Notice
CORRECTION
SERVICE FLASH
Please add this notice to the Service Manual listed below.
Category :
Multi-media Projector
Model :
Canada, U.S./Europe,
Destination :
NOTE: Match the Chassis No. on the unit's back cover with the Chassis No. in the Service
Manual.
If the Chassis. No. does not match the unit's, additional Service Literature is required.
Only the difference service information is given in this manual. For detailed service infor-
mation, refer to the original service manual SM5110516-00, issued in September 2003,
for Model PLC-XU50.
Differences:
The outline of the differences are as follows;
- The LCD panels are changed.
According to the above, the main board, electrical adjustment, service data table and diagrams are
changed.
FILE WITH ORIGINAL SERVICE MANUAL (SM5110516)
PRODUCT CODE
1 122 213 40
(MW3AY)
1 122 214 40
(PW3AY)
1 122 214 42
(PW3CY)
●
PRODUCTION CHANGE
ADD INFORMATION
PLC-XU50
Asia, Africa, U.K.
Issued Date :
Chassis No.
Effective from :
REF. NO. :
FILE NO.
REVISION-7
July / 2004
MW3-XU5003
SM5110516
SM
REFERENCE NO.
5110516-07

Advertisement

Table of Contents
loading

Related Manuals for Sanyo PLC-XU50

Summary of Contents for Sanyo PLC-XU50

  • Page 1 If the Chassis. No. does not match the unit’s, additional Service Literature is required. Only the difference service information is given in this manual. For detailed service infor- mation, refer to the original service manual SM5110516-00, issued in September 2003, for Model PLC-XU50. Differences: The outline of the differences are as follows;...

  • Page 2: Safety Precautions

    ■ Safety Instructions SAFETY PRECAUTIONS WARNING: The chassis of this projector is isolated (COLD) from AC line by using the converter transformer. Primary side of the converter and lamp power supply unit circuit is connected to the AC line and it is hot, which hot circuit is iden- tified with the line ( ) in the schematic diagram.
  • Page 3 ■ Specifications Projector Type Multi-media Projector Dimensions (W x H x D) 11.73" x 2.8" x 8.58" (298mm x 71mm x 218mm) (not including raised portions) Net Weight 6.2 lbs (2.8 kg) LCD Panel System 0.8" TFT Active Matrix type, 3 panels Panel Resolution 1024 x 768 dots Number of Pixels...
  • Page 4 ■ Circuit Protections This projector provides the following circuit protections to operate in safety. If the abnormality occurs inside the pro- jector, it will automatically turn off by operating one of the following protection circuits. ● Fuse Fuse A fuse is located inside of the projector. When the POWER indica- tor is not lightning, the fuse may be opened.

  • Page 5: Air Filter Care And Cleaning

    Circuit Protections ● Warning temperature and power failure protection The projector will be automatically turned off when the internal temperature of the projector is abnormally high, or the cooling fans stop spinning, or the power supplies in the projector are failed. - If the WARNING indicator is flashing, it may detect the abnormal temperature inside the projector.

  • Page 6: Order Replacement Lamp

    ■ Lamp Replacement WARNING: ORDER REPLACEMENT LAMP - For continued safety, replace with a lamp assembly of the same Type No. Service Parts No. type. POA-LMP65 610 307 7925 - Allow the projector to cool for at least 45 minutes before you open the lamp cover.

  • Page 7: To Enter The Service Mode

    ■ Electrical Adjustments ● Service Adjustment Menu Operation To enter the service mode To enter the “Service Mode”, press and hold the MENU and INPUT buttons on the projector at the same time for more than 3 seconds. The service menu appears on the screen as follows. To adjust service data Select the adjustment group no.

  • Page 8: Circuit Adjustments

    Electrical Adjustments ● Circuit Adjustments CAUTION: The each circuit has been made by the fine adjustment at factory. Do not attempt to adjust the follow- ing adjustments except requiring the readjustments in servicing otherwise it may cause loss of per- formance and product safety.

