- Page 1 VFFR2101ESSE VFFR2101ESE VFFR2101ESBE Models / Modelos VFFR2101ESSE-C VFFR2101ESE-C VFFR2101ESBE-C INSTRUCTION MANUAL REFRIGERATOR / FREEZER MANUAL DE INSTRUCCIONES REFRIGERADOR / CONGELADOR BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
-
Page 2: Table Of Contents
Table of Contents Warning Warning------------------------------------------------------- 1 Safety and warning information Basic safety symbol----------------------------------------- 5 Appliance connection -------------------------------------- 5 LED light ------------------------------------------------------ 5 Safety and warning information--------------------------- 5 Product Introduction Product features -------------------------------------------- 8 Product components --------------------------------------- 9 Installation dimension-------------------------------------- 10 Installation Transportation----------------------------------------------- 11 Where to install your unit ---------------------------------- 11... -
Page 3: Warning
Warning CAUTION This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 4 Warning replaced by the manufacturer,its service agent or similarly qualified person to avoid any hazards. 3. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. 4. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
- Page 5 Warning 13. WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. 14. WARNING:To avoid contamination of food, please respect the following instructions: - Opening the door for long periods can cause asignificant increase of the temperature in the compartments of the appliance.
-
Page 6: Warning
Warning When you are finished, reconnect the refrigerator to the electrical source and reset the temperature controls to the desired setting. 16. This appliance is intended to be used in household and similar applications such as: - staff kitchen areas in shops, offices and other working environments;... -
Page 7: Safety And Warning Information
Safety and Warning Information Basic safety symbol This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol.It alerts you to warnings that will △ inform you of any potential hazards that could hurt or kill you. These messages will also help protect your unit from damage. - Page 8 Safety and Warning Information Safety and warning information If you believe there is refrigerant leaking, do not touch the unit or the power outlet, ventilate the room and if possible turn your unit off using the circuit breaker. Call the manufacturer immediately. Refrigerant will cause serious injury when coming into contact with the skin or eyes.
- Page 9 Safety and Warning Information Safety and warning information Do not touch food or containers in the freezer with wet hands.It may cause frostbite. Do not spray water at the outside or the inside of the fridger do not clean it with benzene or thinner.
-
Page 10: Product Introduction
Product Introduction Product features This unit container super freeze, energy-savings, noise reduction, optimal refrigeration are preset options for your unit. Precise temperature control Microcomputer control systems are able to separately control both the fridge and freezer more accurately. Automatic defrosting This unit is equipped with a program that controls the frequency and duration of defrosting your freezer. -
Page 11: Product Components
Product Introduction Product components The layout of items below are subject to change without notice, and may not look or come setup as seen in the picture below. The appearance and specifications of the actual product may differ depending on the model. -
Page 12: Installation Dimension
Product Introduction Installation dimension Select a good location to place your appliance where it is flat and easy to use.Avoid placing the unit near heat sources,direct sunlight or moisture. 372,7 372,7 1654,4 The above figures are a guideline for installation purposes. The actual dimensions of the unit may vary slightly. -
Page 13: Installation
Installation Transportation Do not carry the refrigerator horizontally or by laying it down. Do not carry the refrigerator by holding the door or handle; the refrigerator shall be carried by lifting the bottom. This unit should never be moved alone, two people are required to safely lift or move your unit. -
Page 14: Operation
Operation Before Use This refrigerating appliance is not intended to be used as a built-in appliance. Remove all of the packaging, including the foam backing at the bottom of the unit and the tape that fixes the shelves and door bins inside. Place the refrigerator to a proper position, and adjust the feet to level. -
Page 15: Control Panel
Operation Control panel Quick Cool Smart icon icon FRIDGE FREEZER MODE QUICK QUICK SMART COOL FREEZE Quick Freeze Mode control icon Default is Fahrenheit when power is on. Press "MODE" button 5 seconds, to switch between °C °F Other buttons use the same method to switch between two modes. Set temperature range: Celsius degree mode Fridge temperature range: 2~8°C... - Page 16 Operation QUICK FREEZE MODE This mode will quickly drop in temperature when storing large amounts of warm or room-temperature foods in the freezer. The unit will remain in QUICK FREEZE mode for 24 hours or until the temperature reaches -18ºF(-28°C) and will then return to the original setting, or until the function is turned off at the control panel.
-
Page 17: Fridge Compartment Switch Off/On
Operation NOTE: • IF THE UNIT IS UNPLUGGED, HAS LOST POWER, OR IT IS TURNED OFF. YOU MUST WAIT 3 TO 5 MINUTES BEFORE RESTARTING THE UNIT. IF YOU ATTEMPT TO RESTART BEFORE THIS TIME DELAY, THE REFRIGERATOR-FREEZER WILL NOT START. NOTE: ·... -
Page 18: Refrigerator Chamber
Operation Refrigerator chamber The fridge compartment should mainly be used to store food that will be consumed in a short time. 1 Refrigerator door rack 2 Refrigerator glass shelves 3 Crisper 4 Full width crisper Freezing chamber The freezing chamber is used to freeze foods,store deeply frozen foods and make ice cubes.lt can preserve foods for a long time. -
Page 19: Instructions For Storing Foods
Operation Instructions for storing foods CAUTION -When storing freezing foods, put them to the inside of freezing chamber, other than the bottle rack. -Do not put bottled or canned foods into the freezing chamber to prevent frost cracking. Before putting hot foods into the refrigerator, cool them to room temperature first; otherwise, they will increase power consumption. - Page 20 Operation Storage of foods Butter can become tainted by strong smelling foods so it is best stored in a sealed container. Eggs should be stored in the fridge compartment. Red meat Place fresh red meat on a plate and loosely cover with waxed paper, plastic wrap or foil. Store cooked and raw meat on separate plates.
- Page 21 Operation Storage of foods Food is not allowed to touch directly all surfaces inside the appliance. It has to be Note: wrapped separately in aluminum sheet or in cellophane sheet or in airtight plastic boxes. Freezing and storing food in the freezer compartment ·...
-
Page 22: Maintenance
Maintenance Defrosting This production has automatic defrosting function, without manual operation. Cleaning Precautions for internal and external cleaning of refrigerator: - Before cleaning, always turn off the power switch, disconnect the power plug. - During cleaning, make sure that no water will enter the switch, control panel, doorlamp and top control box. -
Page 23: Normal Phenomena
Maintenance Normal phenomena Button failure Please check the control board whether the fridge under lock mode.When under lock mode, all buttons can't work. Low voltage,the compressor can't start You should purchase pressurizer of more than 1000W when the area of the appliance installation,that's better to protect your fridge. - Page 24 Maintenance Normal phenomena Abnormal odors in refrigerator Odorous foods shall be packaged tightly; check for bad foods; the inside of refrigerator shall be cleaned. Ice maker failing to work normally Whether the ice maker switch is turned on; whether the freezing chamber door is closed or ajar; Whether the water valve is opened;...
-
Page 25: Troubleshooting
Maintenance Troubleshooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Fault Possible cause Remedial action The mains plug of the appliance No display on the Check whether the power is on ;... - Page 26 This symbol on the product or in its packing indicates that this product may not be treated as household waste. Instead, it should be taken to the appropriate waste collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by the...
