AXIS
H1200/DS | H1400 | H1600/DS | H1600XXL/DS
H1200VLG/D | H12003V | EPI950
INSTALLATION & USER GUIDE
1. SPECIFICATIONS
2. PRELIMINARY INSTALL GUIDE
3. OUTDOOR AIR KIT
4. COMPONENTS LIST
5. INBUILT INSTALLATION
5.1 MASONRY BRICK INSTALLATION
5.2 HEBEL INSTALLATION
6. INBUILT INTO ISLAND WALL
NO COMBUSTIBLE SURROUNDINGS
7. APPLIANCE DETAILS
8. OPERATION & MAINTENANCE
9. TEST RESULTS
10. WARRANTY
NOTICE TO INSTALLER:
These instructions must be left with the owner, who should retain for future use.
1
Edition: 26/10/2022
