FIPA M8B3 Quick Start Manual

Electronics and sensors | Cables and plugs

Adapter plug

Adapter plug

Product notes

> Connect electric devices with mismatching connectors without the need for manual wiring

Technical data

Item no. Electric connection
M8B3 / M8S4 M8, 3-pin, female / M8, 4-pin, male
M8B4 / M8S3 M8, 4-pin, female / M8, 3-pin, male
20.553 M8, 4-pin, female / 2x M8, 3-pin, male
20.554
M12, 5-pin, female / 2x M8, 3-pin, male
20.555 2x M8, 3-pin, female / M12, 4-pin, male
20.556 M8, 4-pin, female / M12, 4-pin, male

Wiring diagram and Pin assignment for M8B3 / M8S4

M8 female
4
3 1
FIPA GmbH Headquarters | Germany | Phone: +49 89 962489-0 | www.fipa.com | info@fipa.com
FIPA Inc. | USA | Phone: +1 919 6519888 | www.fipa.com | sales.us@fipa.com
FIPA Ltd. | Thailand | Phone: +66 2 294-4166 | www.fipa.com | sales.th@fipa.com
Cable length [mm]
--
--
300
300
--
--
1 1
2
3 3
4 4
Weight [g]
10
10
38
47
21
13
M8 male
2
3
4
1
