Thank you for purchasing the INADA CHAIR. HCP-S333D You can enjoy various types of massage for relieving or soothing fatigue. HCP-S333E We hope the INADA CHAIR will be a valued partner in your daily health preservation for many years to come. 感謝您選購 INADA CHAIR 按摩椅。 本產品能緩解並改善您的疲勞,帶給您多種按摩享受。願本產品成為...
Thank you for purchasing the INADA CHAIR. HCP-S333D You can enjoy various types of massage for relieving or soothing fatigue. HCP-S333E We hope the INADA CHAIR will be a valued partner in your daily health CONTENTS preservation for many years to come. ■...
SAFETY PRECAUTIONS Types of Indications Warning This action could result in serious injury or death. Caution This action could result in personal injury or damage to property. Types of Symbols and Description Prohibited. Do not disassemble. Do not Prohibited disassemble Do not use in a location where the chair Do not handle with wet hands.
Page 5
Safety Precautions: Before Use Warning ● The following persons must not use this massage chair: ◎Persons who have been instructed by a doctor to avoid massage therapy. Ex. Thrombosis, severe aneurism, acute varicosity, or dermatitis and/or skin infection including inflammation of the typodermis. ◎Persons with suspected acute neck sprain (whiplash injury) ●...
Page 6
SAFETY PRECAUTIONS Safety Precautions: During Use Caution ● Do not use the chair unclothed. ● Do not use the chair for purposes other than massage, or other than the ordinary uses of a chair. → Could result in accident or injury. ●...
The chair is equipped with heaters for the fingertips and toes. Benefits As a therapeutic massage device for household use, the Inada Chair provides the following benefits: ● Relieves fatigue ● Alleviates muscle fatigue ● Relieves muscle pain ● Improves blood circulation ● Relieves muscle aches...
COMPONENTS & DESCRIPTION Chair ① ⑱ ② ⑤ ⑩ ④ 1 1 2 2 ③ ⑧ ⑨ ⑥ ..1 ⑦ ⑪ ⑰ ..7 ⑯ ..10 ⑫ ..13 ..14 ..15 ⑮ ⑭ ⑬ ..17 ..21 CE FOR ..22 ..23 ①...
Page 9
Remote Control Turns the remote control power ON and OFF. Pushing the POWER button while the chair is activated causes the ① ② rollers to return to the starting position, after which the ① Button chair turns itself off. The button lights in green while the power to the remote control is ON, lights in orange while the power is OFF, and flashes in red while the chair is stopped in an emergency.
BEFORE USE ● This product is shipped with the reclining seat back in its fully reclined position. Be sure to raise the seat back to its fully upright position. ● Do not expose the chair to sudden bursts of heat. If the room where the chair is to be used is cold, turn the heat up slowly.
Page 11
How to Install the Armrests Before installing the armrests, turn off the main power and disconnect the power cord connector from the power connector on the chair. ① Place the armrest at the side of the chair and pass the air hose and harness through the rectangular hole. *Be careful not to pass it through the groove.
Page 12
BEFORE USE ④ Turn over the fabric, and use the T-shaped wrench to install the supplied screw and washer in the direction shown in the diagram. (Total of 3 locations on each side, indicated by circles in the diagram; ensure that the washer direction is correct.) ..1 ..7...
Page 13
How to Transport or Move the Chair Before moving the chair, turn off the main power, unplug the power plug from the wall outlet, and also disconnect the power cord connector from the power connector on the chair. To Move with the Wheels To Carry Raise the reclining seat back to its upright position, hold Fully recline the seat back and carry the chair by holding...
Page 14
BEFORE USE Checking the Seat Cover Before using the chair, check the seat cover for tearing with the following procedure. ① Peel open the Velcro at the top. ② Fold the back pad forward, and check by touching with your hands that the chair fabric is not damaged. Chair Covering Back Pad Velcro...
POSITION ADJUSTMENT How to Sit When the chair is off, the rollers are normally drawn back into the left and right sides of the upper part of the seat back (Storage Position). For safety, first check the position of the rollers. If they are in any position other than the storage positions, turn the main POWER switch ON before sitting down to allow the rollers to return to their storage position.
Page 16
POSITION ADJUSTMENT How to Use the Buffer Pad If you feel that the massage is too intense, place the supplied buffer pad onto the back pad and start the massage again...1 ..7 ..10 ..13 ..14 ● Make sure that the buffer pad does not curl up or become lop-sided. Caution →May result in accident or injury.
Page 17
How to Use the Leg Rest Vertical Adjustment ■ To raise the leg rest Press the top LEG REST button to raise the leg rest. ■ To lower the leg rest Press the bottom LEG REST button to lower the leg rest. When you press the button for approximately 2 Hold Function seconds, the leg raise (lower) operation automatically...
