- Page 1 Sidus F1 Sidus F1Q Q Q Q Sidus F1 Sidus F1 Quick Reference Manual Revision 1.2 – August 2010 - © M.U. 2009/2010...
- Page 2 Sidus F1Q Sidus F1Q e-timer has all the features to control an F1Q class model. It drives the electric motor through a standard ESC and can handle up to 3 separate servos. It is possible to use only one servo to step a disc that releases levers at fixed angles, or directly connect the servos to the moving surfaces (rudder, tail plane, wing).
- Page 3 Motor Safety Start Lock: after completing a timing sequence and reaching DT, a new motor start is disabled. It is re-enabled only through the Programmer or by disconnecting and reconnecting the battery. The behavior complies with the F1Q class rules and is intended to prevent inadvertent motor start, for example during retrieval.
- Page 4 Sidus F1Q – free flight electronic timer Programmer The Programmer is needed to change the timing sequence and dethermalize the model. It also allows to accurately adjust the servo(s) positioning and change other settings. READ READ READ READ R R R RDT...
- Page 5 Timer) then choose T4 (Exit). Motor start unlocking For safety reasons and F1Q class rules compliance, after completing a timing sequence and reaching DT a new motor start is locked. To unlock it through the Programmer (make sure the Timer is ON and the IR sensors mutually visible) press and hold T2 (UNLOCK)
- Page 6 Sidus F1Q – free flight electronic timer Timing memory selection The Timer has 5 “timing memories” (tm1 to tm5) to store up to 5 different timing sequences. 1. From the MAIN press and hold T4 (SET) [over 3 seconds] until the SET menu is...
- Page 7 Sidus F1Q – free flight electronic timer accordingly and the current setting is displayed (positions range from 000 to 130) for each of them. Reach the wished position (e.g. POS2) 4. Press and release T1 to have an ‘*’ (asterisk) appearing in turn close to one of the displayed positions.
- Page 8 Sidus F1Q – free flight electronic timer 3. When finished press and release T2 (Exit) to go back to the SET menu and press and release again T2 (Exit) to end modifications Charging the Programmer battery A micro LiPo battery field Charger is supplied with the system to charge the Programmer LiPo battery.
