IBASE Technology SE-103-N User Manual

Intel atom x6000 fanless signage player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SE-103-N
Intel® Atom® x6000
Fanless Signage Player
User's Manual
Version 1.0
(October 2022)

Advertisement

Table of Contents
loading

Related Manuals for IBASE Technology SE-103-N

Summary of Contents for IBASE Technology SE-103-N

  • Page 1 SE-103-N Intel® Atom® x6000 Fanless Signage Player User’s Manual Version 1.0 (October 2022)
  • Page 2 No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).
  • Page 3 0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by weight (100 ppm). • Lead (Pb) • Mercury (Hg) • Cadmium (Cd) • Hexavalent chromium (Cr6+) • Polybrominated biphenyls (PBB) • Polybrominated diphenyl ether (PBDE) SE-103-N User Manual...
  • Page 4 Avoid Disassembly Do not disassemble, repair or make any modification to the device. Doing so could generate hazards and cause damage to the device, even bodily injury or property damage, and will void any warranty. SE-103-N User Manual...
  • Page 5 Software in use (such as OS and application software, including the version numbers) 3. If repair service is required, you can download the RMA form at http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and contact the distributor or sales representative. SE-103-N User Manual...

  • Page 6: Table Of Contents

    Security Settings ..................47     Boot Settings ..................49     Save & Exit Settings ................50     Appendix ...................... 51  I/O Port Address Map ................52     Interrupt Request Lines (IRQ) ..............54     SE-103-N User Manual...

  • Page 7: Chapter 1 General Information

    Chapter 1 General Information The information provided in this chapter includes:  Features  Packing List  Accessories  Specifications  Product View  Dimensions...

  • Page 8: Introduction

    1.1 Introduction The SE-103-N is a fanless digital signage player that leverages the Intel® x6000 family processors that can be install in commercial establishments to increase brand awareness and customer engagement or deployed in transportation networks to provide real-time information and advertising relevant to the traveler.

  • Page 9: Packing List

    1.3 Packing List The product package should include the items listed below. If any of the items below is missing, contact the distributor or the dealer from whom you purchased the product. SE-103-N Digital Signage Player  Power Adaptor ...
  • Page 10 Note: The product performance relies on the system functioning as a whole. The level of CPU/APU/GPU processor, the interaction among the processor and the memory and storage bandwidth, or the functionality of the digital signage application software may affect the product performance. SE-103-N User Manual...

  • Page 11: Product View

    Function DC 12V Power Input Connector Line out Connector HDMI (Port C, A, B) Power Button (USB 3.1 Connectors) Power Switch Connector LAN Connector EDID Clear Button RS-232/422/485 Power LED Line in Connector HDD LED Front View SE-103-N User Manual...
  • Page 12 SE-103-N User Manual...

  • Page 13: Dimensions

    General Information 1.6 Dimensions Unit: mm SE-103-N User Manual...

  • Page 14: Hardware Installation & Motherboard Information

    Chapter 2 Hardware Installation & Motherboard Information The information provided in this chapter includes:  Installation of memory, M.2 and mini PCIe card  Information and locations of connectors...

  • Page 15: Installation / Replacement

    Hardware Configuration 2.1 Installation / Replacement The following pictures show how to disassemble the SE-103-N. 1. To use the SIM card slot, remove the two (2) screws as shown below. 2. The following pictures show how to disassemble the system when replacing internal parts such as memory modules and M.2 cards.
  • Page 16 Separate the base and heatsink by releasing the six (6) screws shown above. Disassemble the motherboard and heatsink by releasing the seven (7) screws shown above. Note: Removing the main board to install the memory may damage the thermal pad and affect the thermal conductivity efficiency. SE-103-N User Manual...
  • Page 17 Gently push the module in an upright position until the clips of the slot close to hold the module in place when the module touches the bottom of the slot. To remove the module, press the ejector tabs outwards with your fintertips to eject the module. SE-103-N User Manual...
  • Page 18 2.1.2 M.2 Cards 3. Locate the M.2 slot inside the device. 4. Align the key of the M.2 card to the interface, and insert the card slantwise. Fix the M.2 card with an screw. SE-103-N User Manual...
  • Page 19 1. Thread and fasten the hex nut and the 2. Apply adhesive around here. washer. Then install the antenna. Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC). SE-103-N User Manual...

  • Page 20: Setting The Jumpers

    2.2 Setting the Jumpers Set up and configure the SE-103-N by using jumpers for various settings and features according to the application requirements. Contact your supplier if you have doubts about the best configuration. 2.2.1 How to Set Jumpers Jumpers are short-length conductors consisting of several metal pins with a non-conductive base mounted on the circuit board.

