- Page 1 AL-100R/150R APR. 2001 AL-100R ELECTRONIC KEYBOARD Ver.1 : Feb. 2005 INDEX...
-
Page 2: Table Of Contents
CONTENTS Safety Notice ..................1 Specifications ..................2 Block Diagram ................... 4 Circuit Description ................5 Exploded View ................... 7 Parts List ..................10 Schematic Diagrams ............... 16 SAFETY NOTICE CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the same of equivalent type recommended by the appliance manufacturer.Discard used batteries according to manufacturer's instructions. -
Page 3: Specifications
• Tempo Range: 30 to 255 • Controllers: INTRO, FILL-IN, BREAK, VARIATION 1-2, SYNCHRO START/STOP, ENDING, START/STOP • Modes: Normal; CASIO CHORD; FINGERED; FULL RANGE CHORD • Parts: Drum; Percussion; Bass; Chord 1 to Chord 5 • Accompaniment/Song Volume: v slider •... - Page 4 Input impedance: 3.3kΩ Input sensitivity: 10mV x 16.0cm × 2, x 5.0cm × 2 (Output: 30.0W + 30.0W) Speakers: Power Supply: AL-100R/AL-150R: 120V AL-100RV: 220 - 240V Power Consumption: AL-100R/AL-150R: 78.0W AL-100RV: 78.0W CELVIANO (without stand): 141.5 × 51.4 × 23.3 cm (55 3/4" × 20 1/4" × 9 3/16") Dimensions: CELVIANO: 141.5 ×...
-
Page 5: Block Diagram
BLOCK DIAGRAM LEDs Buttons Keyboard Keyboard LCD Controller KC0 ~ 7 Controller ML9040-B03GA (LSI301) MSM5259GS-K (LSI302) TC190C020AF FI0 ~ 10 SI0 ~ 10 LSI1 MIDI SW/LED Reset IC LRCK Controller RN5VD2BAA uPD65881GB (LSI301,LSI351) IC17 CA0 ~ 21 CA0 ~ 14 M-IN FDD Controller M-OUT... -
Page 6: Circuit Description
CIRCUIT DESCRIPTION KEY MATRIX Second contact First contact HG52E35P A0 1 A0 # 1 B0 1 C1 1 C1 # 1 D1 1 D1 # 1 E1 1 A0 2 A0 # 2 B0 2 C1 2 C1 # 2 D1 2 D1 # 2 E1 2... - Page 7 For Piano Ballad For Piano Jazz Dance Jazz Latin Various For Piano Classic For Piano Various Modo One Touch Preset Sequencer Record Metronome Beat Casio Chord Transpose/ Mixer Mixer Mixer Disk Execute Function Mixer Group A/B Solo/Play/Normal Intro Variation 1 Variation 2...
-
Page 8: Exploded View
EXPLODED VIEW CABINET — 7 —... - Page 9 — 8 —...
- Page 10 STAND — 9 —...
-
Page 11: Parts List
PARTS LIST AL-100R/150R Notes: This parts list does not include the cosmetic parts, which parts are marked with item No. "R-X" in the exploded view. Contact our spare parts department if you need these parts for refurbish. Prices and specifications are subject to change with- out prior notice. - Page 12 Price ITEM NO. CODE NO. PARTS NAME SPECIFICATION Applicable Q Code R REMARKS Main PCB 1005 2374 PCB ASSY/M437-MA1M M241560*1 TK(M437) Common 7911 4127 DIODE RB520S-30TE61 Common 1004 7442 DIODE/ZENER HZU2.7B2TRF Common 1004 7445 IC/MONOLITHIC NJM2068MD(T1) Common 2105 3696 IC10 IC/C-MOS TC7SH04FU-TE85L Common...
