- Page 1 ZVOX AccuVoice Headphones ® Model AV52 www.zvox.com...
- Page 2 Important Safety READ THIS FIRST Instructions Important Safety Instructions For ZVOX Audio System 1. Read these instructions. WARNING 2. Keep these instructions. 3. Heed all warnings. • Do NOT use headphones at a high • volume for any extended period.
-
Page 3: Table Of Contents
Table of Contents What is included in the carton ................................2 ................................... 3 Features of the AV52 Headphones ..............................3 Diagram of the AV52 Headphones ............................... 4 Charging the Internal Battery ................................5 Wearing the AV52 Headphones ................................5 Power and Button Layout ..................................6 Button Layout Continued .................................. -
Page 4: What Is Included In The Carton
What is Included in the Carton USB charging cable Audio signal cable USB Type A to USB Type C 3.5mm (1/8”) stereo miniplugs AV52 Headphones User Manual Carrying Case 2 AV52 Headphones | What is Included in the Carton... -
Page 5: Features Of The Av52 Headphones
Features of the AV52 Headphones • acoustic and electronic digital processing. These headphones make it easy to hear all voices clearly, even at low volume levels with 40mm dynamic drivers delivering deep bass. • Engage the AV52 headphones’ Active Noise Cancelling technology for immersive sound by using a dedicated noise reduction circuit chip for •... -
Page 6: Diagram Of The Av52 Headphones
Diagram of the AV52 Bottom of the Headphones Left Earcup Right Earcup Active Noise Cancelling Microphone, Clear Voice Capture 8.0 ANC Indicator LED Audio Connection MFB Indicator LED Power Charging Port Previous Track/Volume - Multi Function Button Next Track/Volume + 4 AV52 Headphones | Diagram of the AV52... -
Page 7: Charging The Internal Battery
Charging The Internal Battery: The AV52 headphones plug into a standard wall outlet with a universal wall charger provided with most cellphones or a standard USB input on a computer or TV. The USB type C connector goes Wearing the AV52 into the left side of the headphones for charging. -
Page 8: Power And Button Layout
Power ON/OFF: Power ON: Press and hold the MFB (Multi Function voice command saying “Power on, pairing” will be heard through the headphones followed by red and blue lights Power OFF: Press and hold the same MFB (Multi Function voice prompt say “Power on” will be heard through the headphones. -
Page 9: Button Layout Continued
ANC (Active Noise Cancelling): Turn ON: Power on the AV52 headphones, then tap the ANC button to activate noise cancelling. A GREEN indicator light the headphones are turned off. Turn OFF: To disable ANC (Active Noise Cancelling) tap the ANC button. The same green indicator light will disapear and two low tone beeps will be heard. -
Page 10: Pairing Phone, Tablet, Computer
How to Pair to Phone or Tablet (Computer): Step 1. Press and hold the MFB (Multi Function Button) on the AV52 for 5 seconds to enter the pairing mode. Red and blue lights will Multi Function Button Step 2. Immediately turn on the Bluetooth function within the phone and search ZVOX AV52 in the bluetooth list, then click to connect. -
Page 11: Pairing To Tv & Fcc Statement
How To Pair Wireless To a Television: Connecting The ZVOX AV52 Headphones wireless via Bluetooth to a TV is simple. The TV must be equipped with Bluetooth capabilities (See TVs User Manual). If not equipped you must purchase a Bluetooth Transmitter that will then connect to an audio output jack on the TV allowing wireless audio to transmit to the AV52 headphones. - Page 12 Friday and 10:00 AM to 6:00 PM on Saturday. For further information about additional options, please refer to the ZVOX Audio website, www.zvoxaudio.com or support.zvox.com www.zvox.com 1005250 2021 © 2021 ZVOX Audio LLC. ® ZVOX, AccuVoice & PhaseCue are registered trademarks of ZVOX Audio LLC.
Need help?
Do you have a question about the AccuVoice AV52 and is the answer not in the manual?
Questions and answers
The power on/off light flashes blue and red, doesn't connect with my laptop, it used to.
The power light on your Zvox Audio AccuVoice AV52 is flashing blue and red because the headphones are in Bluetooth pairing mode. If they are not connecting to your laptop, try the following steps:
1. Ensure Bluetooth is enabled on your laptop.
2. Check if the headphones are already paired with another device and disconnect if necessary.
3. Clear the Bluetooth pairing records by holding the MFB (Multi-Function Button) and Volume + for 5 seconds until the blue LED stays lit for 2 seconds, followed by red and blue flashing alternately.
4. Try pairing again by selecting the headphones from your laptop's Bluetooth settings.
If the issue persists, restart both the headphones and the laptop before attempting to pair again.
This answer is automatically generated
