Fabric XL
User Guide
English
Manual Version 1.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Fabric XL and is the answer not in the manual?

Questions and answers

Related Manuals for Air Fabric XL

Summary of Contents for Air Fabric XL

  • Page 1 Fabric XL User Guide English Manual Version 1.1...

  • Page 2: Installation

    Introduction Thank you for purchasing the AIR Fabric XL plugin instrument. Fabric XL is the brand-new flagship sample-based synthesizer from AIR Music Technology and delivers the ultimate sounds for all your production needs. Fabric XL brings a stunning collection of cutting-edge presets, including everything from twisted and dark motion pads, drone and sub-basses, acoustic and electric guitars, acoustic and electric pianos, classic poly and lead synths, and much more.

  • Page 3: Operation

    Operation Overview Setup Section View Toggles, Main Vol Perform Controls Layers Controls...
  • Page 4 Effects Controls Settings...

  • Page 5: Setup Section

    Setup Section 1. Keyboard: Click this icon to enable or disable the virtual keyboard. When enabled, you can click these keys to input notes, or view notes being played on an external MIDI device. 2. Tempo: Displays the current plugin tempo. To change the tempo: •...
  • Page 6 Perform All settings in this view except Delay On/Off and Reverb On/Off are available in all other plugin views. Parameter Description Value Range Main Vol Overall level of the plugin. -inf – 0.0 – +6.0 dB Layer 1/2 Enable or disable the layer. Off, On Volume Level of the layer.
  • Page 7 Layers Layer Controls Parameter Description Value Range Layer 1/2 Click the power button to enable or disable Off, On the selected layer. Sample Start Starting point of the selected sample. 0–100% Key Low Set the lowest key for the layer key range. C-2 –...
  • Page 8 Parameter Description Value Range Level of the layer. -inf – 0.0 – +12.0 dB Spike Applies additional velocity to the amplitude 0–100% attack. Spike Length Length of time for the Spike to decay. 0–100% Stereo panning of the layer. L64 -- - C -- - R64 Pan Keytrack Ties the stereo panning to the pitch being -100 –...
  • Page 9 Envelopes Click the Amp Env, Filter Env, or Pitch Env buttons to view the selected envelope. Click the Edit button to view and edit the selected envelope parameters. You can also click and drag the envelope points directly. Parameter Description Value Range Attack Length of time for the sound to reach full...
  • Page 10 Envelopes (continued) Parameter Description Value Range Filter Attack Length of time for the filter to reach full level. 0 ms – 32 s Envelope Decay Length of time for the filter to reach sustain 0 ms – 32 s level. Sustain Level of the filter while the note is held.
  • Page 11 Envelopes (continued) Parameter Description Value Range Pitch Level 1 -100 – 0 – +100% Pitch level (relative to the Env Depth) at the Envelope start of the note. Delay Length of time to reach Level 2. 0 ms – 32 s Level 2 Pitch level (relative to the Env Depth) at the -100 –...
  • Page 12 Parameter Description Value Range Mode Waveshape of the low frequency oscillator. Off, Constant, Sine, Triangle, Sawtooth, Square, S+H Random, S+H Alternate, Random Drift, Slow Drift Sync Disable or enable and select how the LFO is Off, First Note, Each Note, synced to the global tempo.
  • Page 13 Percussion Parameter Description Value Range Percussion Click the power button to enable or disable Off, On percussion sample. Sample Select the percussion sample used. Varies Trigger Selects when the percussion sample is Note-On, Note-Off triggered. Octave Adjust pitch of the percussion sample. -4 –...
  • Page 14 Effects Parameter Description Value Range Chorus Use the button in the upper-left corner to enable or Off, On disable the chorus effect. Rate Modulation speed of the chorus effect. 0.05 – 20.00 Hz Wet/dry amount of the chorus effect. 0–100% Tremolo Use the button in the upper-left corner of this section Off, On...
  • Page 15 Effects (continued) Parameter Description Value Range Flavor Use the button in the upper-left corner of this Off, On section to enable or disable the flavor effect. Timbre Selects an emulation type to color the sound. Varies Timbre Depth Amount of timbre emulation applied to the sound. 0–100% Vinyl Distortion Amount of vinyl distortion noise applied to the 0–100%...
  • Page 16 Effects (continued) Parameter Description Value Range Compressor Use the button in the upper-left corner of this section to enable or disable the compressor. Threshold Signal level after which the compression will be -30.0 – 0.0 – +10.0 dB applied. Ratio Amount of compression applied.
  • Page 17 Settings Parameter Description Value Range Global Transpose Transposition of the plugin, in semitones. -36 – 0 – +36 Tune Fine tuning of the plugin, in cents. -100 – 0 – +100 Pitch Bend Number of semitones up or down controlled by MIDI 0–24 (semitones) Range pitch bend messages.
  • Page 18 Settings (continued) Parameter Description Value Range Expression Destination Send Expression data to one of the following control Pitch, Cutoff, Reso, destinations. Amp, Pan Depth Amount of modulation applied. 0–100% When Destination is set to Pitch: -12.0 – +12.0 When Destination is set to Cutoff, Reso, Amp or Pan: -100 – 0 – 100% Ties the modulation to the Control LFO.

  • Page 19: Trademarks And Licenses

    Trademarks and Licenses AIR Music Technology is a trademark of inMusic Brands, Inc., registered in the U.S. and other countries. macOS is a trademark of Apple Inc., registered in the U.S. and other countries. Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
