TIMYO kreutzer E-pack User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

E-PACK
e-bike user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the kreutzer E-pack and is the answer not in the manual?

Questions and answers

Summary of Contents for TIMYO kreutzer E-pack

  • Page 1 E-PACK e-bike user manual...

  • Page 2: Table Of Contents

    Contents Timyo e-pack set Timyo the e-bike company Timyo E-pack Kreutzer Manufacturer's company details Important instructions Introduction Safety instructions General information For your safety Boosting the e-bike is not allowed Installation and maintenance Safety instructions Legal requirements Intended use Quick start For first ride 3.10...
  • Page 3 Battery lock operation - fully integrated 6.3.2 Removing the battery from the e-bike - fully integrated 6.3.3 Inserting the battery into the e-bike - fully integrated 6.3.4 Battery charging - fully integrated © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 3...
  • Page 4 Central drive engine Hub engine MAINTENANCE RANGE OF YOUR E-BIKE TRANSPORT OF THE E-BIKE 11.1 By car 11.2 By train TIPS FOR PROTECTING THE ENVIRONMENT / WASTE 12.1 Batteries for e-bikes © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 4...

  • Page 5: Timyo E-Pack Set

    VD0.1 Timyo e-pack set You have purchased an e-bike, equipped with a Timyo e-bike system. We are pleased to welcome you as a customer and trust that you will enjoy many years of your assist system. In addition to information about adjustment options for your electric assistance system, we would also like to briefly present our company to you.

  • Page 6: Manufacturer's Company Details

    This symbol indicates possible hazards to your health and even to your life that may arise if certain actions are not carried out and the appropriate precautions are not observed. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 6...

  • Page 7: Introduction

    Your e-bike should only be used in accordance with its intended use. Any other use may lead to technical malfunctions and accidents. Liability for defects and warranty are not valid in case of misuse. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 7...

  • Page 8: Safety Instructions

    The engine and battery can be overloaded and extremely overheated. Consequences: Irreparable damage and fire hazard. ■ The brakes and other components may be overloaded. Consequences: Poor performance, overheating, increase in wear. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 8...

  • Page 9: Installation And Maintenance

    ■ Natural wear as a result of normal use and ageing is not covered by the quality guarantee. ■ Contact your dealer for software updates. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 9...

  • Page 10: Legal Requirements

    Max Drive System is designed for use with city and trekking bikes. It can also be used for mountain bikes. Its use is not allowed for competitions or commercial purposes. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 10...

  • Page 11: Quick Start

    Check that your e-bike is ready to use and set up correctly for you: ■ Adjust the height and position of the saddle and handlebars. ■ Check the brake installation and settings. ■ Secure the wheels to the frame and into the fork. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 11...

  • Page 12: For Each Trip

    The modern technology of the e-bike is high tech! Working on bicycle parts requires specialized knowledge, experience and specialist tools! Do not perform work on your e-bike yourself. Take your e-bike to a specialist workshop if it requires repair or maintenance. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 12...

  • Page 13: Electrical Parts

    C. Mid Engine D. Battery E. Belt drive F. Front light Intube + front wheel engine A. Display B. Control unit C. Front wheel engine D. Battery E. Front light © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 13...

  • Page 14: Important Notes

    Show the actual level of the battery level; the display mode 'Soc View'. can be set in the 8: Speed digital display Display current speed; speed unit can be set in 'Unit'. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 14...

  • Page 15: Overview Control Panel

    0, the highest level is level 5. When the display is switched on, the default mode is Level 1; '0' means no power assist. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 15...
  • Page 16 When the Walk assist is active, an icon will appear with '6km'. It is activated by pressing the button for a few seconds . If you release the button again, the walk assist function also stops immediately. Make sure that you NEVER use the walk assist function while cycling! © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 16...

  • Page 17: Error Codes

    Contact a technician Contact a technician to correct the error message. The display will not return to normal until the problem is resolved. The drive will not be functional until then. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 17...

