Model No. WEBE13101
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (Under Seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through
direct assistance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before
using this equipment. Save this
manual for future reference.
¨
USERÕS MANUAL
www.weiderfitness.com
new products, prizes,
fitness tips, and much more!
455
455
Visit our website at
Advertisement
Table of Contents
Related Manuals for Weider WEBE13101
Summary of Contents for Weider WEBE13101
- Page 1 ¨ Model No. WEBE13101 USERÕS MANUAL Serial No. Write the serial number in the space above for future reference. Serial Number Decal (Under Seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...
-
Page 2: Table Of Contents
Table of Contents WARNING DECAL PLACEMENT ............2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
Important Precautions WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight bench. 1. Read all instructions in this manual before 11. Keep hands and feet away from moving parts. using the weight bench. 12. -
Page 4: Before You Begin
Whether your goal is a shapely figure, dramatic number before calling. The model number is increase in muscle size and strength, or a healthier WEBE13101. The serial number can be found on a cardiovascular system, the WEIDER ¨ PRO 455 will decal attached to the weight bench (see the front help you to achieve the specific results you want. -
Page 5: Part Identification Chart
Part Identification Chart This chart is provided to help you identify the small parts used in assembly. The number in parentheses below each part refers to the key number of the part. The second number refers to the quantity needed for assembly. Important: Some parts may have been pre-assembled for shipping purposes. -
Page 6: Assembly
Assembly Before beginning assembly, carefully read the ¥ As you assemble the weight bench, make sure following information and instructions: that all parts are oriented as shown in the draw- ings. ¥ Place all parts of the weight bench in a cleared area and remove the packing materials;... - Page 7 3. Attach the Front Leg (8) to the Frame (2) with two M10 x 65mm Bolts (18), two M10 Washers (24), and two M10 Nylon Locknuts (19). 4. Tap three 45mm Square Inner Caps (21) into the Leg Lever (4) as shown. Tap a 1Ó...
- Page 8 7. Lubricate the M10 x 178mm Bolt (17). Attach the Backrest Tubes (5, 42) to the Frame (2) with the Bolt, two M10 Washers (24), and an M10 Nylon Locknut (19). Secure the Backrest (6) to the Frame (2) by inserting the Adjustment Pin (32) through one of the three sets of holes in the adjustment tubes.
-
Page 9: Using The Weight Bench
11. Tap two 3/4Ó Round Inner Caps (9) into each Pad Tube (10). Insert the Pad Tubes into the holes in the Leg Lever (4) and the Front Leg (8). Slide two Foam Pads (22) onto each Pad Tube. 12. Make sure that all parts are properly tightened before you use the weight bench. - Page 10 ATTACHING THE CURL POST For some exercises, the Curl Post (26) must be attached to the weight bench. Slide the Curl Post (26) into the Front Leg (8). Align one of the adjustment holes in the Curl Post with the adjustment hole in the Front Leg.
-
Page 11: Exercise Guidelines
Exercise Guidelines THE FOUR BASIC TYPES OF WORKOUTS PERSONALIZING YOUR EXERCISE PROGRAM ¥ Muscle Building We have not specified an exact length of time for each workout, or a specific number of repetitions or In order to increase the size and strength of your sets for each exercise. - Page 12 for 3 minutes after each set if you are doing a muscle STAYING MOTIVATED building workout, 1 minute after each set if you are doing a toning workout, and 30 seconds after each set For motivation, keep a record of each workout. The if you are doing a weight loss workout.
- Page 13 MONDAY EXERCISE WEIGHT SETS REPS Date: AEROBIC EXERCISE TUESDAY Date: EXERCISE WEIGHT SETS REPS WEDNESDAY Date: THURSDAY AEROBIC EXERCISE Date: EXERCISE WEIGHT SETS REPS FRIDAY Date: Make photocopies of this page for scheduling and recording your workouts.
-
Page 14: Part List
Part ListÑModel No. WEBE13101 R0800A Key No. Qty. Description Key No. Qty. Description Upright 1Ó Round Inner Cap Frame M10 Washer Crossbar M6 Washer Leg Lever Curl Post Right Backrest Tube Curl Pad Backrest Carriage Bushing Upright Base 1Ó Angle Cap... -
Page 15: Exploded Drawing
Exploded DrawingÑModel No. WEBE13101 R0800A... -
Page 16: Ordering Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information when calling: 1. The MODEL NUMBER of the product (WEBE13101) 2. The NAME of the product (WEIDER ¨...
