Summary of Contents for KONNEK STEIN QC21SE
-
Page 2: Product Introduction
1.Product Introduction... -
Page 3: Camera Information
2.Camera Information... -
Page 4: Install The App
3.Install the App 3.Sign up and login smart life account. The app is keep updating，If you had problem with connecting to the device, Please contact the Customer Service Email: customerservice@ttinno.com... -
Page 5: Connecting Device
4.Connecting Device Firstly, make sure your phone is connected to a 2.4GHz Wi-Fi and power the camera. Step 1 long press the reset button on the back next to Power interface for around 8 secs, a short “beep beep beep" prompt tone will be heard when reset successfully, If you still don't hear it, repeat the reset steps. - Page 6 Step 2 Open “Smart Life” APP, click “add device” or “+” on the upper-right corner choose “add device” (Picture 1), Choose “Camera&Lock” and select “smart camera (Wi-Fi)” (Picture 2). Tick "Make sure the indicator is flashing quickly or a prompt tone is heard" and click "Next"...
- Page 7 Step 3 Enter the Wi-Fi password to connect the device to network (Only 2.4GHz Network Supported) (Picture 4), The APP will generate a QR code, use the camera to scan the QR code. A “beep beep beep" prompt tone will be heard if scan successfully, click the button of "I heard a prompt"...
- Page 8 Step 4 If the interface jumps to Picture 7, it means camera added successfully. The interface will jump to preview like Picture 8. Back to homepage (Picture 9), you can click the added device directly to view monitoring status.
- Page 9 5.App Video Interface Information Camera Name Switch Video Quality HD/SD Time Stamp Edit Camera Settings Sound Switch Zoom in Unfold the function bar Record a video clip and save it to gallery Microphone: Press to talk (Two-way or One-way audio) Screenshot: Take a screenshot and save it to gallery Full-Screen Mode Playback: Watch the videos saved on the microSD card...
-
Page 10: Product Installation
6.Product Installation... -
Page 11: Basic Parameters
7.Basic Parameters Note: To reset camera:long press the reset button for 8 seconds, you will hear three beeps prompt tone when reset successfully Please insert a TF card with a speed of Class 10 or above, otherwise it may cause abnormal storage. -
Page 12: Points For Attention
8.Points For Attention Keep away from metal objects Please avoid placing the camera on the back of furniture or in a microwave oven. Avoid placing the camera around audio cables, video cables and USB cables. Please keep as far away from cables as possible. Please try to keep the camera within range of a Wi-Fi signal. -
Page 13: Other Information
10.Other Information FCC ID:2AVTM-QC21SE This device complies with Part 15 of the FCC Rules Operation is sub」ect to the following two conditions...