  • Page 18: Functional Overview Display Dpc10

    The display shows this symbol when the lighting is switched on. Error indicator. Error code indicator. Speed unit. Unit indicator. Remaining range (RANGE). (this representation is not accurate) Assist level © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 18...

  • Page 19: Selection Of Assist Levels

    (this display may differ from the actual range due to different conditions (terrain, temperature, assist level) - power output (W) - calorie meter (C (only if torque sensor is fitted)). © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 19...

  • Page 20: Headlight/Rear Light

    20 % ≤ C < 30 % 10 % ≤ C < 20% 8 % ≤ C < 10% 5 % < C < 8% the digital display flashes ≤ 5% © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 20...

  • Page 21: Usb Charging Function

    NOTE: If the daily mileage reaches 99999 km, this value will be automatically reset. 5.2.11 Selections in km / miles When the system is switched on, short-press twice to open the 'MENU'. Press repeatedly until 'S7' appears on the display (as shown below). © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 21...

  • Page 22: Setting The Light Sensitivity

    (the brightness can be set from 1-5). Once you have made your choice, short-press twice to save your choice and return to the main screen, or short-press once to save your choice and move on to the next item, 'Auto Power Off'. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 22...

  • Page 23: Setting Automatic Switch-Off

    'Speed Limit’. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 23...

  • Page 24: Speed Limit

    Once you have viewed the desired information, short-press twice to save your choice and return to the main screen, or short-press once to go to the next item 'Display software information'. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 24...

  • Page 25: Display Software Information

    'Sensor software information'. PLEASE NOTE: This information will not be displayed if no torque sensor is present in the drive system. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 25...

  • Page 26: Sensor Software Information

    Check the plug or cable of the throttle whether they are properly attached 2. Disconnect the throttle. If the problem still occurs, please contact your dealer (only if this function is available) © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 26...
  • Page 27 2. Contact your dealer if the problem persists. Braking signal has an error. 1. Check all connectors. (If brake sensors are fitted) 2. Contact your dealer if the problem persists. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 27...
  • Page 28 The temperature of the battery is too Contact your dealer. low. The SOC of the battery is too high. Contact your dealer. The SOC of the battery is too low. Contact your dealer. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 28...

  • Page 29: Functional Overview Dpc11

    Trip: daily mileage (TRIP) - total mileage (ODO) - top speed (MAX) - average speed (AVG) - range remaining (RANGE) (This display is an estimate, not accurate) - energy consumption (CALORIES)- power (POWER)- travel time (TIME). © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 29...

  • Page 30: Switching The System On / Off

    (RANGE) (this display may differ from the actual range due to different conditions (terrain, temperature, assist level) - energy consumption (CALORIES) - power consumption (POWER) - travel time (TIME) © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 30...

  • Page 31: Headlight / Rear Light

    60% - 80% display. Each full dash represents 40%-60% a percentage of battery capacity remaining (as shown in the table). 20%-40% 5%-20% < flashes © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 31...

  • Page 32: Settings

    'Metric' (kilometres) or 'Imperial' (miles). Once you have chosen your preferred setting, short-press to confirm your choice save your choice and return to the Display Setting menu. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 32...

  • Page 33: Brightness' Setting The Brightness Of The Display

    Then use to choose from '3'/'5'/'9' (the amount of assist levels). Once you have chosen the desired setting, short-press to save your choice and return to the Display Setting menu. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 33...

  • Page 34: Service' Switching The Message On/Off

    'Information'. This information is not subject to change and is only information about the e-bike. 5.3.20 'Battery Info' Information on the battery This functionality is disabled, this menu does not display any relevant or appropriate information. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 34...

  • Page 35: Ctrl Info' Information About The Controller

    The last 10 error codes of the e-bike can be displayed. The error code '00' indicates that there is no error. Short-press to return to 'Information'. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 35...

  • Page 36: Error Code Definitions

    10 mm and 20 mm. 3. Check that the connector of the speed sensor is correctly connected. 4. Contact your dealer if the problem persists. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 36...
  • Page 37 The temperature of the battery is too Contact your dealer. low. The SOC of the battery is too high. Contact your dealer. The SOC of the battery is too low. Contact your dealer. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 37...