  • Page 9: Clamp Adjustment [Pc]

    Electrical Adjustments Clamp adjustment [PC] Clamp adjustment [COMPONENT] 1. Receive the 16-step grey scale computer signal with 1. Receive the 16-step grey scale component signal Computer2 [RGB] mode. with Computer2 [Component] mode. 2. Enter the service mode. 2. Enter the service mode. TPG1 TPG1 3.
  • Page 10 Electrical Adjustments Sub Gain adjustment [PC] Video Center adjustment 1. Receive the 16-step grey scale computer signal with 1. Receive the 16-step grey scale computer signal with Computer2 [RGB] mode. Computer2 [RGB] mode. 2. Enter the service mode. 2. Enter the service mode TPG1 TPG1 3.

  • Page 11: Note On White Uniformity Adjustment

    Electrical Adjustments ⁄1 Black Reference adjustment Gamma adjustment 1. Receive the 16-step grey scale computer signal with [PC-GAMMA ADJUSTMENT] Computer2 [RGB] mode. 1. Receive the 16-step grey scale computer signal with 2. Enter the service mode. Computer2 [RGB] mode. TPG1 3.

  • Page 12: Test Points And Locations

    Electrical Adjustments ● Test Points and Locations MAIN BOARD IC1851 IC5351 -12-...
  • Page 13 Electrical Adjustments ● Service Adjustment Data Table These initial values are the reference data written from the CPU ROM to memory IC when replaced new memory IC. The adjust- ment items indicated with “✻” are required to readjust following to the “Electrical adjustments”. Other items should be used with the initial data value.
  • Page 14 Electrical Adjustments Adjustment Item Initial Value Range Input source / Description ✻ Gamma Adjustment G_GAM_BRT 0/0/0/0 0 ~ 2047 [Addr:0x2030-2031] Signed 11bit Ignore lower 2bit PC/AV/DVI/HDCP ✻ White Balance Adjustment R_GAM_BRT 0/0/0/0 0 ~ 2047 [Addr:0x202E-202F] Signed 11bit Ignore lower 2bit PC/AV/DVI/HDCP ✻...
  • Page 15 Electrical Adjustments Adjustment Item Initial Value Range Input source / Description Group 100 H8 Option Lamp Time Monitor 0~8738 Read Only RS232C Baudrate 0 ~ 1 0: 19200bps1: 9600bps Cooling Time 1 ~ 15 Cooling time1:30 sec.3:90 sec.15:450 sec. Hi-Land SW 0 ~ 3 0: Normal Mode1~3: High-Land Mode 1-3 Lamp Total Time...
  • Page 16 Electrical Adjustments Adjustment Item Initial Value Range Input source / Description ECO_VALU_FAN1_MIN 70/70 Minimum Control Value for FAN1 at Eco Mode ECO_VALU_FAN1_MAX 135/135 Maximum Control Value for FAN1 at Eco Mode ECO_VALU_FAN2_MIN 85/85 0~255 Minimum Control Value for FAN2 at Eco Mode ECO_VALU_FAN2_MAX 130/130 Maximum Control Value for FAN2 at Eco Mode...
  • Page 17 Electrical Adjustments Adjustment Item Initial Value Range Input source / Description L1 HIMOTHR 0 ~ 16 L1 LWMOTHR 0 ~ 16 L2 LWDIFFTH 0 ~ 255 L2 Still picture L2 HIDIFFTH 0 ~ 255 L2 HIMOTHR 0 ~ 16 L2 LWMOTHR 0 ~ 16 Group: 301 Color Gain AV Color...
  • Page 18 Electrical Adjustments Adjustment Item Initial Value Range Input source / Description Group: 514 HDTV 575p Gakaku (Component) HDTV TOTAL DOTS 1253 0 ~ 4096 HDTV DISP DOTS 0 ~ 4096 HDTV H BACK PORCTH 0 ~ 4096 HDTV V BACK PORCTH 0 ~ 4096 HDTV DISP LINE 0 ~ 4096...
  • Page 19 Electrical Adjustments Adjustment Item Initial Value Range Input source / Description RGB H BACK PORCTH 0 ~ 4096 RGB V BACK PORCTH 0 ~ 4096 RGB DISP LINE 0 ~ 4096 RGB CLAMP 0 ~ 127 RGB WIDTH 0 ~ 63 Group: 524 RGB 575p Gakaku RGB TOTAL DOTS 1385...
  • Page 20 ■ Electrical Parts List MW3-XU5003 Product safety should be considered when a component replacement is made in any area of a projector. Components indicated by a ! mark in this parts list and the circuit diagram show components whose value have spe- cial significance to product safety.
  • Page 21 MW3-XU5003 Electrical Parts List Note: Parts order must contain Chassis No., Part No., and Descriptions. ● OUT OF CIRCUIT BOARD R/C Board F601 Main Board Fuse Power Board AV Board A901 DVI Board Ballast Board Lamp Cover SW Board FN904 Cooling Fan(R) FN905 Cooling Fan(G)
  • Page 22 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description 405 015 8724 TR 2SC2812-L6-TB ASSEMBLIED BOARDS 405 015 8922 TR 2SC2812-L7-TB 405 163 1612 TR 2SC2812N-L6-TB0 610 306 7261 ASSY,PWB,AV MA7A 405 163 1711 TR 2SC2812N-L7-TB0 610 306 7278 ASSY,PWB,DVI MA7A 405 173 9813 TR 2SC3928A1R...
  • Page 23 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description 405 173 9912 TR 2SC3928A1S 405 163 1612 TR 2SC2812N-L6-TB0 Q221 405 134 5925 TR 2SA1037AK-T146-R 405 163 1711 TR 2SC2812N-L7-TB0 405 147 2215 TR 2SA1037AK-S-T146 405 173 9813 TR 2SC3928A1R 405 002 0318...
  • Page 24 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C5002 403 323 8815 CERAMIC 2.2U Z R2001 401 105 7919 MT-GLAZE 0.000 ZA 1/16W C5041 403 323 8815 CERAMIC 2.2U Z R2004 401 113 4412 MT-GLAZE 75 JA 1/16W C5042...

