- Page 1 User Manual: Ikelo - Optical Bodyscanner...
-
Page 2: Feedback
Custom8 NV. No patent liability is assumed with respect to the use of the information contained herein. Neither is any liability assumed for damages resulting from the use of the information contained herein. -
Page 3: Table Of Contents
2.2 Side contour measurement..................7 2.3. Back contour measurement..................7 3. Review the measurement....................8 3.1 Derived parameters....................8 3.2 Full contours......................9 Open a Previous Measurement....................10 Shut down the system......................10 Technical specifications......................11 Parts:..........................11 Technical data:.........................11 Environment:........................11 Maintenance:........................11 User Manual Ikelo (version 2.0.x, 30 okt 2019) 3/10... -
Page 4: Start The Software
Double-Click the software icon on the desktop and wait until the software starts up: In the top left corner, the user can choose between performing a measurement on a new client, or opening a previous measurement. User Manual Ikelo (version 2.0.x, 30 okt 2019) 4/10... -
Page 5: Perform A New Measurement
Fill in the customer name, the gender and the date of birth. There is also a memo field for additional information (optional): When ready, press ‘OK’. An empty screen will show, with 2 active buttons: Start a new measurement Cancel the operation (go back to main screen) User Manual Ikelo (version 2.0.x, 30 okt 2019) 5/10... -
Page 6: Perform The Measurement
90°, elbows against each other (as close as possible). Press ‘OK’ when ready… User Manual Ikelo (version 2.0.x, 30 okt 2019) 6/10... -
Page 7: Back Contour Measurement
After the image analysis, the results are available as an overview of the derived parameters, or as the full contours of the body. The user can switch from one view to the other by clicking on the corresponding buttons: Show the full contours Show the derived parameters User Manual Ikelo (version 2.0.x, 30 okt 2019) 7/10... -
Page 8: Derived Parameters
By moving the blue slider in the middle, the corresponding widths of the body in the frontal plane, and the depth with respect to the buttocks in the sagital plane can be obtained. User Manual Ikelo (version 2.0.x, 30 okt 2019) 8/10... -
Page 9: Open A Previous Measurement
Open a measurement by double clicking on the name, or by selecting and clicking on ‘OK’. HUT DOWN THE SYSTEM 1. Close down the software 2. Close down the PC 3. Switch the ON/OFF switch of the measuring device to the “OFF” position. User Manual Ikelo (version 2.0.x, 30 okt 2019) 9/10... -
Page 10: Technical Specifications
Do never execute maintenance out of your own decision. Follow all instructions for installation and maintenance stringent. To avoid electric shocks, do not connect or disconnect electric cables during thunderstorm and maintenance has to be postponed. User Manual Ikelo (version 2.0.x, 30 okt 2019) 10/10...
