Floor Plan, Layout & Space Requirements
Printer Dimensions (with Door Closed)
Printer Dimensions (with Door Opened)
Printer Weight
Shipping Dimensions
Shipping Weight
Airwolf 3D EVO22-T Additive Manufacturing Center
F16467-58
Site Preparation Guide
Machine Specifications
1
Airwolf 3D EVO22-T
Additive Manufacturing Center
Installation and Service Manual Link:
https://www.southwesternindustries.com/media/manuals/32502_manual.pdf
28" x 24.5" x 36"
28" x 49.5" x 36"
75 lbs.
48" x 42" x 36"
200 lbs.
Rev 10/12/2021
Advertisement
Summary of Contents for Trak Machine Tools Airwolf 3D EVO22-T
- Page 1 Printer Dimensions (with Door Closed) 28" x 24.5” x 36” Printer Dimensions (with Door Opened) 28" x 49.5” x 36” Printer Weight 75 lbs. Shipping Dimensions 48" x 42" x 36" Shipping Weight 200 lbs. Airwolf 3D EVO22-T Additive Manufacturing Center F16467-58 Rev 10/12/2021...
- Page 2 Airwolf 3D EVO22-T Additive Manufacturing Center Site Preparation Guide Electrical Requirements Power Requirements AC Input 100 – 240 VAC 4 A, 50 – 60 Hz Maximum Power Output 221 W Max. 24VDC, 9.2 A PC Requirements for Apex Requirements Windows Mac OS Mac Version 2013 or later;...
- Page 3 Airwolf 3D EVO22-T Additive Manufacturing Center Site Preparation Guide Lifting, Moving, Uncrating, and Unpacking CAUTION! Proper equipment of sufficient capacity must be used when lifting and/or moving the printer. 1. Lifting/Moving while on a Pallet • The best option for lifting the Airwolf EVO22-T 3D Printer is a pallet jack.
- Page 4 Airwolf 3D EVO22-T Additive Manufacturing Center Site Preparation Guide 11. Remove the tape that keeps the 3D Printer door closed, and open the printer door. 12. Remove the two (2) zip ties around the two (2) chamber heaters inside the 3D Printer.