  • Page 25: Dvi Board

    MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R5034 401 105 2914 MT-GLAZE 22K JA 1/16W D1041 407 187 8219 ZENER DIODE UDZ12B-TE-17 R5037 401 105 0514 MT-GLAZE 1K JA 1/16W 407 221 7116 ZENER DIODE UDZS-TE-1712B R5041 401 105 0316...
  • Page 26 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description TRANSISTOR R1096 401 105 5212 MT-GLAZE 470 JA 1/16W R1097 401 105 5212 MT-GLAZE 470 JA 1/16W Q3071 405 134 5925 TR 2SA1037AK-T146-R R1098 401 105 5212 MT-GLAZE 470 JA 1/16W 405 147 2215...
  • Page 27 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description 405 015 8922 TR 2SC2812-L7-TB 405 163 1612 TR 2SC2812N-L6-TB0 RC BOARD 405 163 1711 TR 2SC2812N-L7-TB0 405 173 9813 TR 2SC3928A1R 610 309 3659 ASSY,PWB,RC MT3A 405 173 9912 TR 2SC3928A1S Q1371...
  • Page 28 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description Q2117 405 014 4519 TR 2SC2412K T146 R 405 173 9912 TR 2SC3928A1S 405 014 4618 TR 2SC2412K T146 S Q3115 405 134 5925 TR 2SA1037AK-T146-R 405 015 8724 TR 2SC2812-L6-TB 405 147 2215...
  • Page 29 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description Q3181 405 014 4519 TR 2SC2412K T146 R 405 173 9813 TR 2SC3928A1R 405 014 4618 TR 2SC2412K T146 S 405 173 9912 TR 2SC3928A1S 405 015 8724 TR 2SC2812-L6-TB Q5307 405 134 5925...
  • Page 30 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description 405 015 8724 TR 2SC2812-L6-TB 405 014 4618 TR 2SC2412K T146 S 405 015 8922 TR 2SC2812-L7-TB 405 015 8724 TR 2SC2812-L6-TB 405 163 1612 TR 2SC2812N-L6-TB0 405 015 8922 TR 2SC2812-L7-TB 405 163 1711...
  • Page 31 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description IC2322 410 362 6501 IC TC74LCX541FT C1238 403 155 1619 CERAMIC 33P J IC2323 410 346 8804 IC TC74LCX574FT C1239 403 155 1619 CERAMIC 33P J IC2324 410 346 8804 IC TC74LCX574FT...
  • Page 32 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C2113 403 304 2115 ELECT 47U M 6.3V C2509 403 175 3310 ELECT 47U M C2114 403 164 0234 CERAMIC 0.1U Z C2531 403 157 3611 CERAMIC 100P J C2116...
  • Page 33 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C313 403 164 0234 CERAMIC 0.1U Z C428 403 304 2115 ELECT 47U M 6.3V C3131 403 284 4314 CERAMIC 0.022U K C429 403 304 2115 ELECT 47U M 6.3V...
  • Page 34 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C5354 403 321 7414 ELECT 100U M C6661 403 347 5517 POS-SOLID 470U M C5356 403 164 0234 CERAMIC 0.1U Z C6664 403 349 4716 ELECT 220U M 6.3V C5359...
  • Page 35 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C9882 403 164 0234 CERAMIC 0.1U Z R1392 401 105 0613 MT-GLAZE 10K JA 1/16W R1396 401 105 7919 MT-GLAZE 0.000 ZA 1/16W RESISTOR R1397 401 105 7919 MT-GLAZE 0.000 ZA 1/16W R1201...
  • Page 36 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R1881 401 105 0415 MT-GLAZE 100 JA 1/16W R2319 401 105 7919 MT-GLAZE 0.000 ZA 1/16W R1882 401 105 0415 MT-GLAZE 100 JA 1/16W R2321 401 105 7919 MT-GLAZE 0.000 ZA 1/16W R1883...
  • Page 37 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R2467 401 105 7919 MT-GLAZE 0.000 ZA 1/16W R3139 401 105 0514 MT-GLAZE 1K JA 1/16W R2469 401 105 7216 MT-GLAZE 82 JA 1/16W R314 401 105 0613 MT-GLAZE 10K JA 1/16W R2471...
  • Page 38 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R3871 401 105 3218 MT-GLAZE 270 JA 1/16W R514 401 105 0316 MT-GLAZE 10 JA 1/16W R3872 401 105 0514 MT-GLAZE 1K JA 1/16W R517 401 105 0514 MT-GLAZE 1K JA 1/16W R3873...
  • Page 39 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R542 401 105 7919 MT-GLAZE 0.000 ZA 1/16W R673 401 230 4715 MT-GLAZE 680 JA R544 401 105 0316 MT-GLAZE 10 JA 1/16W R674 401 105 8015 MT-GLAZE 1M JA 1/16W R547...
  • Page 40 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R692 401 105 0712 MT-GLAZE 100K JA 1/16W R847 401 105 0613 MT-GLAZE 10K JA 1/16W R695 401 225 4614 MT-GLAZE 1.2 JA R848 401 105 4017 MT-GLAZE 330 JA 1/16W R697...
  • Page 41 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description RB402 645 034 5050 R-NETWORK 22X4 1/32W DIODE 645 037 0823 R-NETWORK 22X4 1/32W D1281 407 149 0817 DIODE 1SS355-TE-17 RB403 645 034 5050 R-NETWORK 22X4 1/32W D2451 407 149 0817 DIODE 1SS355-TE-17...

  • Page 42: Power Board

    MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description D8122 407 149 0817 DIODE 1SS355-TE-17 405 163 1711 TR 2SC2812N-L7-TB0 D856 407 149 0817 DIODE 1SS355-TE-17 405 173 9813 TR 2SC3928A1R D857 407 149 0817 DIODE 1SS355-TE-17 405 173 9912 TR 2SC3928A1S...
  • Page 43 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description L612 645 062 3561 INDUCTOR,900U R601 401 287 5710 MT-GLAZE 220K JA L694 645 059 2065 INDUCTOR,10U K R611 402 088 0109 RESISTER 0.15 KA R612 402 088 0109 RESISTER 0.15 KA...
  • Page 44 MW3-XU5003 Electrical Parts List Key No. Part No. Description Key No. Part No. Description -44-...
  • Page 45 ■ Mechanical Parts List MW3-XU5003 Note: Parts order must contain Chassis No., Part No., and Descriptions. ● Cabinet Parts -45-...
  • Page 46 MW3-XU5003 Mechanical Parts List ● Optical Parts (Integrator-in) (Relay-out) -46-...
  • Page 47 MW3-XU5003 Mechanical Parts List (Polarized-in-R) (Polarized-in-G) (Polarized-in-B) (Projection) -47-...
  • Page 48 MW3-XU5003 Mechanical Parts List L2-d L2-b L2-e L2-c L2-a (Prism/LCD panel Ass'y) -48-...
  • Page 49 MW3-XU5003 Mechanical Parts List -49-...

