VALOI 360 Getting Started Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Getting
Started
Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the 360 and is the answer not in the manual?

Questions and answers

Summary of Contents for VALOI 360

  • Page 1 Getting Started Guide...
  • Page 3 Its two primary functions are to hold the film flat and to allow you to move quickly to the next frame when scanning. In addition to a VALOI 360 Holder you will also need the following to scan (not included): •...
  • Page 4 Content...
  • Page 5 Why Valoi? Online Guides The System’s Parts Assembly In Use General Tips For Scanning Diagnosing Common Problems Diagnosing Bad Scanning Results Contact...
  • Page 6 Why VALOI?
  • Page 7 In Finnish, “valoi” means light and creation - inseparable concepts of analogue photography The Finnish naming of our brand isn’t coincidental - as the Nordics is where our project started. Our Scandinavian roots are also visible in the minimalist, functional design.

  • Page 9: Online Guides

    Online Guides We have created a series of video guides to help you assemble and get started with your Valoi product, and with camera scanning. Please visit www.valoi.co and navigate to the ‘Guides’ section in the top right corner.
  • Page 10 The System’s Parts...
  • Page 11 The VALOI 360 system consists of the following modules: • Holders • 35mm Holder • 120 Holder • Custom Series Holders (see www.valoi.co) • Advancer • Accessories • Diffuser • Duster • Levelling Mirror • Light source Adapter 104 •...
  • Page 12 Holders...
  • Page 13 These can be used on their own (using the rubber feet) or in conjunction with the Advancer. *VALOI does not recommend disassembly of the Holders. The user is responsible for any damage to the product or themselves if they choose to disassemble the Holder.
  • Page 15 35mm Holder The 35mm Holder is intended for scanning standard 135 (35mm), both full (standard) frames of 24x36mm and half frame of 24x18mm. The Holder can both be used on its own or in conjunction with the Film Advancer (sold separately) for added functionality and higher quality scanning.
  • Page 17 120 Holder The 120 Holder can be used with any ~60mm gauge film type: 120 and the discontinued formats 220 and 620. It can be used effectively with any frame size from 6x4.5 to 6x9 with single-capture and with any size longer than that using digital stitching techniques.
  • Page 19 Feet: Threaded, adjustable in height for levelling The Advancer will allow you to increase productivity and quality when scanning. It is compatible with the holders in the 360 system and with all the accessories. Its adjustable rollers mean that most roll film formats ever produced are covered by the 6 pre-set grooves in the axles, including 35mm and 120 medium format.
  • Page 20 Accessories...
  • Page 21 In addition to the main parts of the system, there is also an ever-expand- ing range of accessories that works perfectly in conjunction with the Holders and Film Advancer: The Diffuser is used when your light source is not sufficiently diffused (evenly lit).
  • Page 22 Assembly...
  • Page 23 Holders. Repeatedly changing configuration between stand-alone with Advancer recommended removing and reattaching the rubber dome feet repeatedly will make them lose stickiness. Replacement feet are available from VALOI upon request - please email hello@valoi.co.
  • Page 25 Advancer All the parts for the VALOI 360 Advancer come in the box. have decided leave them unassembled safer transport and so you get to familiarise yourself with maintaining it. With the possibility to change rubber rollers easily, the Advancer should last a lifetime.
  • Page 27 Insert one axle into one of the axle holes on the Advancer frame, about halfway through. Before it reaches the opposite side, slip on two rollers and slide them a bit down the axle. Don’t feel the need to place them in the correct groove yet: this is easier once the unit is fullyassembled.
  • Page 29 Now secure each axle by slipping a knob on, rotating it while pushing in until the screwhole is right over the flat area on the axle. By screwing the screw in slightly first, then rotating the knob until it seats, you can tell where the flat area is.
  • Page 31 You have now fully assembled your VALOI 360 Film Advancer. See the instructions below on how to operate it using different holders.
  • Page 32 In Use...
  • Page 33 Currently, the VALOI 360 system can be used in two main configurations: The appropriate Holder can be used alone. The appropriate Holder can be used with the Film Advancer. The user also has to provide: A digital camera, a method of holding the camera in a fixed position (preferably a copy stand), and a flat uniform light source.