  • Page 21: Jumper & Connector Locations On Motherboard

    Program VCORE Connector (Factory used only) Program CPLD Connector (Factory used only) Front Panel Connector (Optional) Audio Line-In Connector Audio Line-Out Connector Power Button Connector (Optional) M.2 E-Key Connector M.2 M-Key Connector Power Button Connector Clear EDID Button Connector SE-103-N User Manual...
  • Page 22 Clear ME Register ATX / AT Power Select EDID Enable/Bypass Select 2.3.2 Clear CMOS Data (SW1-1) Function Setting Normal (default) P1-OFF Clear CMOS P1-ON Clear ME Register (SW1-2) 2.3.3 Function Setting Normal (default) P2-OFF Clear ME P2-ON SE-103-N User Manual...
  • Page 23 Hardware Configuration 2.3.4 ATX / AT Power Selection (JP1) Function Pin closed Illustration (default) 2.3.5 EDID Enable / Bypass Selection (JP2) Function Pin closed Illustration Enable (default) Bypass SE-103-N User Manual...
  • Page 24 2.3.6 DC 12V Power Input Connector (CN2) Pin Assignment Ground +12V 2.3.7 Digital I/O Connector (J2) Pin Assignment Pin Assignment Ground OUT3 OUT1 OUT2 OUT0 SE-103-N User Manual...
  • Page 25 Hardware Configuration 2.3.8 Pin Assignment for COM1 (CN10) Port  Signal Name RS-232 Ground SE-103-N User Manual...

  • Page 26: Chapter 3 Driver Installation

    Chapter 3 Driver Installation The information provided in this chapter includes: Intel® Chipset Software Installation Utility  VGA Driver Installation  HD Audio Driver Installation  Intel® ME Drivers Installation  ...

  • Page 27: Introduction

    INF files for Plug & Play function for Intel chipset components. 1. Insert the drivers disk enclosed in the package. Click Intel on the left pane and then Intel(R) Elkhartlake Chipset Drivers on the right pane. SE-103-N User Manual...
  • Page 28 Next to continue. 4. Accept the software license agreement and proceed with the installation process. 5. On the Readme File Information screen, click Install for installation. 6. After the installation, press Finish to complete the setup process. SE-103-N User Manual...

  • Page 29: Vga Driver Installation

    1. Insert the drivers disk enclosed in the package. Click Intel on the left pane and then Intel(R) Elkhartlake Chipset Drivers on the right pane. 2. Click Intel(R) Elkhartlake Graphics Driver. 3. On the following screen, click Begin Installation. SE-103-N User Manual...
  • Page 30 4. Click I agree to accept the license agreement. 5. After the installation has been completed, click Finish. SE-103-N User Manual...

  • Page 31: Hd Audio Driver Installation

    Intel(R) Elkhartlake Chipset Drivers on the right pane. 2. Click Realtek High Definition Audio Driver. 3. On the Welcome screen, click Next to continue. 4. When the InstallShield Wizard has successfully installed the Realtek Audio Driver, click Finish to complete the setup. SE-103-N User Manual...

  • Page 32: Intel® Me Drivers Installation

    3.5 Intel® ME Drivers Installation 1. Insert the drivers disk enclosed in the package. Click Intel on the left pane and then Intel(R) ME Drivers. 2. When the welcome screen to the Intel® Management Engine Components appears, click Next to continue. SE-103-N User Manual...
  • Page 33 Driver Installation 3. Accept the license agreement and click Next. 4. On the Setup’s Destination Folder screen, click Next to continue. 5. After the Intel® components have been completely installed, click Finish. SE-103-N User Manual...

  • Page 34: Observer Utility Installation

    1. Insert the driver disk enclosed in the package. Click Tools on the left pane and then Observer on the right pane. 2. Click Next to accept the detination folder, or click Browse to select a different folder. 3. Click Install on the next screen to begin installation. SE-103-N User Manual...

  • Page 35: Lan Drivers Installation

    3. On the next screen, clic, Install Drivers and Software. 4. In the welcome screen to the install wizard for Intel(R) Network Connections, click Next. 5. On the next screen, accept the terms in the license agreement and click Next. SE-103-N User Manual...
  • Page 36 6. In the Setup Options screen, click Next. 7. Click install to begin the installation. 8. Click Finish when Install wizard has completed. SE-103-N User Manual...

  • Page 37: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup This chapter describes the different settings available in the AMI BIOS. The topics covered in this chapter are as follows:  Main Settings  Advanced Settings  Chipset Settings  Security Settings  Boot Settings  Save &...

  • Page 38: Introduction

    These defaults have been carefully chosen by both AMI and the system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could make the system unstable and crash in some cases. SE-103-N User Manual...

