Summary of Contents for Healthy Networks LungPass Pro
- Page 1 Quick Start Guide Please read the full User Manual at lungpass.com/support.
- Page 2 LungPass Pro stethoscope 1. LED light - shows the stethoscope status 2. Control button - turns 3. Micro-USB port (covered the stethoscope on & off, by a protective flap) - for starts a recording charging the stethoscope...
- Page 3 Blinking blue Glowing blue Blinking white searching for a connection with the app audio recording / connection with the app established; ready for transmission in progress recording Blinking yellow Glowing green Glowing pink when charging: when charging: when updating charging in progress fully charged firmware: firmware mode activated...
- Page 4 Device First Use...
- Page 5 Step 1. Charge your LungPass Pro stethoscope Before using LungPass Pro for the first time, please charge the stethoscope for at least 30 minutes: 1. Connect the micro-USB cable provided in the box to the stethoscope’s micro-USB port (3). 2. Connect the micro-USB cable to a USB power source.
- Page 6 Step 2. Install the LungPass Pro app 1. Search for LungPass Pro in the Google Play Store or Apple App Store on a smartphone. 2. Download the app. 3. Open the app and create a new account.
- Page 7 Step 3. Complete a 5 min guide To ensure correct usage of LungPass Pro with your patients, please complete the quick interactive guide by yourself first: 1. You will see it in the app after creating an account. 2. It includes short videos on...
- Page 8 Device Regular Use...
- Page 9 Connecting the stethoscope to the app 1. In the app, start a lung exam by tapping on a respective button on the main screen. 2. You will be taken to a ‘Connect the device’ screen. 3. Press and hold the Control button (2) on the stethoscope for three seconds, then let go.
- Page 10 Conducting a lung exam 1. Connect the stethoscope to the app 2. Place the stethoscope firmly onto a patient's clean, intact, unbroken skin at a generally accepted placement position for listening to the lungs 3. Instruct the patient to take deep breaths in and out through an open mouth during the recording.
- Page 11 Important 1. Do not move your fingers on the stethoscope while recording. 2. Do not move the stethoscope while recording. 3. Always listen to the recording you made to ensure it is of high quality, i.e. you can clearly hear the breathing cycle and no artefacts are present.
- Page 12 Turning the stethoscope off 1. Press and hold the Control button (2) on the stethoscope for 4 seconds until the LED (1) is off; 2. Exit the lung exam screen. The stethoscope will go into search mode for 30 seconds (blinking blue LED (1)) and then turn off automatically.
- Page 13 Please read the full User Manual at lungpass.com/support. You can also contact your local distributor for further assistance. Healthy Networks OU Narva mnt 5, 10117 Tallinn, Harju county, Estonia Assembled in China LUS110-002-Rev01-May, 2022...
- Page 14 Automatic detection of crackles and wheezes lungpass.com...
