Operating Instructions and Parts Manual
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect
yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could
result in personal injury and/or damage to product or property. Please retain instructions for future reference.
Description
Provides support for your lower back and eliminates knee
strain. 1" tubular steel framework resists rust. The 2-1/2"
diameter track wheels swivel easily, while providing excel-
lent stability.
Unpacking
After unpacking unit, inspect carefully for any damage that
may have occurred during transit. Check for loose, missing,
or damaged parts. Shipping damage claim should be filed
with carrier.
B
IND001
Printed in China
08/07
1MZH7
HIGH RISE SEAT CREEPER
Qty.
No. Description
1 Pad 1
2 Connection Plate 1
3 Tube 2
4 Base 1
5 Caster 4
A Bolt 8
B Spring Washer 8
C Flat Washer 8
D Nut 4
Operating Instructions and Parts Manual
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect
yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could
result in personal injury and/or damage to product or property. Please retain instructions for future reference.
Assemble:
Step 1:
Use the bolt(A), spring washer(B), flat washer(C) and nut(D) to connect the 2 tubes(3) with connection plate(2).
Step 2:
Put the connected tubes(2) with spring washer(B) and flat washer(C) on the base (4) then use the special
wrench(included) to attach 4 casters(5).
Step 3:
Put the pad(1) on the top of the tubes and attach it with 4 bolts(A).
Disassemble:
Follow in opposite sequent instructions.
CAUTION
Wear safety glasses and gloves.
DANGER
RISK TO CHILDREN AND OTHERS
CHILDREN MAY BE ATTRACTED TO THE SEAT AND VIEW IT AS A TOY
KEEP CHILDREN AWAY FROM THIS PRODUCT AT ALL TIMES
YOUR SEAT IS A PROFESSIONAL TOOL.IT IS NOT DESIGNED FOR RECRE-
ATIONAL USAGE
STORE THE SEAT IN A SECURE LOCATION WHEN NOT IN USE
RISK OF FALLING OR ROLLING
DANGER
OBSTRUCTIONS TO THE CREEPER WHEELS COULD CAUSE IT TO FLIP
OVER RESULTING IN INJURY
IF USED ON AN UNEVEN SURFACE THE SEAT COULD ROLL AWAY FROM
THE WORK AREA AND CAUSE INJURY OR PROPERTY DAMAGE
BROKEN WORN OR MISSING PARTS COULD LEAD TO COLLAPSE OF SEAT
RESULTING IN INJURY
OPERATE THE CREEPER ON A FLAT HARD LEVEL SURFACE FREE OF
OBSTRUCTIONS, FLOOR DRAINS, HOLES, CURBS, CRACKS,ETC. THAT
COULD CAUSE THE CREEPER TO FLIP OVER
MAKE CERTAIN THE SEAT IS HELD SECURE WITHIN YOUR WORK AREA
CHECK SEAT PERIODICALLY FOR ANY MECHNICAL PROBLEMS AND
CORRECT BEFORE USING
Manufactured for Grainger International, Inc.
100 Grainger Pkwy., Lake Forest, IL 60045 U.S.A.
1MZH7
HIGH RISE SEAT CREEPER
