Force gauge

Sensor + Hand Terminal HT 6.0

Operating Instructions

Table of Contents

Need help?

Do you have a question about the HT6.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for HKM Messtechnik HT6.0

Page 2: Table Of Contents
Table of contents Force gauge Sensor + Hand Terminal HT 6.0 1. General notes and information ....................3 1.1. Description ................................3 1.2. Scope of delivery ..............................3 1.3. Intended use..............................3 1.4. Safety instructions ............................3 2. Technical data .......................... 4 3. Operating elements and functions ..................5 4.
Page 3: General Notes And Information
Force gauge Sensor + Hand Terminal HT 6.0 Notes 1. General notes and information 1.1. Description The electronic force gauge is for measuring forces and weights. It consists of a transducer and the hand-held terminal connected by a cable. This displays the measured values with seven digits, prefix and the specified unit. Factory calibration is performed according to your specifications and the units N, kN,g, kg, t or lb.
Page 4: Technical Data
Force gauge Sensor + Hand Terminal HT 6.0 Technical data 2. Technical data Nominal load see type plate on the transducer or in the declaration of conformity on ppage 11 Overload 1.2-fold nominal load Measuring rate slow (10 Hz) / middle (20 Hz) / fast (100 Hz) Display 12 digits, 2 lines Resolution...
Page 5: Operating Elements And Functions
Operating elements Force gauge Sensor + Hand Terminal HT 6.0 3. Operating elements and functions The force gauge has two operating modes: - the measuring mode: in this mode, the measurements are performed. This is the standard mode of the force gauge, which is always enabled after switching on.
Page 6: Operation
Force gauge Sensor + Hand Terminal HT 6.0 Operation 4. Operation 4.1. Switching on: By pressing the button, the force gauge is switched on. The nominal load of the transducer is shown briefly on the display. Always make sure that this load is not exceeded. The current measured value is shown in the display.
Page 7: About" Menu Option
Force gauge Sensor + Hand Terminal HT 6.0 Operation The menu is used via the four buttons: - It is opened with the MENU button. - You can scroll through the menu options / submenu options with the buttons, or increase or decrease adjustable values. - The enter button is for opening the selected menu option or to confirm the entry.
Page 8: Measuring
Force gauge Sensor + Hand Terminal HT 6.0 Operation Procedure: - Press MENU to open the menu - Select the “2. Configuration” menu option with and open it with enter - Select the desired submenu option with and open it with enter - Select the required value with and confirm it with enter...
Page 9: Zero Positioning And Taring
Force gauge Sensor + Hand Terminal HT 6.0 Operation Procedure: - Select suitable adapters to install the transducer. - Make sure that the applied force is always vertical to the measuring axis of the transducer, for tensile as well as compression forces.
Page 10: Changing The Battery
Calibration cycle Force gauge Sensor + Hand Terminal HT 6.0 4.4. Changing the battery The charging state of the battery is monitored by the force gauge. If the battery is starting to get depleted (battery charge < 4V), “Batt” flashes in the bottom line of the display. In this case, for safe operation of the force gauge, the battery needs to be replaced. To replace the battery, the hand-held terminal must be switched off.
Page 11: Declaration Of Conformity
Declaration of conformity Force gauge Sensor + Hand Terminal HT 6.0 6. Declaration of conformity Declaration of conformity for devices with CE mark HKM-Messtechnik GmbH Ziegelhofstraße 228 79110 Freiburg Germany herewith declare that the product below conforms to the stated guidelines and standards. Product: Sensor and Hand-held Terminal HT 6.0 EU guideline...
