Operating Instructions • Warning Information
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry
products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this
type of work. To reduce your exposure to these chemicals: work in a well
ventilated area, and work with approved safety equipment, such as those
dust masks that are specially designed to filter out microscopic particles.
SPECIFICATIONS
Blows per Minute . . . . . . . . . . . . . . . . . . . . . . . . . . 4,500 BPM
Stroke Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.5"
Number of Needles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Piston Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1"
Air Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1/4" NPT
Minimum Hose Size. . . . . . . . . . . . . . . . . . . . . . . . . . . 3/8" I.D.
Recommended Air Pressure . . . . . . . . . . . . . . . . . . . . . 90 psig
Average Air Consumption . . . . . . . . . . . . . . . . . . . . . . . . 6 CFM
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18.3"
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.2 Lbs
Sound Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99.5 dBA
CAT125
• Parts Breakdown
WARNING
• MaxiMuM BPM of 4,500
• Max. aiR PRESSuRE:
90 PSIg, 6.2 BAR
ALWAYS ReAD
INSTRuCTIoNS BeFoRe
uSINg PoWeR TooLS
ALWAYS WeAR
SAFeTY goggLeS
ALWAYS WeAR FACe
PRoTeCTIoN
ALWAYS WeAR HeARINg
PRoTeCTIoN
ALWAYS WeAR HAND
PRoTeCTIoN
AvoID PRoLoNgeD
exPoSuRe To vIBRATIoN
RATeD RPM oF THe
ACCeSSoRY MuST
RPM
RPM
RPM
exCeeD THe MAxIMuM
TooL RPM SHoWN
CAT125
Needle Scaler
Copyright © Professional Tool Products, 2014
All rights reserved
11/21/14
Advertisement
Table of Contents
Related Manuals for Cornwell Tools CAT125
Summary of Contents for Cornwell Tools CAT125
- Page 1 Minimum Hose Size......3/8" I.D. CAT125 Recommended Air Pressure ..... 90 psig Average Air Consumption .
- Page 2 • use accessories rated at 4,500 BPM or more. • Operation can cause impacts, cuts, abrasions and heat. Wear gloves to protect hands. • use accessories recommended by Cornwell Tools. • Keep the tool in ef f i c ient op e r a t i ng con d i t ion. • Never use dull, chipped or damaged accessories.
- Page 3 PARTS BREAKDOWN - CAT125 Ref. # Item # DeSCRIPTIoN Ref. # Item # DeSCRIPTIoN 32 RS37932 Front Valve Block RS37901 Back Head 33 RS37933 Piston RS37902 O-Ring 35 RS37935 Barrel Sleeve RS37903 Throttle Valve 36 RS37936 Nose 3-1 RS379031 O-Ring RS37904 Spring 37 RS37937 Key RS37905 O-Ring (8 x 2.5)
- Page 4 THIS WARRANTY AND THE REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. CORNWELL SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, TO THE EXTENT PERMITTED BY APPLICABLE LAW, ANY WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IF CORNWELL CANNOT LAWFULLY DISCLAIM IMPLIED WARRANTIES UNDER THIS LIMITED WARRANTY, ALL SUCH IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. IN NO EVENT SHALL CORNWELL BE LIABLE TO THE PURCHASER OR TO THE USER OF A CORNWELL PRODUCT FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES BASED UPON BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLIGENCE, TORT, OR ANY OTHER LEGAL THEORY. SUCH DAMAGES INCLUDE, WITHOUT LIMITATION, EXPENSES, LOST REVENUES, LOST SAVINGS, LOST PROFITS, OR ANY OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE PURCHASE, USE OR INABILITY TO USE THE CORNWELL PRODUCT. Some states do not allow the exclusion or limitation of incidental or consequential damages or exclusions or limitation on the duration of implied warranties or conditions, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary by state. Repair kits and replacement parts are available for many Cornwell products, regardless of whether or not the product is still covered by a warranty plan. CAT125 11/21/14...
