VINYL-VAC SYSTEM
MODEL: ASP-1105

Advertisement

loading
Need help?

Need help?

Do you have a question about the VYNIL-VAC ASP-1105 and is the answer not in the manual?

Questions and answers

Summary of Contents for Consolidated VYNIL-VAC ASP-1105

  • Page 1 VINYL-VAC SYSTEM MODEL: ASP-1105...
  • Page 2 Warranty, Specific Safety Rules & Electrical Information WARRANTY INFORMATION The Vinyl-Vac System has a full 1 YEAR WARRANTY on everything against manufacturer’s defects except for the tube frame around it. It is there to protect the machine. If tube frame gets broken, it has done its job. Note: If a weld breaks, fix it with a self-tapping metal screw. Specific Vinyl-Vac System Safety Rules When using the Vinyl-Vac System, follow these basic safety rules: 8.

  • Page 3: Operation

    Introduction, Assembly & Operation INTRODUCTION & PERFORMANCE Your Vinyl-Vac System has gone through extensive testing. Our goal is to move large amounts of air in order to handle almost any amount of leakage through walls etc. creating a proper amount of suction and maintaining it. For example, we have set liners with 6 foot inwall steps not covered, coping not taped, skimmers and returns not taped, and still set the liner with no problem and cut in the steps dry.
  • Page 4 Operation- Liner Installation OPERATION LINER INSTALLATION PROCEDURES When using your Vinyl-Vac System on a new construction installation where there is no existing deck to place it close to the pool, we suggest you go to any building supplier and buy a piece of 4” weeping tile, non perforated, 2-3 feet or whatever length you need to position your Vinyl-Vac System away from the pool.

  • Page 5: Troubleshooting

    Troubleshooting PROBABLE CAUSE SUGGESTED SOLUTION PROBLEM 1. Excessive noise. 1. Motor bearings. 1. Have motor checked by qualified technician. 2. Motor fails to develop full power 2. Circuit overloaded with other 2. Do not use other appliance or motors on (low voltage).
  • Page 6 Parts Diagram/Parts List Model ASP-1105 Order# Description Order# Description 68-11055010 Switch 68-11055160 Hex. nut 68-11055020 Pan hd screw 68-11055170 Fan housing 68-11055030 Switch plate 68-11055180 Washer 68-11055040 Switch housing 68-11055190 Hex. bolt 68-11055050 Reset 68-11055200 68-11055060 Pan hd screw 68-11055210 Inlet 68-11055070 Tube frame...
