Scosche TerraClamp MAGICMOUNT PSM11015 Quick Start Manual

Triple clamp

PARTS INCLUDED

1. (1) Elastic Band

2. (1) *MAGICMOUNT

3. (1) 1.5" Extension Bar

4. (2) Adjustment Knobs w/ Washers

5. (2) Mounting Adapter Pairs

6. (1) Pivot Joint Bolt Mount

7. Includes 3 different different size bolts:

x 1.5mm x 55mm

x 1.5mm x 60mm

x 1.5mm x 65mm

*Caution: This magnetic mount is not a toy.

The small magnetics are harmful if swallowed. Keep

out of reach of children.

WARNING: Do not use the magnetic mount with

any hard-drive based devices such as iPod

classic, iPod video and Zume MP3 players.

TerraClamp

MAGICMOUNT

w/ Mounting Plates

™

TRIPLE CLAMP

™

PSM11015
