- Page 1 DM50 HARDWARE MANUAL • DM50 INDUSTRIAL ROUTER IOT PROTOCOL GATEWAY...
-
Page 2: Table Of Contents
FIGURES LIST ..........................2 Preface ............................3 About Mikrodev ..........................4 WARNING! ............................5 DM50 GENERAL INFORMATION ................. 6 GE0 Board Type Physical Interfaces ............. 6 GE1 Board Type Physical Interfaces ............. 7 General Device Specifications ..............8 INSTALLATION INFORMATION................9 Rail Installation .................. -
Page 3: Figures List
Figure 4 Power Connection Diagram ................10 Figure 5 Digital Input Connection Diagram ...............11 Figure 6 Digital Output Connection Diagram .............12 Figure 7 RS485 Serial Port Connection Diagram ............13 Figure 8 RS232 Serial Port Connection Diagram ............14 DM50 SERIES – HARDWARE MANUAL... -
Page 4: Preface
Preface Mikrodev DM50 series industrial router iot protocol gateway can read and control Smart Electrical Devices (protection relays, reclosers, energy and quality analyzers, etc.) in the electrical sector with the industry standard protocols IEC 61850, MODBUS TCP and MODBUS RTU. TCP/IP connection settings are made over the product interface. It can also communicate with SCADA or control center software with IEC 60870, DNP3 and MODBUS TCP protocols. -
Page 5: About Mikrodev
MIKRODEV is one of the few companies in the world that has its own designed IEC 61131- 3 compliant library for its programmable logic control devices. In addition, the open, flexible, programmable SCADA solution developed by MIKRODEV is also available to customers. -
Page 6: Warning
✓ Make sure that the environment in which your device is being used is free of moisture, electric shock, vibration and dust. ✓ Pay attention to the supply voltage and the connections of the product. Mikrodev is not responsible for any issues due to power failure since there is no auxiliary supply (UPS) on the device. -
Page 7: Dm50 General Information
RS485 Port 2 Data Transfer LED CANBUS Connections WIFI Status LED System Error LED RS485 Port 1 Connections System Power LED RS485 Port 2 Connections USB Port RS485 Port 1 Data Transfer LED Ethernet Port GSM Connection Status LED DM50 SERIES – HARDWARE MANUAL... -
Page 8: Ge1 Board Type Physical Interfaces
CANBUS Connections System Error LED RS232 Connections System Power LED RS485 Port 1 Connections RS232 Data Transfer LED RS485 Port 2 Connections RS485 Port 1 Data Transfer LED USB Port GSM Connection Status LED Ethernet Port DM50 SERIES – HARDWARE MANUAL... -
Page 9: General Device Specifications
1 Port or 2 Port, 10/100 Mbps GSM/LTE* 4G/LTE WIFI* 1 Port 802.11 b/g/n 1 Port, USB Type C Din RAIL Type- Expansion CANBUS Expansion Up to 512 I/O Points Capacity Modules * Optionally selected. DM50 SERIES – HARDWARE MANUAL... -
Page 10: Installation Information
In the disassembly of the device, the flexibility of the spring located at the back of the device is used, light force is applied towards the rail, the lower part of the device is released from the DIN Rail and disassembly is completed. Figure 3 Mounting / Demounting DM50 SERIES – HARDWARE MANUAL... -
Page 11: Connection Diagrams
CONNECTION DIAGRAMS 3.1 Supply Connection Board Type: GE0, GE1 Supply: 24VDC (9-30 VDC), Protected Power: 300mA @ 24V DC Figure 4 Power Connection Diagram DM50 SERIES – HARDWARE MANUAL... -
Page 12: Digital Inputs
0-36V DC ON Voltage Level: 7-36V DC OFF Voltage Level: 0-6V DC Input Impedance: >2M Isolation: Optical OFF to ON Response: 20 us ON to OFF Response: 90 us Figure 5 Digital Input Connection Diagram DM50 SERIES – HARDWARE MANUAL... -
Page 13: Digital Outputs
3.3 Digital Outputs Board Type: GE0, GE1 Module Output: 2 Channel, Mosfet Output Module Output Type: PNP Transistor Voltage Range: 9-30V DC Max. Output Current: 1.5A @ 24V DC Isolation: Optical Figure 6 Digital Output Connection Diagram DM50 SERIES – HARDWARE MANUAL... -
Page 14: Rs485 Serial Port
Limited to Hardware ESD Protection, 8 kV Direct, 25 kV Air Isolation: Discharge Communication Distance: 1000 m Data Bits: Stop Bits: Parity: None-Even-Odd Baudrate: 300 bps to 200 kbps Figure 7 RS485 Serial Port Connection Diagram DM50 SERIES – HARDWARE MANUAL... -
Page 15: Rs232 Serial Port
3.5 RS232 Serial Port Board Type: RS485 Port Count: 1 Port Communication Distance: 10 m Data Bits: Stop Bits: Parity: None-Even-Odd Baudrate: 300 bps to 200 kbps Figure 8 RS232 Serial Port Connection Diagram DM50 SERIES – HARDWARE MANUAL...