POSITION ADJUSTMENT How to Use the Reclining Seat Back ■ To raise the reclining seat back Press the top RECLINE button to raise the reclining seat back. ■ To lower the reclining seat back Press the bottom RECLINE button to lower the reclining seat back. Reclining Movement Range The chair reclines up and down in conjunction with the movement of the seat back and leg rest.
PROGRAMS & SELECTION The preset programs make it easy to select a program that suits Preset Programs your preferences or objectives. Full Body & Stretch This program includes light stretching in a full-body massage. Stretch All This program includes light stretch actions where the entire body is stretched.
PRESET PROGRAMS Preset Program Massages ● 6 automatic programs provide a variety of different massages to relieve fatigue. ● With the preset program buttons, you can choose your favorite program to give you a massage according to the preset menu. ❶...
Page 21
Air Massage Intensity Adjustment and Cancelation The air massage intensity can be adjusted. Each time the air intensity button is pressed, the intensity changes in the order of Low, Medium and High. (The default setting when the program starts is Medium.) In the same way, the intensity can be changed in the order of Low, Medium and High even when Max Intensity mode is ON.
MANUAL SELECTION Description of Manual Selection Operations Select the massage operation of your choice from among menus ① to ④ . ● A circle in the adjustment column means that the particular adjustment can be made in the course of that massage action. ●...
Page 23
③ ② ① ④ ④ Air Massage Press the button for the area that you want to massage. Intensity Button Operation Action Adjustment An air massage from your ○ Arm Air shoulders to fingers. An air massage from your ○ Seat Air lower back to buttocks.
Page 24
MANUAL SELECTION Operation of Parts and Position Adjustment ❶ Press the button. If no selection is made within 5 minutes, the power shuts off ❶ automatically. ❷ Press the button for the desired massage. Select a combination of your operations of choice from basic operations, rolling, special operations and air massage.
Page 25
Width Adjustment During a basic operation where width adjustment is possible, the width of the rollers can be adjusted in 3 steps (Narrow, Medium and Wide). Speed Adjustment During a basic operation where speed adjustment is possible, the speed of action can be adjusted in 3 steps.
TROUBLESHOOTING If there is still a problem after trying the solutions given in this troubleshooting guide, stop using the chair immediately to prevent accident or injury, and unplug the power plug from the wall outlet. Contact the vendor or the “Repair Service Center“ (see back page) for assistance. Problem Cause &...
Noise during chair These noises are a normal part of the chair’s operation and do not affect its operation performance in any way. The following noises are made during operation. Noises during tapping Sound of the rollers rubbing against the seat cover during kneading Sound of raising and lowering the rollers, sound of roller operations...
Can I put the chair onto an electric How do I make the massage lighter? carpet? Do not place the chair onto an electric carpet because it could cause Perform the following: a fire. ● Raise the reclining seat back. The chair is very heavy, so it could damage the ●...
Page 29
Can someone who is under 150 cm (5 The remote control panel has come feet) or over 180 cm (6 feet) use the off. Can I fix it? chair? Reattach with the following Yes. procedure. ❶ Hold the remote control as illustrated, Because the correct shoulder positions may not be found during shiatsu point locating, we and insert the projection on the bottom...
CARE AND STORAGE Storage ● After wiping off any dust or dirt, store your chair in a place that is relatively dry. ● If the chair is left unused for a while, put a cover on it that will protect it from dust and dirt. ●...
AFTER SALES SERVICE 1. Warranty Please read the contents carefully and keep it in a safe place. Please complete and mail in the warranty card that was included with your chair. If the chair is to be used outside the home (in a commercial setting, for example), fees will be charged for repairs. 2.
SPECIFICATIONS Name & Model Number HCP-S333A HCP-S333D HCP-S333E Power Supply AC120V~ AC220-240V~ AC110V~ Power Consumption 140W 110W 140W Power Frequency 60Hz 50-60Hz 60Hz Rated Time 30 minutes Kneading Speed 3 levels, from minimum 6 times/minute to maximum 20 times/minute (approx.) Tapping Speed 3 levels, from minimum 180 times/minute to maximum 500 times/minute (approx.) ..1...
Page 96
Manufactured by FAMILY CO., LTD. 发行日/ 發行日( 日/月/年) DATE OF ISSUE(day/mo/yr) 2-1-3 Nishi-Miyahara,Yodogawa-ku, Osaka 532-0004, Japan 1 / 10/2012 由 FAMILY CO., LTD. 製造 Made in JAPAN 2-1-3 Nishi-Miyahara, Yodogawa-ku, Osaka 532-0004, Japan 日本製造 原产地 : 日本 Manufactured by FAMILY CO., LTD. 532-0004 日本国大阪市淀川区西宫原...
