ENDEAVOUR E145S Installation And User Instructions Manual

Fireplace mantle

Hide thumbs

Installation and User Instructions

Model: E145S Fireplace Mantle

For use with E145R – 2KW Electric Fire

PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE.

INSTALLER: DO NOT DISCARD THIS MANUAL – LEAVE WITH THE CUSTOMER.

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Appliance Development Services Ltd

Tel 01723 583227

Table of Contents

Need help?

Do you have a question about the E145S and is the answer not in the manual?

Questions and answers

Summary of Contents for ENDEAVOUR E145S

Page 1 Installation and User Instructions Model: E145S Fireplace Mantle For use with E145R – 2KW Electric Fire PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE. INSTALLER: DO NOT DISCARD THIS MANUAL – LEAVE WITH THE CUSTOMER. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Page 2 SECTION 1 DIMENSIONS Dimensions in mm SECTION 2 ASSEMBLY AND INSTALLATION 2.1 Unpack  Open the package carefully and remove the mantel . Carefully inspect for any damage before you begin assembly.  Ensure you have all the parts listed opposite before assembling ...
Page 3 Screw ST4*8 (8) Mantle(1) Wall Mounting Bracket (1) Screw ST5*40 (8) Screw M5*30 (4) Plastic Wall Plugφ8*40 (8) Washer (4) Glass Retaining Bracket (4) Side Glass (2) Rubber U Channel (4) NOTE: Left and right of product are distinguished by its front view. 2.2 Before Installation Tools required: Magnetic Phillips screwdriver 2.3 Installation...
Page 4 NOTE: Follow these instructions before fitting the fire to the wall. Remove the fire and mantle from all packaging and carefully inspect for any damage before installing. 1. Place the fire on its back and remove the front bottom screw on both sides of the fire.
Page 5 4. Take the second glass retaining bracket and attach to the bottom of the fire. Please repeat steps 2-4 for the opposite side. 5. Remove the 2 screws holding the LED cover plate and put the plate aside. pull the LED cable out then replace the cover with the LED protruding thought the half circle gap.
Page 6 7. Take the screws removed in step 1 and use these to attach the top brackets to the fire as shown in the picture opposite. 8. Holding the back of the fire, tilt the mantle up onto its top, and connect the LED cable from the fire to the LED cable on the mantle 9.
Page 7 SECTION 3 CLEANING & MAINTAINENCE our mantle surface coating will give off a slight odour for a brief initial period. Try to ventilate as much as possible during this time. Daily cleaning:  Clean the mantel surfaces with a soft, lint-free cloth.
