REQUIREMENTS FOR INSTALLATION
Place the exterior silica cartridge
Install the plastic tubing and the plastic cartridge containing the silica gel. It is
!
highly recommended to replace this cartridge after the drying cycle for the one
that was on the inside, ensuring the silica used is always dry.
Insert the tubing in the
plastic silica cartridge's
hole. Apply some
pressure.
Place the silica gel correctly
While unboxing, you will �ind two silica cartridge. For perfect installation, you
!
should place one silica cartridge on the chamber �loor. As detailed in the
previous section, you must replace the exterior cartridge with this one after
every drying cycle, ensuring the silica used is always dry.
Slide the cartridge and
hang it to the two binding
barrels that the Dryer has
on its side.
Silica gel cartridge
Finally, insert the tubing in
the connector on the left
lateral case.
