Bryant Evolution 280ANV Owner's Manual

280ANV Evolution® Extreme
Variable Speed Heat Pump
with Puron® Refrigerant
2-5 Nominal Tons
A NOTE ABOUT SAFETY
Any time you see this symbol
unit, be aware of the potential for personal injury. There are three levels
of precaution:
WARNING signifies hazards that could result in personal injury or
death.
CAUTION is used to identify unsafe practices which would result in
minor personal injury or product and property damage.
NOTE is used to highlight suggestions which will result in enhanced
installation, reliability, or operation.
WARNING
!
PERSONAL INJURY, DEATH AND / OR PROPERTY
DAMAGE HAZARD
Failure to follow this warning could result in personal injury, death or
property damage.
Improper installation, adjustment, alteration, service, maintenance, or
use can cause explosion, fire, electrical shock, or other conditions
which may cause personal injury or property damage.
qualified installer, service agency, or your distributor or branch for
information or assistance. The qualified installer or service agency
must use factory-authorized kits or accessories when modifying this
product.
Read and follow all instructions and warnings, including labels shipped
with or attached to unit before operating your new heat pump.
ABOUT YOUR HEAT PUMP SYSTEM
Our products are designed, tested and built in accordance with US
Department of Energy standardized procedures and other standards;
however, actual operating results and efficiencies may vary based on
manufacturing and supplier tolerances, equipment configuration,
operating conditions and installation practices.
IDENTIFYING YOUR SYSTEM
Your new Bryant heat pump system is what we call a "split system." It
has an outdoor unit and an indoor unit connected to each other with
copper tubing called refrigerant lines. Each of these units has a rating
plate with the model and serial numbers you will need to reference when
calling an authorized Bryant dealer about your system.
Take a few moments now to locate those numbers and record them for
future reference.
BRYANT SYSTEM
USING YOUR NEW
Your Bryant heat pump system is controlled by a wall-mounted
Evolution Control installed inside your home. This system requires an
Evolution Control which has software designed specifically to operate
this system. See the Evolution Control Homeowner Guide for more
details on system operation.
VARIABLE SPEED OPERATION
You may notice your system runs for longer periods of time. This
system is designed to meet cooling or heating needs of the home at a
wide range of conditions. Your indoor temperature will remain more
consistent with fewer drafts, better humidity control, enhanced comfort
and enhanced energy efficiency.
Owner's Manual
in manuals, instructions and on the
Consult a
HEATING AND COOLING YOUR HOME
For heating or cooling operation, make sure the System or Mode control
is set to the appropriate mode. Then, adjust the Temperature control to
your desired setting. Finally, use the Fan control to select Automatic
(turns on and off as heating is needed) or On (runs continuously).
Depending on your typical heating needs, your home comfort system
may also include a supplementary heating source that will automatically
turn on as needed. You may also select this heat source manually if
desired.
OPERATION UNDER EXTREME CONDITIONS
Your heat pump will run as long as necessary to maintain the indoor
temperature selected on your Evolution Control. On extremely hot days,
your heat pump will run for longer periods at a time than on moderate
days. Your system will also run for longer periods of time under the
following conditions:
• Frequent opening of exterior doors
• Operating laundry appliances
• Taking hot showers
• More than the usual number of people present in the home
• More than the normal number of electric lights in use
• Drapes or blinds are open on the sunny side of the home
IMPORTANT HEAT PUMP FACTS
Heat pump systems have a few unique features and operations that you
should be aware of:
• During the heating cycle, your heat pump delivers a constant flow of
air at around 95°F (35°C)to about 105°F (41°C), compared to sudden
blasts of hot air provided by a typical furnace.
• Ice or frost may form on the outdoor coil during winter heating
operation. Your heat pump will automatically melt the ice using its
defrost cycle. During defrost, you may see steam or fog rising from
the outdoor unit, which is normal. At the beginning and end of the
defrost cycle, you may hear a "whoosh" sound coming from the unit.
This is normal for heat pump applications.
• Heat pumps installed in areas expecting snow are elevated with
support feet.
SOUND
Your new heat pump is different from most heating and cooling systems.
Because this is a variable speed system, it is designed to operate at
different speeds depending on the temperature and humidity conditions.
You may notice the sound coming from the outdoor unit changing from
time to time, and from season to season. In winter, the system will
operate at higher speeds as it gets colder outside to maintain its heating
performance. The higher speed produces a higher sound. This change of
speeds allows the system to operate more efficiently and maintain
comfortable conditions inside the home. You may also hear a slight
"purr" at start-up and shut down. These sounds are normal and do not
represent a problem with your system.
ROUTINE MAINTENANCE
Simple, routine maintenance as described below will enhance your heat
pump system's ability to operate economically and dependably. Always
remember the following safety precautions:
