- Page 1 Service Guide M9010A, M9018B, M9019A Keysight PXIe Chassis Family...
- Page 3 WITHOUT NOTICE, IN FUTURE EDI- without prior agreement and written con- www.keysight.com/find/M9010A TIONS. FURTHER, TO THE MAXIMUM sent from Keysight Technologies, Inc. as EXTENT PERMITTED BY APPLICABLE www.keysight.com/find/M9018B governed by United States and interna- LAW, KEYSIGHT DISCLAIMS ALL WAR- tional copyright laws.
- Page 4 Any interruption of trained personnel. If necessary, return the protective (grounding) conductor Operator is responsible to maintain the product to a Keysight Technologies or disconnection of the protective safe operating conditions. To ensure Sales and Service Office for service and...
- Page 5 Safety and Regulatory Symbols A CAUTION denotes a hazard. It calls attention to an operating pro- The CSA mark is a registered trade- cedure or practice that, if not cor- mark of the Canadian Standards Asso- MSIP-REM-Kst-xxxxxxx rectly performed or adhered to, ciation and indicates compliance to could result in damage to the South Korean Class A EMC Declara-...
-
Page 7: Table Of Contents
Contents 1 PXIe Chassis Replacement About the Chassis Family......... . 10 Static-safe Handling Procedures . - Page 8 Keysight PXIe Chassis Family Service Guide...
-
Page 9: Pxie Chassis Replacement
Keysight provides three PXIe chassis in the PXIe Chassis Family: - M9010A – a 10-Slot PXI 24 GB/s, Gen 3 chassis - M9018B – an 18-Slot PXI 8 GB/s, Gen 2 chassis - M9019A – an 18-Slot PXI 24 GB/s, Gen 3 chassis There is no replacement of the chassis fan or power supply assemblies at this time. -
Page 10: About The Chassis Family
PXIe chassis and other, non-PXI instrumentation. The Keysight PXIe chassis have these key features: – Up to 16 PXIe hybrid slots (the M9010A has 8 hybrid slots), 1 PXIe timing slot, and 1 PXIe system slot. – 4U chassis with innovative cooling design. -
Page 11: Static-Safe Handling Procedures
About the Chassis Family PXIe Chassis Replacement Static-safe Handling Procedures Electrostatic discharge (ESD) can damage or destroy electronic components. Use a static-safe work station to perform at work on electronic assemblies. The figure shows a static-safe work station using two types of ESD protection: - Conductive table-mat and wrist-strap combination... -
Page 12: Replacing The Chassis Core Assembly
PXIe Chassis Replacement Replacing the Chassis Core Assembly Replacing the Chassis Core Assembly If the Keysight M9010A, M9018B, or M9019A PXIe chassis fails and must be replaced, follow the instructions given below. Order a Replacement Core Assembly 1 Contact Keysight (see www.keysight.com/find/assist). -
Page 13: Replacing The Defective Core Assembly
Remove and retain Serial Number Plate screws Figure 1 PXIe Chassis Family Serial Number Plate (M9010A Rear Panel shown) 3 Remove the Serial Number plate from the defective chassis. a Using a Torx T8 screwdriver, remove the two screws that secure the plate to the chassis. - Page 14 PXIe Chassis Replacement Replacing the Chassis Core Assembly Serial Number Update The following steps describe how to update the chassis serial number. Note that Keysight does not require the serial number to be updated for your replacement hardware to work. This capability is provided if you need to maintain the same serial number to meet regulatory, governmental, track Keysight warranty on the unit, or other requirements.
- Page 15 -- Name and address of owner. A P.O. box is not acceptable as a return address. -- Product model number (for example, M9010A). -- Product serial number. The serial number plate is located on the rear panel of the chassis.
- Page 16 PXIe Chassis Replacement Replacing the Chassis Core Assembly On the shipping label, write ATTENTION REPAIR DEPARTMENT and the RMA number. Reprogramming the chassis serial number causes the host name to change. Keysight Connection Expert will no longer find the old host name.
- Page 18 This information is subject to change without notice. © Keysight Technologies, 2017 Printed in Malaysia Edition 1, March 2017 *M9019-90008* M9019-90008 www.keysight.com...
