House of lithium 50/50 User Manual

Hide thumbs

Advertisement

Quick Links

house of lithium
USER MANUAL
50/50

Advertisement

loading
Need help?

Need help?

Do you have a question about the 50/50 and is the answer not in the manual?

Questions and answers

Summary of Contents for House of lithium 50/50

  • Page 1 USER MANUAL 50/50...
  • Page 2 lithium...

  • Page 3: Table Of Contents

    CONTENTS Part 1 - Unboxing Pg. 1-5 Part 2 - Display Instructions Pg. 6-12 Part 3 - Common Problems and Solutions Pg. 13-15 Part 4 - Use and Maintenance Pg. 16-19 Part 5 - After Sales and Warrenty...

  • Page 4: Part 1 Unboxing

    Unboxing Part 1 The 50/50 ebike comes 95% assembled. Only three steps to Fold/Unfold: (1) Frame Unfolding Push the clamp to lock the frame solidly and make sure it is tight.
  • Page 5 (2) Handlebar Attach handlebars to the stem using a the 6mm allen key provided.
  • Page 6 (3) Pedal Unfold Rotate the pedal up until the pedal is fully engaged. Fold To fold the pedal, push it from the front first, and then rotate it downward.
  • Page 7 (4) Battery Removal and Charging When the charger light turns red, it means the battery is being charged; When the light turns green, it means the battery is fully charged. *Two ways to charge: 1. Remove the battery and charge.
  • Page 8 ( 6 ) Transmission System 1.This function can only be adjusted while pedaling. 2. Depress this lever to shift to a higher gear. 3.Depress this lever to shift to a lower gear.

  • Page 9: Part 2 - Display Instructions

    Display Instruction Part 2 ( I ) Display Interface...
  • Page 10 (1) Press the “i” buton to display different information. 1.Miles traveled 2. Total miles traveled 3. Maximum speed 4. Average speed 5.Total traveled time...
  • Page 11 (2) Driving Mode Switching 1. Eco Mode Activates at a slow speeds providing low acceleration (Low energy consumption). 2.Normal Mode Activates at a normal speeds providing normal acceleration (Normal energy consumption). 3.Sport Mode Activates at a high speeds providing high acceleration (Higher energy consumption).
  • Page 12 (3) Switching Walk-Assistance Mode On-Off 1.Walk-assistance function may only be used when you walking the ebike 2.To activate the walk-assistance function, press the “-” button for 2 s. 3.The walk-assistance function will be switched off as soon as you release the button.
  • Page 13 II INTRODUCTION OF COMMON FUNCTIONS T he f o llo w ing f u nc t io ns mu s t r e s t a r t t he dis pla y a f t e r s e t t ing t he ins t r u me nt t o ma k e e f f e c t .
  • Page 14 (2) Default Settings In case of the rider change the settings and then don`t remember the default settings, here are two images for reference. (3) Password Setting the energy consumption of the motor. 1.This setting means power-on password setting when you turn on the display.
  • Page 15 (4) Cruise Control Cruise Control is to ride your bike at a constant speed. Press the“i” button to access the CRU setting. Press the“+”or“-”button to turn “off” into “on” to activate the Cruise Control. Press the throttle at a constant speed you want for 5s.

  • Page 16: Part 3 - Common Problems And Solutions

    Common Problems Part 3 and Solutions The battery cannot be charged, the display shows an abnormal battery power. Use a multimeter to check if the battery still has voltage. Check if the charger indicator is normal. (Red light means charging, green light means fully charged) The battery case is damaged, stop using the battery and contact us.
  • Page 17 When an error code appears on the display. Error Code Definition Current Abnormality Throttle Abnormality Motor Abnormality Motor Hall Signal Abnormality Brake Abnormality Communication Abnormality l Error code 21 and 30 indicates controller problem. l Error code 25 indicates brake problem. Do following steps to...
  • Page 18 This is a normal phenomenon that occurs after a bicycle has been used for a period. Can people sit on the rack? The maximum load of the rack is 25kg. It is prohibited to sit on. Water leaks into the display.

  • Page 19: Part 4 Use And Maintenance

    Use and Maintenance Part 4 Ø Battery Maintenance ü Fully charge the battery for the first use. ü Do not use the battery in low power level. ü Must use the specified charger for charging. ü Do not charge the battery at high temperature (over 212 Fahrenheit/100°C).
  • Page 20 ü If it is a hydraulic brake, check regularly to see if there is any oil leakage. ü Clean the brake regularly. Ø Motor Maintenance ü Do not try to disassemble the motor. ü If there are any problems with the motor, contact HOL with a video.
  • Page 21 Common failures and check Ø Problem Possible reason Remedy ü 1. Battery voltage is too low. Make sure the battery is The speed adjuster 2. Speed adjusting handle connection fully charged doesn’t work or the ü may have become loose.
  • Page 22 The indicating light Turn to the supplier for The charger and the battery parameters doesn’t turn green, adjustment or replace the the battery becomes don't match. seriously hot charger. 1. If your problem is not listed above.

  • Page 23: Part 5 - After Sales And Warrenty

    Warranty After Sales Thanks for choosing House OF Lithium Electric Motor Sports. If you have any questions about our products, or would like to get the latest news and current deals from us, please feel free to follow us at: houseoflithium.com...
  • Page 24 Q & A 1. If there is something wrong with my electric bike, who should I contact? HOL: Take a video or some pictures, have the order detail information of the bicycle, and then contact customer service directly asap.
  • Page 25 Warranty The main parts of the warranty provisions Problems caused by Motor, Battery and Controller (Electricity System ) are all under 2 years warranty. Other Parts Warranty Check all the parts and make sure they are working perfectly, if there is any part which doesn`t work properly initially, contact HOL asap.
  • Page 26 The product has been in any accidents, such as traffic accidents The product has been in extreme environment (including extreme temperature or humidity), extreme physical or electrical stress or interference, fluctuation or surges of electrical power, lightning,...
  • Page 27 Do-It-Yourself (DIY) Parts Service. DIY Parts Service allows you to service your own product. If determines that DIY Parts Service is available to you, will ship to you a replacement part for your product. The replacement part will be accompanied by instructions on installation and any requirements for the return of the replaced part.
  • Page 28 House Of Lithium House Of Lithium...
