- Page 1 Rechargeable HOBBYIST Air Brush User Manual TL4590...
-
Page 2: Technical Data
Technical Data PRODUCT NAME: Rechargeable Air Brush PRODUCT CODE: TL4590 POWER: Lithium Battery 3.7V 1200mAh MAX OUTPUT: 7 L/min CUP CAPACITY: 5CC/20CC CHARGING TIME: Up to 4 hours USING TIME: Up to 45 minutes NOZZLE DIAMETER: 0.5mm MAX PRESSURE: 18-25PSI... - Page 3 How to use Check the product & USB cable, make sure no damage after taking out from Step 1: package. Step 2: Use USB cable and 5V 2A adapter to charge the cordless compressor. It takes about 2-3.5 hours to fully charged. When the red light turns to green, it means the power is fully charged.
-
Page 4: Cleaning And Maintenance
Cleaning and Maintenance A: Cleaning step Step 1: Step 2: Empty any remaining airbrush Using the dropper, add hot water or coloring from the cup. alcohol to the cup to clean. Step 3: Step 4: Thoroughly swab the cup clean Spray water or alcohol through the with a cotton swab. -
Page 5: Common Faults And Solutions
mon Faults an Common Faults and Solutions AIRBRUSH MECHANISM AIRBRUSH Parts Name 1.Needle Cap 2.Nozzle cap 3.Nozzle 4.O-Ring for Nozzle Cap 5.Needle 6.O-Ring for Needle Guide 7.Nozzle Guide 8.Lid for Color Cup PARTS DETAILS P ART 9.Operation Lever 10.Lever Guide 11.Stopper 12.Needle Chuking Guide 13.Spring... -
Page 6: Environment Friendly Disposal
d Solutions Warning • The compressor should be used in a clean, dry and ventilated area. MECHANISM • Please do not wash the machine body under water. • Keep out of reach of children. 1.Ne 2.Ne • The compressor’s ambient temperature should be 0-40ºC. Do not put in direct 3.No sunlight.
