NewBeeDrone AcroBee Lite Quick Start Manual

BOX CONTENTS:
• Carrying Case
• FPV Box Goggle
• AcroBee Container With Charger
• Radio
• AcroBee Lite
• 4 HV 4.35V 250mAh Nitro Nectar Batteries
• Micro USB Charging Cable
• 4 Spare Propellers
PRE-FLIGHT INSTRUCTIONS:
• Take out the AcroBee from AcroBee Container.
• Plug in USB and charge goggle screen and radio.
• Charge Nitro Nectar batteries with charging port
from AcroBee Container.
• Power on radio.
• Insert battery into AcroBee and plug in battery
lead.
CHARGING ACROBEE BATTERIES:
• Plug in micro USB power source to AcroBee Contain-
er to power charger.
• Insert Nitro Nectar batteries into charging port.
• Charger LED indicator lights are solid red when
charging & solid green when full.
• Always remove battery when indicator light is solid
green.
CHARGING GOGGLE & RADIO:
• When Radio & Goggle Screen are plugged into USB
cable with Data Link, LED will be solid red while
charging and turn solid green when charging is
complete.
• When Radio & Goggle Screen are plugged into USB
cable with power only, LED will be solid red while
charging, and turn off when charging is complete.
• Always remove charging cable when charging is
complete.
1 RADIO FUNCTIONS:
Turning On
Press the power button quickly two times. The radio
will play a start-up tone. The power button will light
up in yellow and the LED light below the power button
will display a solid green color.
Turning Off
Hold the power button for two seconds which will play
a power down tone and turn off all LED lights.
Binding Mode
2
Hold down the right trim button while powering up
the radio. The indicator green LED light will blink for
10 seconds while in bind mode until automatically
going back to normal mode and turning the LED solid
green again.
Flight Simulator
While the radio is powered on, hold down the right
trim button for 2 seconds and release. The LED will
turn solid blue indicating it is in flight simulator
mode. Radio must be connected to a computer via
micro USB cable to use.
3
GOGGLE SCREEN FUNCTIONS:
Channel Button
Push down once to scroll through different channel
numbers.
Frequency Button
Push down once to scroll through different frequency
bands.
Menu Button
Push down once to scroll through options of adjusting
the screen (Brightness, Contrast, Color, Zoom, Reset).
4
5
6
AcroBee Lite RTF Kit
