobaltdigital.com/ • Online catalog • Related products and full product lines • Trade show information •...