  • Page 50: Cabinet Parts

    610 307 8120 PANEL AV-MA7A 645 065 8754 LENS,PROJECTION 610 308 0116 SHIELD GR-MA7A 645 061 5450 LENS,INTEGRATOR(IN) 645 047 8031 BADGE,SANYO*26.2X5.7L26.0 645 061 5467 LENS,INTEGRATOR(OUT) 610 289 1812 BADGE V MARK S-MK6A 645 061 5559 MIRROR(B) 645 067 8950 MIRROR(B)
  • Page 51 MW3-XU5003 -51-...
  • Page 52 SANYO Electric Co., Ltd. (MW3AY) Jul. 2004 BB 400 Printed in Japan...

  • Page 53: Schematic Diagrams Printed Wiring Board Drawings

    PLC-XU50 MW3-XU5003 These schematic diagrams and printed wiring board drawings are part of the service manual notice for chassis No. MW3-XU5003, model PLC-XU50. File with the service manual No. SM5110516-07. Note: All the information of part numbers and values indicated on these diagrams are at the beginning of production.
  • Page 54 ■ Parts description and reading in schematic diagram MW3-XU5003 1. The parts specification of resistors, capacitors and Resistor Reading coils are expressed in designated code. Please check Example 1/2 D J 10K B the parts description by the following code table. 2.
  • Page 55 ■ Pin description of diode, transistor and IC MW3-XU5003 ● Diode ● Diode K: Cathode A: Anode ● Transistor/FET ● Transistor/FET C: Collector D: Drain B: Base G: Gate Index E: Emitter S: Source C1 C2 C1 C2 ● IC ●...
  • Page 56 Diagrams & Drawings (MW3-XU5002)
  • Page 57 ■ Schematic Diagrams TERMOSTAT (SET TO OPEN AT 90+/-5C) SW902 POWER FACTOR CORRECTION S10B5540N S10B5540N AC CORD C611 C613 1000KK LF901 400GK POWER U20B30101 1000NH LENS 2.2DV AC100-120V (LIVE) R601 C601 C601 L601 L601 C602 C602 F601 VA601 275GM 275GM AC200-240V F35B DB611...
  • Page 58 C202 C201 25KZ 25KZ R1001 R1003 Q201 C1001 L1001 R1002 R1004 C200 IN2_R 6.3EM K10V 220WM D1001 R1013 J11MD400G R201 1/16 1/16GJ 6.2B GZ0C R200 100C PC1-R :UDZS R1016 R231-R233 R231 R202 6.2BG 1/16GJ K10V_39 1/16GJ PC1-R 100C 1/16GZ0C 1/16GZ0C 1/16GZ0C Q1001 1.5KC...
  • Page 59 D1281 1SS355 J10ML400G P_FAIL P-FAIL PC1/PC2 RGB/COMP K3V_39 PC1-R IC1281 R1284 PC1-G 1/16GJ SI-3012LU-TL K3V_37 390KC PC1-B K3V_35 R1285 C1202 C1283 C5202 R1201 1/16GF R5201 1/16GJ 1/16GJ 10KZ1U 25KZ0.1 100KC R1281 10KZ1U GQFZ GQFZ 1/16GJ GQFZ T12V 15.5V K3V_29 RX2+ R1286 R1283 C1282...
