TECHNI CAL
Serial/Ethernet Communication Control Interface (SCOM)
Applies for Series X Maritime Multi Display Generation 1 (G1) (MMD):
Please visit www.hattelandtechnology.com for the latest electronic version of this manual.
MA NUA L
HD 12T21 xxD-xxx-Fxxx
HD 15T21 xxD-xxx-Fxxx
HD 17T21 xxD-xxx-Fxxx
HD 19T21 xxD-xxx-Fxxx
HD 24T21 xxD-xxx-Fxxx
HD 26T21 xxD-xxx-Fxxx
Technical Manual SCOM Series X G1
Updated: 02 Nov 2021
Doc Id: INB100018-4 (Rev 20)
Created: 6542/6784/363
Approved: 6644