  • Page 38: Overview Of Display Screen C300S

    Displays 30 seconds of the last traveled distance of the previous session. It automatically resets and after the reset starts measuring the current session Trip time Measures how long you ride; resets automatically after display is turned off © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 38...

  • Page 39: Switching On

    'NO' and 'YES'. TRIP Reset includes maximum speed (MAXS), average speed (AVG), one way trip distance (TRIP). After confirmation, short-press (<0.5 sec.) to save and to return to 'TRIP Reset'. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 39...
  • Page 40 Do you want the screen to be on but stop the assist? Set the assistance level to 0. The computer system then continues to measure distances and speeds. Pay attention! The display will turn off automatically after 5 minutes at a speed of 0 km/h. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 40...

  • Page 41: Error Messages

    6km/h. 6km/h is shown on the display. Walk assist can only be used when walking with the e-bike. Make sure you NEVER use the walkassist while cycling! © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 41...

  • Page 42: Using The Lighting

    Contact a technician Contact a technician to correct the error message. The display will not return to normal until the problem is resolved. The drive will not be functional until then. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 42...

  • Page 43: Overview Of Display Screen C300T

    Displays 30 seconds of the last traveled distance of the previous session. It automatically resets and after the reset starts measuring the current session Trip time Measures how long you ride; resets automatically after display is turned off © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 43...

  • Page 44: Switching On

    (<0.5 sec) to switch between 'NO' and 'YES'. TRIP Reset includes maximum speed (MAXS), average speed (AVG), one way trip distance (TRIP). After confirmation, short-press (<0.5 sec.) to confirm © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 44...
  • Page 45 Do you want the screen to be on but stop the assist? Set the assistance level to 0. The computer system then continues to measure distances and speeds. Pay attention! The display will turn off automatically after 5 minutes at a speed of 0 km/h. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 45...

  • Page 46: Error Messages

    This way you don't have to move the whole bike yourself. 5.6.7 About the throttle This throttle is located under the control unit. This is in addition to walk-assist, where the engine provides an impulse while walking. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 46...

  • Page 47: Overview Of Display Functions Dp C07

    The charging status is indicated by 10 bars. The battery is fully charged when all bars are lit on the screen. An optimization algorithm ensures a stable display of the battery status. This avoids the problem of fluctuating battery level indicators in many displays. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 47...

  • Page 48: Overview Of Control Panel

    1; the highest is level 5. The default level when switching on is level 1. If no number is indicated, the engine will not provide any assistance. no assist level. 1 assist level. 5 © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 48...

  • Page 49: Switch Between Distance Mode And Speed Mode

    “ appears on the screen. As soon as you release the button, the walk assist mode is switched off. Make sure you NEVER use the walk assist function while cycling! © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 49...

  • Page 50: Switching Between Engine Assist And Pedal Assist

    To enter the parameter setting mode, turn on the screen and press the " " button TWICE for more than 0.3 seconds. ■ You are now in the menu to enter parameter settings. Here your settings can be changed. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 50...

  • Page 51: Resetting The Data Of A Single Trip

    "0", the sensor function will be disabled. ■ The lower the number, the darker it has to be for the sensor to automatically switch on the bicycle lighting Function OFF Lowest level Highest level © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 51...

  • Page 52: Screen Brightness Lighting

    Error in the Hall sensor of the engine Take your electric e-bike to your dealer or to a specialist to have the error resolved. Engine temperature reaches maximum pro- Stop the e-bike for a break tection value © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 52...
  • Page 53 Changes to the electrical system may result in criminal prosecution. This may be the case if the supported maximum speed has been modified. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 53...

  • Page 54: Overview Of Display Screen Kd716

    ' button on the control panel and the following riding data will be displayed: Trip Distance (Km) -> ODO (Km) -> Max. speed (Km/h) -> Avg. speed (Km/h) ->Trip Time (Min.) © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 54...