  • Page 60 "K3V" DIGITAL R228 PTA6 R229 S3.3VAD PTA7 C229 C231 C232 C233 C236 C228 L202 25KZ0.1 25KZ0.1 25KZ0.1 25KZ0.1 25KZ0.1 L2PF2R2MG 25KZ0.1 GQFZ GQFZ GQFZ GQFZ GQFZ GQFZ C237 6.3EM220WM :6.3EM220F1 C226 C227 R223 L203 16KK0.082 KK8200 1/16GJ L2PF2R2MG 470C C6215 C6218 6.3EM100 C239...
  • Page 61 ROMWE S3.3V IC2371 S3.3V IC2341 TC7SZ08FU-(TE85L) R2302 R2303 R2372 R2341 R2343 C2341 1/16 1/16 TC74LCX245FT 1/16GZ0C 1/16 1/16 25KZ0.1 GZ0C GZ0C R2381 1/16GJ3.3KC RAMWE GZ0C GZ0C GQFZ DIR_IN RAMOE A1_PW J30B 1640G D_R0 BHEN_N R2371 1/16GZ0C R2342 ROMOE D_R1 D0_PW 1/16 D0_PW D8_PW...
  • Page 62 D6831 LAMP REPLACE(Y) D6832 TEMP WARNING(R) S3.3V D6833 STAND-BY(RED ON) LAMP ON (GREEN ON) Q1821 R1821 1/16GJ 536P 4.7KC R6831 D6831 H8_SDA1 H8_SDA1_5 1/16GZ0C J10EZ120G C6202 SML-210YTLG L6201 6.3EM R6832 L2PD3R3MG K8A_1 47WM D6832 1/16GZ0C :L2PF3R3MG R6858 Q1822 K8A_2 R1822 IC6211 SML-210LTMG 1/16GJ...
  • Page 63 R2561 C2561 C2562 R2563 R2564 D2561 1/8GZ 1/16GJ 1/16GJ 16EM100 25KZ0.1 (D:F1) GQFZ 1SS355 270C 270C P-FAIL 15.5V P_FAIL D2562 1SS355 R2562 1/16GJ 270C IC2566 R2567 R2568 R-PANEL R2566 C2566 C2563 C2564 16KZ 16EM100 25KZ0.1 2.2FA (D:F1) GQFZ IC1401 J11EA321G TC74ACT240FT 3.3V C1401...
  • Page 64 SCH_MW3AY...
  • Page 65 ■ Printed Wiring Board Diagrams ! CAUTION This projector is isolated from AC line by using the internal converter transformer. Please pay attention to the following notes in servicing 1. Do not touch the part on hot side (primary circuit) or both parts on hot and cold sides (secondary circuit) at the same time.
  • Page 66 MAIN (SIDE:A) FN902 LAMP BALLAST 1AA4B10C3630A_B R1812 Q1823 Q691 C6672 R6632 R6631 C1811 Q1821 Q1827 IC1801 R6601 C4811 R6603 C68P R1813 D4812 TP12V2 R69B R1814 R1811 R4861 Q6843 R691 R1889 R1824 R1884 R4834 R692 R1822 C6632 R1355 R1886 IC6211 Q4867 R464R463 IC6671 R844...
  • Page 67 MAIN (SIDE:B) POWER “K6R” IC2801 C2802 R2801 C2803 R2802 R1834 R1823 R1821 R1826 C6671 C4808 C6631 C6202 R851 D2892 L6201 R1457 R847 C6641 IC1811 D3882 C857 D3884 R2447 FN901 RB1460 R826 R9806 R572 R1477 R569 C9806 RB1459 C6664 R561 R9822 R9803 R453 R562...
  • Page 68 POWER (SIDE:A) POWER (SIDE:B) LF901 L601 VA601 R611 TERMOSTAT PTH611 R612 “SW902” C612 R62T C613 C62T D62R C62F R62R R62M C62E C614 C62C R62B R62C C62B R62D R659 PC642 C641 MAIN “K8R” PC641 R636 FB693 LAMP BALLAST DS643 C634 R/C (SIDE:A) LAMP COVER SW (SIDE:A) R/C (SIDE:B) LAMP COVER SW (SIDE:B)