  • Page 39: Main Settings

    Set the time. System Time Use the <Tab> key to switch between the data elements. 4.4 Advanced Settings This section allows the configuration of the system and the selection of the system features according to your preference. SE-103-N User Manual...
  • Page 40 4.4.1 CPU Configuration BIOS Setting Description When enabled, a VMM can utilize the Intel (VMX) Virtualization additional hardware capabilities provided by Technology Vanderpool Technology. SE-103-N User Manual...
  • Page 41 ME State Temporarily Disabled Mode. When disabled, AMT BIOS Features are no longer supported and user is no longer able to AMT BIOS Features access MEBx Setup. Note: This option does not disable Manageability Features in FW. SE-103-N User Manual...
  • Page 42 TPM 1.2 will restrict support to TPM 1.2 devices only. TPM 2.0 will restrict support to TPM 2.0 devices only. Device Select Auto will support both with the default being set to TPM 2.0 deices if not found, and TPM 1.2 device will be enumerated. SE-103-N User Manual...
  • Page 43 BIOS Setup 4.4.4 SMART Settings BIOS Setting Description Run SMART Self Test on all HDDS during SMART Self Test POST. SE-103-N User Manual...
  • Page 44 Sets parameters of Serial Port 2 (COMB). Serial Port Enable / Disable the serial port. Select an optimal setting for the Super IO device. Options are: IO=3F8h; IRQ=4; Change Settings IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; SE-103-N User Manual...
  • Page 45 BIOS Setup SE-103-N User Manual...
  • Page 46 Fintek Hardware Monitor BIOS Setting Description These fields are the parameters of the hardware monitoring function feature of the Temperatures / Voltages motherboard. The values are read-only values as monitored by the system and show the PC health status. SE-103-N User Manual...
  • Page 47 The maximum time the device will take before it properly reports itself to the Host Controller. Device power-up delay “Auto” uses default value for a Root port it is 100ms. But for a Hub port, the delay is taken from Hub descriptor. SE-103-N User Manual...
  • Page 48 SE-103-N User Manual...
  • Page 49 BIOS Setup 4.4.8 Network Stack Configuration BIOS Setting Description Network Stack Enables / Disables UEFI Network Stack. 4.4.9 NVMe Configuration SE-103-N User Manual...

  • Page 50: Chipset Settings

    BIOS Setting Description System Agent (SA) Configuration System Agent (SA) parameters PCH-IO Configuration PCH parameters 4.5.1 System Agent (SA) Configuration BIOS Setting Description Graphics Configuration Configures the graphics settings. VT-d Checks if VT-d function on MCH is supported. SE-103-N User Manual...
  • Page 51 Enables / Disables the integrated LAN to wake up the Enable system. Enables / Disables PS_ON support a new C10 state from the CPU on desktop SKUs that enables a lower power PS_ON Enable target that will be required by the California Energy commission (CEC). SE-103-N User Manual...
  • Page 52 Enables / Disables the SATA device. Controller(s) SATA Mode Determines how SATA controller(s) operate. Options: Selection AHCI / Intel RST Premium Serial ATA Enables / Disables serial ports. Ports SATA Ports Hot Enables / Disables SATA Ports HotPlug. Plug SE-103-N User Manual...

  • Page 53: Security Settings

    BIOS Setup 4.6 Security Settings BIOS Setting Description Administrator Sets an administrator password for the setup utility. Password User Password Sets a user password. Secure Boot Configures Secure Boot. SE-103-N User Manual...
  • Page 54 Restore Factory Forces system to user mode. Install factory default Keys Secure Boot key databases. Enables expert users to modify Secure Boot Policy Management variables without full authentication. SE-103-N User Manual...

  • Page 55: Boot Settings

    65535(0xFFFF) means indefinite waiting. Bootup Selects the keyboard NumLock state. NumLock State Quiet Boot Enables / Disables Quiet Boot option. Boot mode Selects a Boot mode, Legacy / UEFI. select Boot Option Sets the system boot order. Priorities SE-103-N User Manual...

  • Page 56: Save & Exit Settings

    Restores / Loads defaults values for all the setup Restore Defaults options. Save as User Saves the changes done so far as User Defaults. Defaults Restore User Restores the user defaults to all the setup options. Defaults SE-103-N User Manual...

  • Page 57: Appendix

    Appendix This section provides the mapping addresses of peripheral devices and the sample code of watchdog timer configuration.  I/O Port Address Map  Interrupt Request Lines (IRQ)

  • Page 58: I/O Port Address Map

    Standard SATA AHCI Controller 0x00003080-0x00003083 Standard SATA AHCI Controller 0x00003060-0x0000307F Standard SATA AHCI Controller 0x00000020-0x00000021 Programmable interrupt controller 0x00000024-0x00000025 Programmable interrupt controller 0x00000028-0x00000029 Programmable interrupt controller 0x0000002C-0x0000002D Programmable interrupt controller 0x00000030-0x00000031 Programmable interrupt controller 0x00000034-0x00000035 Programmable interrupt controller SE-103-N User Manual...
  • Page 59 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x00001854-0x00001857 Motherboard resources 0x00000000-0x00000CF7 PCI Express Root Complex 0x00000D00-0x0000FFFF PCI Express Root Complex 0x0000EFA0-0x0000EFBF Intel(R) SMBus Controller - 4B23 0x00002000-0x000020FE Motherboard resources 0x00000040-0x00000043 System timer 0x00000050-0x00000053 System timer SE-103-N User Manual...

  • Page 60: Interrupt Request Lines (Irq)

    Intel(R) Ethernet Controller (3) I225-IT IRQ 4294967288 Intel(R) Ethernet Controller (3) I225-IT IRQ 4294967287 Intel(R) Ethernet Controller (3) I225-IT IRQ 4294967286 Intel(R) Ethernet Controller (3) I225-IT IRQ 4294967285 Intel(R) Ethernet Controller (3) I225-IT IRQ 0 System timer SE-103-N User Manual...
