SimpleLink™ Wi-Fi CC3135MOD Dual-Band Network Processor Module

1 Features

Fully integrated and green/RoHS module includes
all required clocks, serial peripheral interface (SPI)
flash, and passives
®
Integrated Wi-Fi
and internet protocols
802.11a/b/g/n: 2.4 GHz and 5 GHz
FCC, IC/ISED, ETSI/CE, and MIC certified
FIPS 140-2 Level 1 validated IC inside
Rich set of IoT security features helps developers
protect data
Low-power modes for battery powered application
Coexistence with 2.4 GHz radios
Industrial temperature: –40°C to +85°C
Wi-Fi network processor
– Wi-Fi core:
802.11 a/b/g/n 2.4 GHz and 5 GHz
Modes:
– Access Point (AP)
– Station (STA)
®
– Wi-Fi Direct
GHz)
Security:
– WEP
– WPA
/ WPA2
– WPA2 Enterprise
– WPA3
Personal
– WPA3
Enterprise
– Internet and application protocols:
HTTPs server, mDNS, DNS-SD, DHCP
IPv4 and IPv6 TCP/IP stack
16 BSD sockets (fully secured TLS v1.2 and
SSL 3.0)
– Built-in power management subsystem:
Configurable low-power profiles (always on,
intermittently connected, tag)
Advanced low-power modes
Integrated DC/DC regulators
Application throughput
– UDP: 16 Mbps
– TCP: 13 Mbps
Multilayered Security
Features:
– Separate execution environments
– Networking security
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
subsystem:
(only supported on 2.4
PSK
SWRS225D – FEBRUARY 2019 – REVISED MAY 2021
– Device identity and key
– Hardware accelerator cryptographic engines
(AES, DES, SHA/MD5, CRC)
– File system security (encryption, authentication,
access control)
– Initial secure programming
– Software tamper detection
– Secure boot
– Certificate signing request (CSR)
– Unique per device key pair
Recovery mechanism – ability to recover to factory
defaults
Power-Management Subsystem:
– Integrated DC/DC converters support a wide
range of supply voltage:
Single wide-voltage supply, VBAT: 2.3 V to
3.6 V
– Advanced low-power modes:
Shutdown: 1 µA, hibernate: 5.5 µA
Low-power deep sleep (LPDS): 115 µA
Idle connected (MCU in LPDS): 710 µA
RX traffic (MCU active): 53 mA
TX traffic (MCU active): 223 mA
Wi-Fi TX power
– 2.4 GHz: 16 dBm at 1 DSSS
– 5 GHz: 15.1 dBm at 6 OFDM
Wi-Fi RX sensitivity
– 2.4 GHz: –94.5 dBm at 1 DSSS
– 5 GHz: –89 dBm at 6 OFDM
Additional integrated components on module
– 40.0 MHz crystal with internal oscillator
– 32.768 kHz crystal (RTC)
– 32 Mbit SPI Serial Flash
– RF filters, diplexer, and passive components
QFM package
– 1.27-mm pitch, 63-pin, 20.5-mm × 17.5-mm
QFM package for easy assembly and low-cost
PCB design
Module supports
SimpleLink Developers
Ecosystem
CC3135MOD
