Flush mount for low-profile vandal dome IP cameras
Camera Mounting Screws for
DWC-M(P)V8 Cameras (25mm)
Camera Mounting Screws for
DWC-M(P)VC Cameras (16mm)
NOTE:
Download all your support materials and tools in one place
1.
Go to: http://www.digital-watchdog.com/resources
Search your product by entering the part number in the 'Search by Product' search bar. Results
2.
for applicable part numbers will populate automatically based on the part number you enter.
3.
Click 'Search'. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
Tel: +1 (866) 446-3595 / (813) 888-9555
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
DWC-VFFMW
WHAT'S IN THE BOX
2
Quick Setup Guide
2
Mounting Template
Quick Start Guide
digital-watchdog.com
1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DW DWC-VFFMW
Summary of Contents for DW DWC-VFFMW
- Page 1 Quick Start Guide Flush mount for low-profile vandal dome IP cameras DWC-VFFMW WHAT’S IN THE BOX Camera Mounting Screws for Quick Setup Guide DWC-M(P)V8 Cameras (25mm) Camera Mounting Screws for Mounting Template DWC-M(P)VC Cameras (16mm) NOTE: Download all your support materials and tools in one place Go to: http://www.digital-watchdog.com/resources...
- Page 2 Quick Start Guide Quick Start Guide INSTALLATION Before the installation, remove the magnetic cover from the flush mount. Using the mounting template mark and drill the necessary holes in the mounting surface. Adjust the 3-point in-ceiling wing using a screwdriver. Twist the screws to tighten and expand until the flush mount is secured to the mounting surface.
