USER MANUAL

BAR CODE SCANNER FOR IEC SERIES

2D-PMH-A1 and 2D-LMH-A1

Rev 1110322.1

Table of Contents

Need help?

Do you have a question about the 2D-PMH-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for MicroTouch 2D-PMH-A1

Page 1 USER MANUAL BAR CODE SCANNER FOR IEC SERIES 2D-PMH-A1 and 2D-LMH-A1 Rev 1110322.1...
Page 2: Table Of Contents
Package Contents ....................5 Product Setup and Use ................6 Bar Code Scanner Default Settings ............9 Default Settings ......................9 Reset MicroTouch Default Settings ................9 Caution ........................9 Presentation Mode ....................10 Presentation Mode Idle Illumination Light ..............11 Power Up Beeper ....................
Page 3 Appendix ....................20 Cleaning ......................... 20 Solutions to Common Problems ................21 Warranty Information ....................22 RoHS Declaration ....................23...
Page 4: About This Document
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of MicroTouch a TES Company. Disposal Information...
Page 5: Product Overview
Product Overview This product is a feature-rich, flexible bar code scanner that is configured for immediate use out of the box for most applications. Product Number 2D-PMH -A1 Is preconfigured for Portrait orientation (mounted on the long vertical side of a monitor in Portrait orientation). Product Number 2D-LMH -A1 Is preconfigured for Landscape orientation (mounted on the short vertical side of a monitor in Landscape orientation).
Page 6: Product Setup And Use
Product Setup and Use The bar code scanner will be installed in the accessory port on back of the left side of the touch computer, as viewed from the front, as noted by the arrow below.
Page 7 Remove the cover from the touch computer’s accessory port. Connect the bar code scanner cable to the cable in the touch computer’s accessory port. IMPORTANT: To avoid damaging the connectors, be sure to observe correct polarity by matching the wire colors (same wire color on each side of each connector).
Page 8 Gently push the bar code scanner into place on the touch computer, making sure the connector is properly stowed. Secure the bar code scanner with the two included M3x6 screws, taking care to not over tighten them.
Page 9: Bar Code Scanner Default Settings
USB HID Keyboard Mode: TERMID124 Reset MicroTouch Default Settings If the scanner ever needs to be reset to the MicroTouch as-shipped settings, scan the code below. Caution Below are descriptions of the default settings and their optional settings. To avoid rendering the scanner unusable, please use discretion when changing the bar code scanner’s settings.
Page 10: Presentation Mode
Presentation Mode Presentation Mode allows the bar code scanner to automatically read a bar code when one is presented (as opposed to requiring the user to press the trigger button). Various settings allow modification to how Presentation Mode works. PAPTPR (the default) is for optimized scan speed, with limited reading range. PAPTRE sets “full depth of field”, allowing reading bar codes at a greater distance.
Page 11: Presentation Mode Idle Illumination Light
Presentation Mode Idle Illumination Light The illumination LED is a bright LED that acts as a “flashlight” to make sure the scanner can see the bar code. In the idle state (when no bar code is present for reading), the illumination light can be turned off (the default) or set to Low, Medium or High brightness.
Page 12: Power Up Beeper
Power Up Beeper By default, the bar code scanner beeps when it first turns on. This is the BEPPRWR1 setting. Presentation Illumination Light Intensity The illumination LED comes on when a bar code is presented for reading. The intensity is set to High (PWRLDC150) by default.
Page 13: Use Hid Keyboard Mode
Modes By default, the bar code scanner uses the USB HID interface. Other modes can be set by scanning the bar codes below To reset to the default USB HID interface mode, scan the bar code below.
Page 14: Other Settings
Other Settings Streaming Presentation Mode In Streaming Presentation Mode, the bar code scanner continuously scans for bar codes. Streaming Mode overrides Presentation Mode. Normal Streaming Mode offers good scan speed and the longest ranges (depth of field). Normal Streaming Enhanced Streaming Mode gives the highest possible scan speed but slightly less range ranges (depth of field).
Page 15: Set Beep Volume
Set Beep Volume The bar code scanner can be set to beep at various intensities when a bar code is scanned to let the user know the scan is complete. It can also be turned off, but this is inadvisable. Medium Medium High...
Page 16: Keyboard Country Layout (Language)
Keyboard Country Layout (Language) United States French German Italian...
Page 17: Reset
Reset The RESET bar code below simply turns the bar code scanner off and back on. No settings are affected. To reset the bar code scanner to its default settings, scan the code at the beginning of this (Bar Code Scanner Settings) section.
Page 18: Changing The Physical Orientation
Changing The Physical Orientation To allow for maximum flexibility in mounting, the bar code scanner can be configured to mount at any of four orientations. To change the orientation, follow the steps below. Remove the screws Place the bar code scanner on an acceptable work surface and remove the Phillips #0 screws: Separate the halves Separate the two plastic case halves by gently lifting the back cover at the cable exit point, then sliding the cover off.
Page 19 Remove the internal screws Remove the two #0 Phillips screws that hold the bar code scanner to the metal bracket. Rotate the scanner Note that there are four mounting holes in the backet, allowing the scanner to be rotated to any mounting position in 90 degree increments.
Page 20: Appendix
Appendix Cleaning To clean the case, dampen a clean cloth lightly with water and a mild detergent and wipe gently. Do not use volatile solvents, waxes or any abrasive cleaners on any part of the product.
Page 21: Solutions To Common Problems
Solutions to Common Problems How can I test functionality? Set the barcode scanner to “USB PC Keyboard” mode (see Modes section above). Open a text editor – Notepad, Keep Notes, or similar. Place the cursor in the text editor and scan a barcode or QR code from a commercial product.
Page 22: Warranty Information
Warranty Information Except as otherwise stated herein, or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchscreen display and their components is three years. Seller makes no warranty regarding the model life of components.
Page 23: Rohs Declaration
RoHS Declaration Equipment name：Bar Code Scanner Type designation (Type) ： 2D-PMH-A1 2D-LMH-A1 Restricted substances and their chemical symbols Component Hexavalent Polybrominated Polybrominated Cadmium Lead Mercury chromium biphenyls diphenyl ethers (Pb) (Hg) (Cd) (PBDE) (PBB) ○ ○ ○ ○ ○ ○...
Page 24 TES AMERICA LLC | 215 Central Avenue, Holland, MI 49423 | (616) 786-5353 The information presented in this user manual is intended as general information about MicroTouch products and is subject to change. Product specifications and warranties will be governed by TES America, LLC. Standard terms and conditions of sale. Products are subject to availability.

This manual is also suitable for:

2d-lmh-a1