  • Page 55: Switching Walk Assist On/Off

    The definitions of the codes are included in the error code list. Allow the display to recover when an error code is displayed. Otherwise you cannot ride the e-bike normally. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 55...

  • Page 56: Error Code List

    ' and ' ' buttons simultaneously for 2s to enter general settings. Press and hold both the ' ' and ' ' buttons for 2s to enter general parameter settings. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 56...

  • Page 57: Wheel Diameter Settings

    After values for 5 bars have been entered completely, long-press " " to confirm and return to the previous menu. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 57...

  • Page 58: Power Assist Level Settings (Optional)

    "9". "2" is the furthest, "9" is the weakest. The default value is '2'. Press " " or " " to select the sensitivity value and change the PAS sensitivity settings. Press " " and then access the settings of the magnetic disk. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 58...

  • Page 59: Magnet Quantity Settings

    " to set the maximum speed from 12 km/h to 25 km/h. Press " " to confirm and then access push-assist settings. The maximum speed is set by the display manufacturer. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 59...

  • Page 60: Enable/Disable Settings

    " (more than 2 s), you must cancel the operations, but not to save setting data and use the settings. If there are no operations within one minute, the settings interface will automatically close. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 60...

  • Page 61: Restore Default Settings

    Y means restoring default settings. When you choose "Y", hold " " for 2s to restore default settings, the screen displays DEF-00 at the same time and returns to the home screen. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 61...

  • Page 62: Battery

    To avoid damaging the battery discharge, the battery control system puts the battery in sleep mode. In sleep mode, no function is indicated for technical reasons. Press and hold the " " button for 5 seconds to exit the persistent sleep mode. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 62...

  • Page 63: Semi-Integrated Battery Saber/Swordfish

    The charging port is on the right side of the battery - on the other side is the throttle for unlocking the battery. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 63...

  • Page 64: Fully Integrated Battery Tm40/Tm50/Tm70

    If only one light is on, charging the battery is recommended ■ Do not leave the battery in direct sunlight ■ Charge the battery at least every 2 months when it is not in use © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 64...

  • Page 65: General Information On Charging

    Leaking electrolytes can cause skin problems. If battery acid comes into contact with the eyes, do not rub them. Wash your eyes immediately with clean water. Contact the hospital for further treatment! © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 65...

  • Page 66: Storage Of The Battery Pack

    Avoid direct sunlight. Direct sunlight can lead to overheating, deformation, rupture, poor performance and shortened battery life. ■ To prevent deep discharge, the battery goes into sleep mode after a certain period of time. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 66...

  • Page 67: Battery Wear

    The battery may have a malfunction. Contact your dealer. doesn't light up. The charger's indicator light The battery may have a malfunction. Contact your dealer. does not illuminate red continuously. 6.11 Battery specs © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 67...

  • Page 68: Charger

    ■ If charging takes longer than stated in the specifications table, stop charging. ■ After charging, remove the Battery pack from the charger and unplug it from the power outlet. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 68...

  • Page 69: Drive Unit

    Please note that if the road surface is slippery (e.g. due to rain, snow, sand), there is a risk that the wheels of your e-bike could slip. Always adapt your driving style and speed to the circumstances, using common sense. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 69...

  • Page 70: Maintenance

    ■ Charge status of the battery: The charge status indicates how much electrical energy is stored in the battery at a given time. More energy means a greater range. © TIMYO B.V. TIMYO USER MANUAL EN SKO52021V2 PAGE 70...

  • Page 71: Transport Of The E-Bike

    They must be disposed of by specialist dealers or manufacturers. Legal notice © Timyo B.V. All rights reserved. Timyo B.V. declares that this device complies with the essential requirements and other relevant provisions of the Machinery Directive. © TIMYO B.V. TIMYO USER MANUAL EN...
  • Page 72 Stepvelden 1 4704 RM Roosendaal +31 165 224612 info@timyocycle.com www.timyocycle.com...
