Summary of Contents for iSi ISI-799
- Page 1 ISI-799 Service Manual ０...
-
Page 2: Table Of Contents
Contents 1.0 Configuration and Calibration---------------------------------- 2 1.1 Enter Configuration and Calibration-------------------------------------- 2 1.2 Exit Configuration and Calibration---------------------------------------- 5 1.3 Menu Structure and Parameter Descriptions----------------------------- 5 1.3.1 Key Functions In Setup Mode------------------------------------------- 5 1.3.2 Main Menu----------------------------------------------------------------- 6 1.3.3 Configuration Menu------------------------------------------------------- 7 1.3.4 Calibration Menu---------------------------------------------------------- 8 1.3.5 Serial Communication Menu--------------------------------------------- 9 1.3.6 Print Format Menu-------------------------------------------------------- 10... -
Page 3: Configuration And Calibration
1.0 Configuration and Calibration The ISI-99 Indicator can be configured using a series of menus through the indicator front panel when the indicator in setup mode. 1.1 Enter Configuration and Calibration Method 1: Hold “PRINT” key when press “ON/OFF” key to turn on indicator. Display shows “PW0000”, then using front panel key edit display showing “PW0099”... -
Page 4: Main Menu
1.3.2 Main Menu CONFIG CALIB SERIAL PFORMT ALGOUT DIG IO TEST VERS Main Menus 1.3.3 Configuration Menu CONFIG CALIB SERIAL PFORMT ALGOUT DIG IO TEST VERS DECPNT DSPDIV P UNIT LB/KG ZRTRBN number 0.5d none 0.0000 0.00000 ZRANGE AUZERO MOTBAN FILT CKWCOD ZERO... -
Page 5: Calibration Menu
5. LB/KG (LB and KG Switch) Enable or disable LB and KG switching. 6. ZRTRBN (Zero tracking band) OFF, 0.5d, 1d, or 3d can be entered. 7. ZRANGE (Zero range) 2% or 100% can be entered. 8. AUZERO (Auto zero) If ZERO is selected means automatically zero the indicator when power on. -
Page 6: Serial Communication Menu
1.3.5 Serial Communication menu CONFIG CALIB SERIAL PFORMT ALGOUT DIG IO TEST VERS BAUD BITS TERMIN FUNCTN 8none CR/LF CONTIN 7odd DEMAND 1200 7even 2400 8odd 4800 8even 9600 Parameter Descriptions: 1. BAUD (Baud rate) The transmission speed for serial RS-232 port. 2. -
Page 7: Print Format Menu
1.3.6 Print Format menu CONFIG CALIB SERIAL PFORMT ALGOUT DIG IO TEST VERS D FMT G/N FMT number Parameter Descriptions: 1. D FMT (Data format) If select 0, the print format does not include ID number and consecutive number. If select 1, the print format include ID number. If select 2, the print format include consecutive number. -
Page 8: Digital Input Output Menu
2. MIN (Minimum) Specifies the minimum weigh value tracked by analog output. 3. MAX (Maximum) Specifies the maximum weigh value tracked by analog output. 4. TWZERO (Tweak zero) Adjust the analog output zero calibration. Use a multimeter to monitor the analog output value, 0VDC for 0-10VDC, 4mADC for 4-20mADC. -
Page 9: Test Menu
1.3.9 Test menu CONFIG CALIB SERIAL PFORMT ALGOUT DIG IO TEST VERS AD TEST COUNTS 1.3.10 Version menu CONFIG CALIB SERIAL PFORMT ALGOUT DIG IO TEST VERS 2.00 Serial Communication Format <STX> <PL> <WWWWWWW> <UNIT> <G/N> <S> <TERM> ASC I I 02 G = Gross <CR>... -
Page 10: Error Messages
3.0 Error Messages Un---Under load. OL---Over load. Error 1---Span calibration error. Error 2---Analog out span calibration error 4.0 Appendix 4.1 Load Cell Wiring J1 Loadcell 1 +EXC 2 -EXC 3 SHILD 4 +SIG 5 –SIG K2 K3 K4 K5 K6 K7 Load Cell Wiring ９... -
Page 11: Rs-232 Wiring
4.2 RS-232 Wiring J1 Loadcell RS - 232 RS-232 Wiring １０... - Page 12 4.3 Digital Output and Input( J2 Connector) J1 Loadcell Digital Output and Input( J2 Connector) J2 Pin Label Function GND GND DIN Digital Input DO1 Digital Output 1. DO2 Digital Output 2. DO3 Digital Output 3. +5VDC J2 Connector Assignment １１...
-
Page 13: Analog Output Wiring
4.4 Analog Output Wiring L- 102DA Connect To 4 – 20mA Output Main Board J2 Connector 0 – 10V Output Analog Output Board １２... - Page 14 TOTAL METER SERVICES CONFIGURATION DEFAULT SETTINGS FOR ISI 99 INDICATOR DEC. POINT: CAPACITY: 200.0 DSPDIV: P UNIT: LB/KG: ZRTBN: ZRANGE: AUZERO: ZERO MOTBAN: FILT: CKWCOD: PCS: SERIAL COMMUNICATION SETTINGS UNDER “SERIAL” BAUD: 9600 BITS: 8 NONE TERMIN: CR/LF FUNCTN: CONTIN...