  • Page 35 See assembly instructions. Select the appropriate Holder and place it on your light source. Insert film in the direction shown, with the VALOI marking on the side you insert the film. While moving the film in the Holder we recom- mend pushing down on the holder lightly with one finger while mov- ing the film with the other to prevent the holder from moving.
  • Page 36 120 format 127 format 135 format Also used for the following formats: • • Super8 • 16mm • 110 format • •...
  • Page 37 Scanning using the Film Advancer To scan using the Film Advancer you will need the appropriate Holder for your desired format and the Film Advancer itself. Start by removing any Holder from the Film Advancer to get better access. Then move the rollers to the correct width for your format using both hands.
  • Page 39 Now place the Advancer on your light source and place the appropriate Holder in the Advancer. The VALOI Logo should be on the side opposite to the axles. Ensure that the film and camera are parallel by adjusting your copy stand or using the Advancer’s leveling feet.
  • Page 40 General Tips For Scanning...
  • Page 41 If scanning color film, always use a light source with a high Color Rendering Index (CRI) to get the best results - purchase our recommended light, the Raleno 104 with our Valoi Adapter 104, or see our Gear Guide for other recommendations.
  • Page 42 If your light source is larger than the Advancer or Holder you are using, mask off the extra area to minimise light spilling into the room. A sheet of cardboard or black foam board with a hole cut in the middle works well. Scan with a slight border outside the frame area.
  • Page 43 ISO settings, or automatic ISO. Convert color negatives using one of the software solutions detailed in our VALOI Gear Guide (found on our website). Color negatives are very hard to convert ‘by hand’ in an editing software, therefore investing in good conversion software is important to get good color results.
  • Page 44 Diagnosing Common Problems...
  • Page 45 Problem Solution The Film Holder lifts out of the This can happen if your film is very Advancer curly. Put a finger on the Holder when moving the film to press it down The film is getting stuck in the Make sure the film is emulsion-side holder when trying to push it down, not up.
  • Page 46 The knob falls off Tighten the screw at the end of the knob that attaches it The screw for the knob on the Tighten it with a screwdriver. Advancer falls out Please contact hello@valoi.co if this is a recurring problem.
  • Page 47 Problem Solution It is hard to move the rollers Pick up the Advancer and hold it against your body, then push the rollers towards you using both hands. Flip the Advancer around when moving them in the other direction so that you always push towards your body.
  • Page 48 Diagnosing Bad Scanning Results...
  • Page 49 (bigger F-num- ber), use a correction software such as that built into Lightroom or a plugin like Grain2Pixel. Change your lens for a different one (see the VALOI Gear Guide) Blurry results/lower resolution Shutter vibrations (mirrorless than expected...
  • Page 50 Problem Solution Blurry results/lower resolution Shutter vibrations (DSLR): Use than expected, continued mirror-lockup if your camera has it Lens: Change the lens for a mac- ro lens if using normal lens + extension tubes Focus: Check focus, use focus peaking and live view magnifica- tion, focus on the largest aperture of the lens and stop down before scanning...
  • Page 51 Make sure you follow the instruc- tions of the program/plugin you are using Test a different negative conver- sion program/plugin (see VALOI Gear Guide) Change your light source if using a cheap LED panel or other unsuit- able light source (see VALOI Gear Guide)
  • Page 52 Problem Solution Film is not flat Extremely curly film: Use a professional lab to develop Change your drying practices. Press the film under books for a few days Ensure that the film is seated properly in the holder Last resort: Use a smaller (big- ger number) aperture to get more depth of field (will lead to image...
  • Page 53 Align them perfectly by adjusting your copy stand or ad- justing the levelling feet on the Film Advancer (use Mirror Trick: see VALOI Technique Guide) Software failing to stitch images Too little overlap: Use more over- when doing several captures of...
  • Page 54 Contact...
  • Page 55 We are always here to help you! In case of any questions, please don’t hesitate to contact us. hello@valoi.co www.valoi.co Erkkilänkatu 11 A, PMK-talo, 7. krs 33100 Tampere, Finland Follow Facebook Instagram @valoi.co...
  • Page 56 Find us on www.valoi.co...
