AFP
X-Ray Film Processors
"Mini-Medical" Series
Installation, Operation,
Service & Parts Manual
250 Clearbrook Rd.
Elmsford, N.Y. 10523
(914) 592-6100
December 15, 2001
0000061122 REV 04
