SFF time N-ATX V2 manual

Dear customer,

Thank you for purchasing SFF time N-ATX V2 case. Please read the full compatibility list before assembling your PC. You can find the list on

our website at sfftime.com.

If you have any doubts about choosing your components, or steps in this manual, please contact us via email on info@sfftime.com, and we will

be glad to assist you.

Important notes:

always use the correct screwdriver tip for corresponding bolts (PH1 or PH2)

always use the correct bolt type

do not overtight the bolts

do not force the components in, each component should be installed without using excessive force

Need help?

Do you have a question about the N-ATX V2 and is the answer not in the manual?

Questions and answers

Summary of Contents for SFF time N-ATX V2

Page 1 SFF time N-ATX V2 manual Dear customer, Thank you for purchasing SFF time N-ATX V2 case. Please read the full compatibility list before assembling your PC. You can find the list on our website at sfftime.com. If you have any doubts about choosing your components, or steps in this manual, please contact us via email on info@sfftime.com, and we will be glad to assist you.
Page 2 SFF time N-ATX V2 manual SFF time N-ATX V2 specifications:  15 L volume with 405.5 x 367 x 101 mm outer dimensions  Console/"pizza box" style case with CPU and GPU fans in the same orientation  ATX power supply up to 180 mm ...
Page 3 SFF time N-ATX V2 manual 1. Case assembly (part 1) your case will come with separated chassis panels and you will need to assemble them before installing your parts in it start by attaching the rear panel to the top panel with two...
Page 4 SFF time N-ATX V2 manual 2. Case assembly (part 2) continue by attaching the MBO tray to the rear and top panel use two 5mm countersunk bolts for top panel, and 4mm countersunk bolt for the rear panel (silver finish)
Page 5 SFF time N-ATX V2 manual 3. Case assembly (part 3) now attach the bottom panel to the MBO tray and to the rear panel with five 5mm countersunk bolts...
Page 6 SFF time N-ATX V2 manual 4. Case assembly (part 4) next step is to attach the front panel to top and bottom panels with four 5mm countersunk bolts...
Page 7 SFF time N-ATX V2 manual 5. Case assembly (part 5) before attaching the mask, you first need to install the USB-C cable use two 5mm countersunk bolts to secure it to the front panel if you want to install more than two 2.5”...
Page 8 SFF time N-ATX V2 manual 6. Case assembly (part 6) now you can attach the mask to the front panel using four M3 flanged nuts with provided hex tool...
Page 9 SFF time N-ATX V2 manual 7. Installing the motherboard – preparing standoffs (part 1) to install standoffs, you need a standoff and a bolt that holds it screw the standoff to the bolt with your hands to tighten the standoff,...
Page 10 SFF time N-ATX V2 manual 8. Installing the motherboard – preparing standoffs (part 2) following pictures show standoff configurations for different motherboard sizes always install correct standoffs, otherwise you could damage the motherboard...
Page 11 SFF time N-ATX V2 manual 9. Installing the motherboard – bolts and cables prepare the motherboard by installing CPU, RAM, M.2 drives, and CPU air cooler if using one install the IO shield align the motherboard on the standoffs screw the motherboard down using provided bolts...
Page 12 SFF time N-ATX V2 manual 10. Installing GPU riser cable – preparing the riser bracket (part 1) attach two parts of the riser bracket using two pan head 4mm bolts like shown in the picture the bottom part should be oriented in a way...
Page 13 SFF time N-ATX V2 manual 11. Installing GPU riser cable – preparing the riser bracket (part 2) this picture shows all the positions in which you can mount the top part of the bracket, depending on your GPU thickness you can also position it in between two...
Page 14 SFF time N-ATX V2 manual 12. Installing GPU riser cable – preparing the riser bracket (part 3) attach the assembled riser bracket to the bottom of the chassis with four 5mm countersunk bolts...
Page 15 SFF time N-ATX V2 manual 13. Installing GPU riser cable – riser and bolts install the male end of the riser into the motherboard screw down the female end of the riser onto previously installed riser bracket unlatch the clip on the female end...
Page 16 SFF time N-ATX V2 manual 14. Installing the GPU – GPU bracket before installing the GPU, you need to attach the GPU bracket to it, as shown in the picture put washers under the bolt heads in necessary screw down the GPU bracket to the GPU...
Page 17 SFF time N-ATX V2 manual 15. Installing the GPU – GPU install the GPU into the riser be sure that it is fully seated latch the riser clip to its locked position if your GPU is very tall, you might want to install it along...
Page 18 SFF time N-ATX V2 manual 16. Installing the GPU – bolts screw down the GPU bracket to the case with two screws put washers under the bolt heads if necessary...
Page 19 SFF time N-ATX V2 manual 17. Installing the power supply – PSU bracket screw down the power supply to the bracket using four silver #6-32 bolts we recommend using bolts supplied with your PSU, as they vary in length...
Page 20 SFF time N-ATX V2 manual 18. Installing the power supply – cable before installing the power supply into the case, screw down the internal AC cable to the rear side of the case using two 5mm countersunk bolts insert the AC plug into the connector on...
Page 21 SFF time N-ATX V2 manual 19. Installing the power supply – bolts screw the power supply bracket to the case from the front and the back side of the case using four provided countersunk screws...
Page 22 SFF time N-ATX V2 manual 20. Parts installed after installing all the main components, you can attach other cables, such as PSU cables you can now proceed to install side panels and the stand installation of hard drives and water-...
Page 23 SFF time N-ATX V2 manual 21. Installing side panels install side panels in a way that the notched side is oriented towards the desired stand location secure side panels with two countersunk bolts for each panel...
Page 24 SFF time N-ATX V2 manual 22. Installing the stand lay the case on its top side bend side panels slightly towards the outside of the case (you can do one at a time) align the slots on the stand to...
Page 25 SFF time N-ATX V2 manual 23. Build complete congratulations, you have completed your build in the N-ATX V2 case! if you have any questions, comments or want to send us your feedback, please write to us at info@sfftime.com be sure to check out our website sfftime.com...
Page 26 SFF time N-ATX V2 manual 24. Installing hard drives – 3.5” drive screw down your 3.5” drive to the case using four #6-32 silver bolts like shown in the picture...
Page 27 SFF time N-ATX V2 manual 25. Installing hard drives – 2.5” drives (part 1) the first position allows to install two 2.5” drives or one 2.5” drive along a 3.5” drive place the drives as shown in the picture and...
Page 28 SFF time N-ATX V2 manual 26. Installing hard drives – 2.5” drives (part 2) the second position allows to install up to ten drives to the front panel or up to seven 2.5” drives along a 3.5” drive place the drive as shown in the picture and screw it down...
Page 29 SFF time N-ATX V2 manual 27. Installing water-cooling radiators (part 1) this picture shows the mounting position for installing 120 mm radiator place the radiator with its fan mounted in a position shown in the picture, and screw it to the...
Page 30 SFF time N-ATX V2 manual 28. Installing water-cooling radiators (part 2) following pictures show mounting locations for 360 and 280 mm radiators for custom loop water-cooling we recommend mounting the radiator flush with the MBO tray and its fans in pull configuration in a way that they pull...
