Summary of Contents for Badgematic FLEXI

  • Page 1 English Badge Maker Manual Badgematic Button GmbH Phone: +49(0)234-962906-0 Industriestrasse 59-61 Fax: +49(0)234-962906-19 44894 Bochum info@badgematic.de Germany www.badgematic.de...
  • Page 2: Table Of Contents

    CONTENTS 1. Preparations 2. Make Buttons Arrange Badgematic 04-05 The Machine Material 06-07 Important before you Start: Filling lower Stamp 1 Cap Nuts & Stamp Sets Filling lower Stamp 2 08-09 Important before you start: Paper Inlay & Usage of Fabric First Processing &...
  • Page 3 Congratulations on your new badge maker. Please read this manual carefully before starting.
  • Page 4: Preparations

    PREPARATIONS The Machine English...
  • Page 5 2 operating handle converter upper stamp (upper part) split pin upper stamp (lower part) cap nut lower stamp 1 bridge flexi-holding ground plate lifting bolt distance bolt swivelling plate English...
  • Page 6: Important Before You Start

    IMPORTANT: BEFORE YOU START Hands off the cap nuts!!! Hutmuttern nicht anfassen! The 4 cap nuts and the ball screws underneath may not be adjusted or even removed! You should not touch them at all. Hands off! This device is responsible for the correct hold of the stamp sets. They have to hold up well, but they have to be easy to swap off for exchange.
  • Page 7: Upper Stamp (Upper Part)

    Be careful with the stamp sets!!! The inner parts of the stamp sets are made of aluminum and therefore they are very soft and sensitive. It´s important that you handle them carefully. Especially the upper stamp. Damages in the upper stamp lead to malfunctioning.
  • Page 8 IMPORTANT: BEFORE YOU START The Paper Inlay 80-90g strong „normal“ copy paper Paper Inlay diameter = Foil diameter Always cut the paper clean and round, preferably with a circle cutter or a paper punch. Basically, you CAN also use other, thicker or thinner paper or other material, for example fabric, wrapping paper, even leaves, etc...
  • Page 9: Badge Designer

    MORE HINTS Usage of Fabric Experience shows that nearly every kind of fabric can be used for buttons. Exceptions are very thick and unflexible fabrics, woolen fabrics or fabrics with a high share in stretch. But there are so many kinds of fabric that it is hard to cover them all. If you are not sure if it works: Just try it out! Instead of the paper inlay, just use the fabric cut in the right size and leave out the foil! Depending on the fabric you can also try cutting it in a slightly smaller diameter or using an addi-...
  • Page 10: Fixing The Rubber Handle

    - screw it into the operating lever. Inserting the stamp set Put the badge maker in front of you so that the ground plate is positioned vertically. Turn the swivelling plate into a horizontal position, so that you can correctly read the word „Flexi”. English...
  • Page 11 Before you put the upper stamp into the Flexi-holder you have to bring these two parts into the right position: The upper part is movable. Turn it until the two bolts in it are exactly above the holes you find in the lower part.
  • Page 12: Upper Stamp (Lower Part)

    FIRST STEPS Now put the upper stamp underneath the Flexi-holder, so that the distance bolt on the swivelling plate is exactly between the two split pins of the upper stamp. Now the upper stamp has to be put into the Flexi-holder.
  • Page 13 The rest is very easy: Just put the two lower stamps into the holes in the ground plate, they are accor- dingly marked. Attention: Take care that the lo- wer stamp marked with 1 is at position 1 on the swivelling plate –...
  • Page 14 MAKING BUTTONS The button components: !! Only Badgematic Originals !! = Lifetime-Guarantee for your Badge Maker Our original button components are perfectly adopted to our Badge- matic badge makers. All parts fit together perfectly. They are subject to our regular and stric quality control.
  • Page 15: Lower Stamp

    Get the required button components ready. These parts include a me- tal top, a metal backside with safety pin, a foil and the paper inlay you have designed, printed and cut before. (Note the information on paper page 08.) inserts on Filling lower stamp 1: Turn the swivelling plate, so that lower stamp 1 is in front of you.
  • Page 16: Lower Stamp

    MAKING BUTTONS Filling lower stamp 2: Turn the swivelling plate by 180° up to the stop. Lower stamp 1 is now directly underneath the upper stamp and lower stamp 2 is in front of you. Now put the metal backside into lower stamp 2. Concerning the backside variation with safety pin, put it into the stamp with the pin opening downwards (put it straightly into it, just like the paper inlay!).
  • Page 17 First Processing: Now you can produce your first button: Pull the operating lever forward as far as it will go (no violence, please). After you have released the lever, the metal top with the paper inlay and foil is in the upper stamp. ATTENTION: Do not hold the swivelling plate or the front stamp with the other hand while you pull the lever.
  • Page 18 MAKING BUTTONS Second Processing: Turn the swivelling plate by 180° again up to the stop, so that lower stamp 2 with the metal backside is now directly underneath the upper stamp. Pull the operating lever forward again. This time you need a little bit more power. Pull the lever until there is no more space between the two parts of the upper stamp.
  • Page 19 Your first button: Turn the swivelling plate by 180° There it is – your first self- again. made button! Backside Variations: Depending on the backside variation you want to produce, an additio- nal final step might be necessary. Concerning the 25 mm button with D-shaped pin for example, you have to put the D-shaped pin into the ring backside by hand yet.
  • Page 20: Exchanging The Stamp Set

    EXCHANGING THE STAMP SET The stamps of our badge maker type 900 Flexi are exchangeable. With only a few movements and without any tool needed, you can easily exchange the stamps and switch to another button size. This is how it...
  • Page 21: Inserting Stamp

    Inserting stamp: Now you put in the new upper stamp and the lower stamps. You have already done this while getting your badge maker ready the first time. page 10 Please read point “Inserting Stamp Set” on again. English...
  • Page 22 You can reach us by phone: 9629060 or by email: info@badgematic.de. If it is necessary you can also send us your machine for maintenance or repair. Normally any mainte- nance or repair will be for free. We grant you a life-time guarantee on your...
  • Page 23 Your statutory rights will not be restricted by that. Guarantor is Badgematic Button GmbH, Industriestr. 59-61, D-44894 Bochum. The guarantee period is lifetime after purchase. The guarantee is valid worldwide.
  • Page 24 We can only guarantee a smooth functioning of our badge making machines, if you exclusively use our original Badgematic button badge components. We can only rely on our original Badgematic button badge components concerning a perfect adaption to our badge making machines.
  • Page 25 If the gurarantee event occurs after a period of 24 months after conclu- sion of the contract, the customer shall pay for the costs of transport for repair or improvement. Badgematic pays for the costs of re-transport in any case.
  • Page 26 Internationally: If a guarantee event occurs within 6 months after con- clusion of the contract, Badgematic takes over the necessary forwarding costs for the transport and re-transport internationally. This only includes countries for which we offer transport in our webshop www.badgematic.
  • Page 27 Scan the code and watch a video! Manual Exchanging Stamp Set...
  • Page 28 Badgematic Button GmbH • Industriestraße 59-61 • 44894 Bochum • Germany Telefon: +49(0)234-962906-0 • Telefax: +49(0)234-962906-19 info@badgematic.de • www.badgematic.de...
