- Page 1 User Manual Model Number： CW12K0330 CW12F0327...
- Page 2 You need Tools required 1 person is needed A Phillips head scre wdriver is required for the assembly of this product.（not included） Power tools should not be used to assemble this product.
- Page 3 PRODUC T ASSEMBLY Hardware List Check the package contents before getting started ! STEP 1 530x598x15mm 525x495x15mm 525x495x15mm 885x545x15mm 4PCS 2PCS 2PCS 2PCS 885x545x15mm 860x526x15mm 496x45x15mm 866x516x3mm 2PCS 2PCS 15x12mm 8x30mm M6x35mm 20PCS 20PCS 2PCS 20PCS M3x12mm M3.5x12mm 12PCS 2PCS 2PCS 6PCS M4x18mm...
- Page 4 PRODUC T ASSEMBLY PRODUC T ASSEMBLY STEP 3 STEP 2 4PCS 4PCS 12PCS 2PCS 4PCS 4PCS Arrow Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board.
- Page 5 PRODUC T ASSEMBLY PRODUC T ASSEMBLY STEP 4 STEP 5 6PCS 6PCS 6PCS 6PCS Arrow Arrow Hole Hole The arrow in the HIDDEN CAM must point toward the The arrow in the HIDDEN hole in the edge of the board. CAM must point toward the hole in the edge of the board.
- Page 6 PRODUC T ASSEMBLY PRODUC T ASSEMBLY STEP 6 STEP 7 4PCS 20PCS 4PCS 4PCS Arrow Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board.
- Page 7 PRODUC T ASSEMBLY PRODUC T ASSEMBLY STEP 9 STEP 8 2PCS 6PCS 6PCS...
