C H R O N O A U T O M AT I C
We thank you for the confidence that you
have shown in us by choosing the PIRELLI
PZEROTEMPO brand. To enable you to use
your watch to the best advantage, we
recommend that you carefully read the
instructions
in this leaflet.
C H R O N O
E N G L I S H
F R A N Ç A I S
D E U T S C H
I T A L I A N O
E S P A Ñ O L
PORTUGUÊS
Advertisement
Summary of Contents for PIRELLI PZEROTEMPO CHRONO
- Page 1 E N G L I S H C H R O N O C H R O N O A U T O M AT I C F R A N Ç A I S D E U T S C H We thank you for the confidence that you have shown in us by choosing the PIRELLI I T A L I A N O...
- Page 2 I N D E X 1 PRECAUTIONS 2 COMPONENTS Time function Chronograph function 3 SETTING THE TIME 4 CORRECTING THE DATE 5 USING THE CHRONOGRAPH Cronograph Intermediate time 6 ZEROING THE CHRONOGRAPH COUNTERS Minutes Seconds and 10th of a second...
- Page 3 PRECAUTION Do not operate the crown and the push-buttons when the watch is in the water. Some models come with a screwed crown which must be unscrewed in order to access the setting and screwed back after use. To ensure that the watch is sealed, always check that the crown is correctly ti tightened.
- Page 4 COMPONENTS Time function hour hand crown date display second hand minute hand...
- Page 5 C h r o n o g r a p h f u n c t i o n 10th of a second counter second counter push-button A start/stop minute counter push-button B intermediate time/ catch-up/ reset...
-
Page 6: Setting The Time
SETTING THE TIME Unscrew the crown (if screwed). Pull out the crown by 2 notches. Turn the crown in either direction to move the hands forward or back. Return the crown to the normal position. Retighten the crown. Note By pulling the crown by 2 notches (point 2), the movement stops (second stop function). - Page 7 CORRECTING THE DATE Unscrew crown (if screwed). Pull out the crown by 1 notch. Turn the crown clockwise. The date display changes. Return the crown to the normal position. Retighten the crown. IMPORTANT Do not leave the crown pulled by 1notch for more than 20 minutes as this will effect the hour.
-
Page 8: Using The Chronograph
USING THE CHRONOGRAPH Chronograph IMPORTANT Start chronograph (push-button A). If the hands of hands of chronograph are not correctly positioned, please refer to Section 6. Stop chronograph (push-button A). Read the final time. Reset (push-button B). Note The sequence of point 1+2 con be repzated (added times) - Page 9 Intermediate time Start chronograph (push-button A). Intermediate time (push-button B). Read intermediate time. Read time catch-up (push-button B). Stop chronograph (push-button A). Read the final time. Reset (button B). Note The sequence of point 2 to 4 can be repeated (multiple intermediate times).
- Page 10 ZEROING THE CHRONOGRAPH COUNTERS After changing the battery, or if samething exceptional has occurred, reset the chronograph counters to zero (starting position) by hand.
- Page 11 Minutes Seconds and 10th of a second Unscrew the crown (if screwed). Unscrew the crown (if screwed). Pull out the crown by 1 notch. Pull out the crown by 2 notches. Reset the 10th of a second counter Reset the minute counter (push-button A). (push-button A).
- Page 12 A1 A2 A3...
- Page 13 Function: hours, minutes and seconds. Small seconds counter in position 5, date in position 6. Chronograph functions: hours, minutes and seconds. 12 hours counter in position 4, minutes counter in position 1. Seconds hand in the center. Hour adjustment: unscrew the crown, pull it out, position A3 , rotate it clockwise to correct the hour.
- Page 15 Nous vous remercions de la confiance que vous nous accordez en ayant choisi la I T A L I A N O marque PIRELLI PZEROTEMPO. Sfin d’utiliser votre montre de mainière appropriée, nous E S P A Ñ O L vous recommandos de lire attentivements PORTUGUÊS...
- Page 16 I N D E X 1 PRECAUTIONS 2 DESIGNATION DES PIECES Fonction heure courante Fonction chronographe 3 REGLAGE DE L’HEURE COURANTE 4 CORRECTION DE LA DATE 5 UTILISATION DU CHRONOGRAPHE Chronographe Temps intermédiaire 6 INITIALISATION DES COMPTEURS DU CHRONOGRAPHE Minutes Seconds et 1/10 de seconde...
- Page 17 PRECAUTIONS Ne pas actionner la couronne et les poussoirs lorsque la montre se trouve dans l’eau. Certains modèles sont pourvus d’une couronne vissée. Celle-cidoit être dèvissée pour accéder aux réglages et revissée après utilisation. Afin de garantir l’étanchéité de la montre, vérifier que la couronne soit toujours correctement vissée.
-
Page 18: Designation Des Pieces
DESIGNATION DES PIECES Fonction heure courante aiguille des heures couronne indicateur aiguille des secondes aiguille des minutes... - Page 19 Fonction chronographe compter 1/10 de seconde compteur des secondes poussoir A départ/arrêt compteur des minutes poussoir B temps intermédiaire/ rattrapante/ remise à zéro...
- Page 20 REGLAGE DE L’HEURE COURANTE Dévisser la couronne (si vissée). Tirer la couronne de 2 crans. Touner la couronne dans un sens ou dans l’autre pour faire avancer ou reculer les aiguilles. Remettre la couronne en position normale. Revisser la couronne. REMARQUE En tirant la couronne de 2 crans (point 2), le mouvement s’arrête (fonction stop-...
