Summary of Contents for SUSZARNIE 44G75
- Page 1 SUSZARNIE.EU Jan&Przemysław Borowski Technical Documentation Operating Instructions Aerodynamic Container Wood Dryer 44G75 Model 02/22 Serial number : 18.02.2022 Production date...
-
Page 2: Table Of Contents
Table of contents 1. Health and safety at work................3 2.Description and purpose of the aerodynamic container wood dryer....4 3.Technical data....................5 4.Transportation and unloading................5 5.Workplace setting..................... 6 6.Connecting electrical and water systems............7 7.Loading the chamber with wood. -
Page 3: Health And Safety At Work
1. Health and safety at work. IT IS ABSOLUTELY FORBIDDEN: RUN THE DRYER WHEN PEOPLE ARE INSIDE RUN THE DRYER IF THE DOOR IS INCORRECTLY CLOSED TO OPERATE THE DRYER BY A PERSON OTHER THAN THE OPERATOR TRAINED BY THE MANUFACTURER USE THE DRYER IN CASE OF ANY FAILURE MAKE ANY MODIFICATIONS TO THE DRYER USE THE DRYER FOR PURPOSES OTHER THAN DRYING RAW WOOD... -
Page 4: Description And Purpose Of The Aerodynamic Container Wood Dryer
2. Description and purpose of the aerodynamic container wood dryer. Aerodynamic container wood dryers are powered solely by electricity, they do not require an external heat source: water, air or steam. They do not have electric heaters or heaters. The source of heat is the work of the turbine (fan). By compressing and expanding air molecules, the turbine increases the temperature and ensures air circulation and removal of excess moisture from the chamber. -
Page 5: Technical Data
3. Technical data. External dimensions: length: 6,30 m, width: 2,65 m, height: 2,25 m. Dimensions of dried material: length: 4,40 m, width: 2,14 m, height: 1,65 m. Dryer capacity: 15,5 m Maximum permissible temperature: 70 Power supply: 3 x 400V 50 Hz; Total power consumption: 7,5 kW;... -
Page 6: Workplace Setting
5. Workplace setting. The place where the dryer works can be under a roof or in an open area because, as mentioned above, the dryer is fully weatherproof. In winter you should pay attention to the snow lying on the roof, which in excess can cause damage. It is worth considering placing the dryer under a shed, which will provide convenient loading and unloading of lumber during snow or rain and will also be useful for seasoning wood. -
Page 7: Connecting Electrical And Water Systems
6. Connecting electrical and water systems. Connecting the dryer to the power grid (TN-S type) must be performed by a person with appropriate rights. A five-core copper wire of appropriately selected cross-section should be used for this. The cross-section depends on the installed power and on the length of the cable and is specified by appropriate standards. - Page 8 Before stacking timber on timber trolleys it is necessary to check that the wheels on the trolleys run freely and without resistance and to remove loose timber (bark, sawdust, shavings, knots, etc.) from the rails and the inrun. When placing timber on the carts, the carts must be secured against rolling.
- Page 9 The most important rules related to filling the chamber with material: A sufficiently large distance must be maintained between boards or elements made of wood (pallets, wooden packaging). The ideal situation is when the door "sees" the back wall where the turbine system is located. This ensures a free flow of air. If the dryer is loaded too tightly, the turbine will not receive the right amount of air, which in turn will cause limited temperature rise and insufficient air circulation between the materials, lumber or other wooden elements must form an even wall with equal distances between...
-
Page 10: Service
8. Service. BEFORE STARTING THE DRYER WITH THE SWITCH LOCATED ON THE CASING OF THE ELECTRICAL SWITCHBOARD IT IS NECESSARY TO MAKE SURE THAT THERE IS NO PERSON IN THE CHAMBER! Before starting the drying cycle, when starting the motor for the first time, it is essential to check that: the turbine spins freely during acceleration without any unnecessary noise, friction, etc, The engine cooling fan is working properly,... -
Page 11: Maintenance And Technical Inspection
type B. The task of the "differential" is to protect against unwanted leakage of current - an electric shock. In turn, the overcurrent fuse protects devices inside the electrical switchboard and the double 230V socket mounted outside the switchboard on the right side. The maximum power of devices connected to this socket must not exceed 1 kW (1000 W). - Page 12 Below is a table where you can get answers to frequently asked questions: Problem Cause / solution the door opens and properly level the front part of the dryer (door frame) by appropriately closes with great raising or lowering one of the sides; resistance grease the hinges, locking sockets;...
-
Page 13: Schematic And Electrical Equipment
10. Schematic and electrical equipment. The electrical equipment is shown in the table below: Designation on the Name / function Manufacturer / type diagram Main switch ABB OT40FT3 (40A) Motor circuit breaker ABB MS 132 (10-16 A) Residual current circuit breaker ABB FH204 AC (40/0,03 A) Overcurrent circuit breaker ABB S201-B6 (6 A) -
Page 15: Guarantee Card Of The Dryer
11. Guarantee card of the dryer. Serial Number: 02/22 Model: 44G75 Warranty Terms: 1) The manufacturer provides a warranty for a period of 12 months from the date specified in the warranty card. 2) The warranty covers all elements of the supplied equipment with accessories, excluding consumables subject to wear during normal operation. -
Page 16: Endorsements For Mandatory Annual Inspection
12. Endorsements for mandatory annual inspection. Date of Activities performed during the review: Stamp and signature of implementat the Manufacturer Execute 02.2023 02.2024 02.2025 02.2026 02.2027... -
Page 17: Ec Declaration Of Conformity
PPUH PRZEMYSŁAW BOROWSKI 32-566 ALWERNIA 16A B. PRUSA street NIP: 6282140464 declares that the product: AERODYNAMIC CONTAINER WOOD DRYER Model: 44G75 Serial Number: 02/22 meets the requirements of the following harmonised standards: PN-EN ISO 12100:2012, PN-EN ISO 12857:2008, PN-EN 953+A1:2009,...
