- Page 2 HomePlay Network Player HDL-MZBOX-A50B.30...
- Page 3 Controlled via an IOS / Android app, or a wall mounted HDL user interface, HomePlay allows you to manage the entirety of your audio collection from a single point, and stream audio directly from your favorite online providers.
- Page 4 1. Multi format support(Capable of playing MP3, WMA, AAC, AAC+, ALAC, FLAC, APE, and WAV file formats). 2. High fidelity audio streaming. 3. Simultaneous multi source multi room streaming 4. Simultaneous single source multi room streaming. 5. Fully compatible with HDL room scenes and sequences. www.hdlautomation.com...
- Page 5 Wired Connection: 1-Connect the HomePlay network player and the router with RJ45 cable. 2- Connect the phone to the same router which is connected to the HomePlay network player. HomePlay 3-Configure the HomePlay network player Speaker with HDL ON APP. www.hdlautomation.com...
- Page 6 Wireless Connection: 1-Connect the device running the HDL On app to your router. 2-Open the HDL ON APP on your iOS or Android device, input the Wi-Fi name and password, and click next step. 3-Press the WPS button of the HomePlay network player, then it will connect to the corresponding Wi-Fi automatically.
- Page 7 KNX Setting Connection: If you want to control the HomePlay network player by KNX panel, the HomePlay network and the KNX panel should connect to the same router. For the connection, please refer to the following wiring diagram. www.hdlautomation.com...
- Page 8 KNX Setting Now for the HomePlay network player, KNX panel can control it to play/ stop, pause, audio mute, select song and adjust volume . Play/stop: Add a group address for it, the length is 1 bit, ON command is for play, OFF command is for stop.
- Page 9 Setting Test: You can test the function of play, stop, previous song, next song, volume+ and volume- www.hdlautomation.com...
- Page 10 DLP Setting In order to control the HomePlay network player with DLP, we need to configure the DLP Music page setting of DLP: Enable the HomePlay network player, select Z-Audio mode, Zone NO.1, and set the subnet ID and device ID. After that, you control the HomePlay network player with DLP panel. About the source of the HomePlay network player, we can select USB, NAS, AUDIO-IN and Bluetooth from DLP.
- Page 11 HDL ON Setting In order to control the HomePlay network player by HDL ON, we need to set HDL ON. Search HomePlay network player with HDL ON: After connecting the Android/iOS device and the HomePlay network player to the same router, run HDL ON APP, click music icon to enter music page.
-
Page 12: Party Mode
When there are several HomePlay network players in the system, if we want to all HomePlay network players play music synchronously, party mode can achieve to this function. 1. Run HDL ON APP, click music icon to enter music page. www.hdlautomation.com... - Page 13 Party mode 2. Drag one HomePlay network player to the other HomePlay network player position, then finish the configuration of party mode. In the party mode, the slave player will follow the master player to play the same music. www.hdlautomation.com...
- Page 14 Party mode 3. Click the dissolved group button of the master player, then you can dissolve all the players in the group; if you click the dissolved group button of the slave player, you can dissolve the current player from the group.
- Page 15 Serious about smart buildings.