- Page 13 POTENTIO METER/ROTARY K091B0209-5KB Common PS1,PS3M,PS4M,PS5M,PS6M PCB's 1005 2380 PCB ASSY/M437-PS3M M341451*1 TK(M437) Common 1005 2377 PCB ASSY/M437-PS4M M341452*1 TK(M437) AL-100R 1006 4261 PCB ASSY/M437-PS4M M341452*2 TK(M438) AL-150R 1005 2373 PCB ASSY/M437-PS5M M241557*1 TK(M437) Common 1005 2381 PCB ASSY/M437-PS6M M341453*1 TK(M437)
- Page 14 Price ITEM NO. CODE NO. PARTS NAME SPECIFICATION Applicable Q Code R REMARKS 1004 5597 URUY3117X-J546R Common 1004 5598 GL3ZV802B1H6 Common 1004 5599 URUY3117X-J545R Common 2370 1407 KR3301X-J444K Common Keyboard unit 1005 2259 KEY ASSY M141175*2 TK(MLMP) Common 1004 5531 BLACK KEY M140784-2 Common...
- Page 15 Code R REMARKS 1004 7623 CONNECTOR M441196-1 Common 6906 9312 KNOB/SL M311859B-1 Common 1004 7645 PANEL SUB ASSY/CN M141193*2 AL-100R 1005 4407 PANEL SUB ASSY/CN M141193*4 AL-150R 1005 3835 PLATE/DISPLAY/437 M341405-2 Common 1005 2387 SWITCH ASSY/POWER M341447*2 TK(M437) Common 1004 3510...
- Page 16 Price ITEM NO. CODE NO. PARTS NAME SPECIFICATION Applicable Q REMARKS Code Components 1005 2376 BOARD ASSY/FRONT M241598*1 TK(M437) AL-100R 1005 8211 BOARD ASSY/FRONT M241656*1 TK(M438) AL-150R 6924 5121 SHAFT M440300A-1 Common 6924 5140 GEAR 4247002100 Common 1005 2371 BOARD ASSY/TOP...
-
Page 17: Schematic Diagrams
SCHEMATIC DIAGRAMS Contents MAIN PCB (JCM437-MA1M) MA1M-1 SCHEMATIC ......................17 MA1M-2 SCHEMATIC ......................18 COSOLE PCB (JCM437-CN1M/CN2M) CONSOLE-1 SCHEMATIC ....................19 CONSOLE-2 SCHEMATIC ....................20 I/O PCB (JCM437-PS1/PS2M/PS3M/PS4M/PS6M) MA1M-3 SCHEMATIC (120 V) ..................... 21 MA1M-3 SCHEMATIC (230 V) ..................... 22 I/O PCB (JCM437-PS5M) MA1M-5 SCHEMATIC ...................... - Page 18 SCHEMATIC DIAGRAMS MAIN PCB JCM437-MA1M — 17 —...
- Page 19 MAIN PCB JCM437-MA2M — 18 —...
- Page 20 COSOLE PCB JCM437-CN1M — 19 —...
- Page 21 COSOLE PCB JCM437-CN2M — 20 —...
- Page 22 I/O and POWER SUPPLY PCB JCM437-PS1/PS2M/PS3M/PS4M/PS6M (120 V) — 21 —...
- Page 23 I/O and POWER SUPPLY PCB JCM437-PS1/PS2M/PS3M/PS4M/PS6M (230 V) — 22 —...
- Page 24 I/O PCB JCM437-PS5M — 23 —...
- Page 25 LCD PCB JCM437-LCD1M — 24 —...
- Page 26 KEY PCB JCM887T-KY1M — 25 —...
- Page 27 KEY PCB JCM887T-KY2M — 26 —...
- Page 28 KEY PCB JCM887T-KY3M — 27 —...
- Page 29 LED PCB JCMLMP2-LD1M — 28 —...
- Page 30 LED PCB JCMLMP2-LD2M — 29 —...
- Page 31 LED PCB JCMLMP2-LD3M — 30 —...
- Page 32 LED PCB JCMLMP2-LD4M — 31 —...
- Page 33 LED PCB JCMLMP2-LD5M — 32 —...
- Page 34 LED PCB JCMLMP2-LD6M — 33 —...
- Page 35 LED PCB JCMLMP2-LD7M — 34 —...
- Page 36 LED PCB JCMLMP2-LD8M — 35 —...
- Page 37 Ver.1 : Feb. 2005 Correction of the PARTS LIST (P13) CASIO TECHNO CO.,LTD. Overseas Service Division 6-2, Hon-machi 1-Chome Shibuya-ku, Tokyo 151-8543, Japan...
